Avidsen STYRKA320 Manual

STYRKA320
TELESCOPIC
EN
MOTOR DRIVE KIT
V1
Piston-style – For 2-panel gates
Ref. 114303
Thank you for purchasing an AVIDSEN automatic gate opener.
This document is a quick start guide detailing the main installation steps as well as the equipment required. To install, please download the installation
manual from the following webpage: www.avidsen.com/produits/recherche.php
Warning: The safety instructions and installation instructions can be found in the installation manual. Follow all these instructions, as an
incorrect installation can cause serious injuries.
CONTENTS OF THE KIT
1
x 1
5 5
x 1 x 1
1 24V motorised cylinders
2 Control unit
3 Pillar mounting bracket
4 Gate mounting bracket
5 Clevis pins
EQUIPMENT REQUIRED (NOT SUPPLIED)
The tools and screws required for the installation must be in good condition and compliant with applicable safety standards.
fl ashing light
3m cable
2 x 0.5mm2
2
x 1
6
x 4
6 Spacer
7 Elastic pin
8 Remote control
9 Flashing light
actuators
attachment to the post:
- electronic panel
- fl ashing light
10m cable
2 x 1.5mm2
3
x 4
7 8
x 4 x 2
attachment of the
brackets
onto the posts:
Choose a screw/nut
appropriate for the
thickness of the gate.
There are 4 attachment
4
x 2
9
x 1
drilling the
post
drilling into
the gate
attachment of the
brackets
on the gate:
system
points
