Raytheon ST40 Bidata Quick Reference Manual

ST40 Bidata Instrument - quick reference guide
SPEED
Last permanent
screen is displayed
Current
speed
Maximum
speed
Average
speed
3 seconds
Log
Trip
Water
Temp.
To enter adjust mode, press
OFF
SWITCH ON
Reset
3 seconds
Reset
Reset
3 seconds
Adjusting display backlighting/contrast
for 1 second to adjust BACKLIGHTING and a further 1 second to adjust CONTRAST
LEVEL 1 LEVEL 2
To exit adjust mode press
Normal operation
DEPTH
Depth
Minimum
depth
Shallow
alarm
Deep
alarm
Shallow
anchor
alarm
Deep
anchor
alarm
Offset
LEVEL 3
or or wait for 5 second timeout
Notes:
* denotes temporary screens
which will time-out to the previous
permanent screen after 5 seconds.
On repeater instruments, only the
Speed, Water temperature,
Depth and Minimum depth
screens are available.
Alarm on/off
3 seconds
Alarm on/off
3 seconds
Alarm on/off
3 seconds
Alarm on/off
3 seconds
With Set alarm level screen displayed,
press the
and keys simultaneously
to save the alarm level and return to
normal operation.
LEVEL 2
+
Set
alarm
level
-
LEVEL 1
