SE Controls FRS00010032 User Manual

Description:
The 3A transformer is a 3 Amp 230 V ac switch mode power supply for use with 24 V dc actuators.
The transformer is fitted behind a double pattress plate, which has two touch panel switches for the
the user interaction.The product is to be fitted into a compatible double pattress box, with a minimum
depth of 35 mm.
The output polarity from the transformer is dependent on which touch button is pressed. When fitted with
'THIS WAY UP!" text at the top of the pattress:
- The right-side button produces a positive 24 V dc on the 24 V A connection with 0 V on the 24V B connection.
- The left side button produces a positive 24 V dc on the 24 V B connection and 0 V on the 24V A connection.
The transformer contains thermal protection for extended excess loads, which will engage output power
limiting and eventual shutdown when prolonged over temperature conditions occur. Output will be restored
once temperature has recovered to normal operating temperatures.
+44 (0)1543 443060
sales@secontrols.com
www.secontrols.com
3 Amp Transformer - Switched
User Guide
Please keep these operating instructions for future reference and maintenance.
Subject to technical modifications. Diagram is not binding.
