- Page 1 QUICK START GUIDE Elevator Control Panel & Elevator Floor Expansion Board Applicable Model: EC16 & DEX16 Version: 1.1 Date: August 2023...
- Page 2 Cautions Please note the following cautions. Mis-operation may lead to personal injury or equipment failure: Other Notes: 1) RESET button: Long press 1 to 5 seconds for U disk upgrade; 5 to 10 seconds to restart the controller; 10 seconds or more to restore the factory settings. When restoring the factory settings, only the network configuration of the device is restored, other data is not restored.
- Page 3 LED Indicators After connecting the main controller correctly, turn on the system power, the LED indicators in normal condition is described as follows. 1. LED indicators on the Enclosure PWR indicator (red): Solid Red LED indicates normal energization. COMM indicator (yellow): Slowly flashing Yellow LED indicates data communication is in pr ogress.
- Page 4 System Equipment Composition The elevator controller system is composed of the following equipments. 19 20 DEX16 Expansion Board EC16 Master Control Panel 9.1*6.5inch (230*165mm) 5.2*6.5inch (132*165mm) Description Description Floor Button Control Port FIRE Extend Port Emergency Button Wiegand Manual Button RS-485 Power Input LED Indicator...
- Page 5 System Installation Diagram RS-485 DEX16 EC16 DC12V Alarm FIRE Power In 17-32 layers of extended output Switch TCP/IP TCP/IP Elevator Keys Bus Elevator Cabs F17-32 D147 F1-16 Card Issuer DC12V FR1500S Elevator operation panel...
- Page 6 DEX16 Expansion Board Connection Use the software setup after connecting the DEX16 module to the EC16 master controller. EC16 Elevator Controller Default IP address: 192.168.1.201 Subnet mask: 255.255.255.0 ZKBio CVSecurity IP address: 192.168.1.160 DC12V Subnet mask: 255.255.255.0 TCP/IP +12V 485B 485A #1 DEX16 #2 DEX16...
- Page 7 Elevator Button Connection Elevator original logic controller Elevator button wiring Instruction: Lamp Cord 1 Connect Signal Cable 1 to the NO terminal Lamp Cord 2 of the corresponding floor. After Signal Cable Signal Cable 1 2 is disconnected, COM and NC terminals Signal Cable 2 are connected to the COM and NC terminals Elevator Button...
- Page 8 Reader Connection RS-485 readers and Wiegand readers need to be connected with the master elevator controller in order to make relevant settings through the ZKBio CVSecurity Software. The system sends the personnel information to the master controller through the software, and reader then uploads the data to the master controller for comparison and verification after collection.
- Page 9 Connect to ZKBio CVSecurity 1. Add the elevator control device on the software Login to the software and add the device by searching. The process is as follows: 1) Click Elevator > Elevator Device > Device to enter the device setting interface. 2) Click Search to open the Search interface in the software.
- Page 10 3. Assign elevator control levels group 1) Click Elevator > Elevator Control Rule > Elevator Levels to enter the setting interface. 2) Click New to add a new elevator control level group. 3) Enter the level name, time zones and setting area, then click OK to confirm and exit. 4) After adding successfully, check the levels group.
- Page 11 4. Setting of Elevator Control Authority Allocation Authority allocation is used to manage the elevator control authority of personnel. Only after the authority allocation can personnel normally verify the operation of entering and leaving the elevator. Permission assignment supports three methods: setting access by levels, setting access by person, and setting access by department.
- Page 12 c. Set Access By Department 1) Click Elevator > Elevator Control Rule > Set Access By Department to enter the setting interface. 2) Check the department and click the Add to Default Levels icon in its bar to open the settings window.
- Page 13 Electrical Specifications EC16 Master Control Panel Power 12VDC ± 20%, maximum current 600mA Main Power Supply (without reader and expansion board) 12VDC ± 20%, maximum output current 350mA Wiegand Reader 12VDC ± 20%, maximum output current 750mA RS-485 Reader Output Contact load: 1A / 24VDC Auxiliary Relay Output Note: When connecting to the elevator button, the...
- Page 14 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
