Summary of Contents for Zanussi ZWF 81441W
- Page 1 User Manual GETTING STARTED? EASY. ZWF 81441W ZWF 81443W EN User Manual Washing Machine...
- Page 2 VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage.
- Page 3 staff kitchen areas in shops, offices and other working – environments; by clients in hotels, motels, bed & breakfast and other – residential type environments; areas for communal use in blocks of flats or in launderettes. – Do not exceed the maximum load of 8 kg (refer to the •...
- Page 4 • Make sure that there is air circulation between • When unpacking the appliance, It is possible to the appliance and the floor. see water flowing from the drain hose. This is • When the appliance is in its permanent position, due to the testing of the appliance with the use check if it is levelled correctly with the aid of a of water in the factory.
- Page 5 DISPOSAL • Remove the door catch to prevent children or pets from becoming trapped in the drum. WARNING! Risk of injury or • Dispose of the appliance in accordance with suffocation. local requirements for the disposal of Waste Electrical and Electronic Equipment (WEEE). •...
- Page 6 TECHNICAL DATA Dimension Width/ Height/ Total depth 59,7 cm /84,7 cm /56,8 cm Electrical connection Voltage 230-240 V Overall power 2200 W Fuse 13 A Frequency 50 Hz Level of protection against ingress of solid particles and moisture IPX4 ensured by the protective cover, except where the low voltage equipment has no protection against moisture Water supply pressure Minimum...
- Page 7 hose from the hose holders. 1. Install the appliance on a flat hard floor. The appliance must be levelled and stable. Make sure that the appliance does not touch the wall or other units and there is air circulation below the appliance.
- Page 8 It is possible to connect the drain hose in different ways: 1. Make a U shape with the drain hose and put it around the plastic hose guide. 2. On the edge of a sink - Fasten the guide to the The end of the drain hose must always water tap or to the wall.
- Page 9 INSTALLATION ON SUSPENDED FLOORING Suspended wooden floors are particularly susceptible to vibration. To limit vibration we recommend placing a waterproof wooden panel, at least 15 mm thick, under the appliance. It should be screwed to at least 2 floor beams and should extend beyond the front feet.
- Page 10 EASY START This appliance is designed with a self cleaning SPECIAL FEATURES draining system, allowing light fluff fibers that fall off the clothes to be drained out with the water, in Your new washing machine meets all modern such a way that there is no need to access this requirements for an effective treatment of laundry area for regular maintenance and cleaning.
- Page 11 – You change the programme while it • The display shows the message operates. some seconds if: – You set a option that is not suitable for the programme. PROGRAMME CHART Programme Maximum load Programme description Default temperature Reference spin (Type of load and level of soiling) Temperature range speed...
- Page 12 Programme Maximum load Programme description Default temperature Reference spin (Type of load and level of soiling) Temperature range speed Jeans 3 kg Items in denim and jersey. Normally soiled items. 40°C 900 rpm 60°C - Cold 30'@ 30° 3 kg A short cycle for lightly soiled synthetic and delicate 30°C 700 rpm...
- Page 13 Programme Spin Rinse Hold Extra Rinse Delay Start Quick ■ ■ ■ ■ Easy Iron ■ ■ Refresh 20min ■ Duvets ■ ■ ■ ■ Jeans ■ 30'@ 30° 1) When you set the Quick option, we recommend that you decrease the quantity of the laundry. It is pos- sible to keep the full load but the washing results can be unsatisfactory.
- Page 14 The related indicator comes on. The related indicator comes on. There is water in a drum when the DELAY START programme completes. To drain the With this option you can delay the start of a water refer to ‘At the end of the programme from 30 minutes to 20 hours.
- Page 15 DAILY USE Compartment for liquid additives WARNING! Refer to Safety chapters. (fabric conditioner, starch). CAUTION! Do not LOADING THE LAUNDRY exceed the MAX level. Open the water tap. Connect the mains plug to the mains socket. 1. Pull the door handle to open the appliance Flap for powder or liquid deter- door.
- Page 16 When the flap is in posi- You can cancel or change the set of tion B and you want to the Delay Start option before you use powder detergent: press the button Start/Pause. After 1. Remove the drawer. pressing the button Start/Pause you 2.
- Page 17 4. Close the door and touch the button Start/ • You must drain the water to open the door. Pause again. The programme (or the Delay Draining the water: Start) continues. 1. To drain the water. • Set a Drain or a Spin programme. AT THE END OF THE PROGRAMME •...
- Page 18 STUBBORN STAINS Insufficient detergent may cause: • unsatisfactory washing results, For some stains, water and detergent is not • the wash load to turn grey, sufficient. • greasy clothes, We recommend that you pre-treat these stains • mould in the appliance. before you put the items in the appliance.
- Page 19 Indicative periodic cleaning schedule: Regularly examine the drum to prevent limescale and rust particles. Descaling Twice a year To remove rust particles use only special products for washing machines. Do this separately from the Maintenance wash Once a month laundry wash. Clean door seal Every two months Always obey the instructions that you...
- Page 20 CLEANING THE DETERGENT DISPENSER CLEANING THE INLET HOSE AND THE VALVE FILTER 45° 20° FROST PRECAUTIONS If the appliance is installed in an area where the temperature can be less than 0 °C, remove the remaining water from the inlet hose and the drain pump.
- Page 21 With some problems, the display shows an alarm code and the Start/Pause button may flash continuously: Problem Possible solution • Make sure that the water tap is open. • Make sure that the pressure of the water supply is not too low. For this The appliance does not information, contact your local water authority.
- Page 22 Problem Possible solution The appliance fills with • Make sure that the drain hose is in the correct position. The hose may water and drains imme- be positioned too low. Refer to "Installation instruction". diately. • Set the spin programme. The spin phase does •...
- Page 23 CONSUMPTION VALUES INTRODUCTION This user manual reports two different tables in order to favour a gradual passage from a reg- ulation to the other: • Regulation EU 1061/2010, valid up to 28th of February 2021, is related to the Energy Effi- ciency classes from A+++ to D, •...
- Page 24 Eco 40-60 pro- Litres h:mm °C gramme Quarter load 0.410 2:40 1351 1) Maximum spin speed. Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.48 0.48 4.00 Time to Off/Standby mode is 15 minutes maximum. ACCORDING TO REGULATION 1061/2010 Approximate Remaining Energy con-...
- Page 25 Programme Litres h:mm °C Cotton 2.60 3:25 1400 90°C Cotton 1.70 3:00 1400 60°C Mix 20° 0.23 2:00 20°C Synthetics 0.68 2:00 40°C Delicates 0.26 1:00 30°C Wool/Handwash 0.24 1:05 30°C 1) Reference indicator of the spin speed. 2) Suitable for washing heavily soiled textiles. 3) Suitable for washing lightly soiled cottons.
- Page 28 WWW.ZANUSSI.COM/SHOP...
