- Page 1 X70 Pro ACTION CAMERA...
- Page 2 It is recommended to read all documents. Then, please check that all components are included in the delivery of the camera. Subject to update without notice. https://www.apexcam.com/product/x70-pro/downloads/ If you have any questions, please contact our Customer Service Department at: supports@apexcam.com...
- Page 3 Contents Security Measures......04 Update Firmware........23 Preparations........06 Battery Use Precautions.....23 Memory Card Precautions....24 Component ...........06 Underwater Use Precautions....24 Check supplied components....08 Troubleshooting.......26 Warranty activation .......09 Charging the battery......09 Format memory card (sold separate- ly) to FAT32..........10 Insert the battery/memory card into the camera ..........11 Turn on the camera ........11 Formatting the inserted memory card..11...
- Page 4 Security Measures Before using the equipment, please make sure you are familiar with its safety measures. If you see any malfunctioning equipment, please contact customer service: supports@apexcam.com Warning: Follow the instructions below to protect against fire, high heat, chemical leakage and electric shock.
- Page 5 ■ Keep the device out of reach of children and infants. Straps or cables may pose a choking, shock, or injury hazard to children. Swallowing camera parts or accessories may also pose a choking or injury hazard to children or infants. ■...
- Page 6 Preparations Components On/Off button/ Mode switching button < > Selector button Work Indicator Light /Shutter < > Lens Flash Light 1.3" Front Screen Down Button < ▼ > Up Button < ▲ >...
- Page 7 2.0" Touch Screen Card Slot (built-in) Lanyard Hole Battery Compartment Working and Charging Indicators Tripod Screw Port Horn HD Mini Output External Microphone/USB Cable Connector Microphone (built-in)
- Page 8 Check the Supplied Components Camera External microphone USB Type-C Cable Handlebar Mount Kit Hand Bag User Manual Installation Manual Waterproof Case Tripod Stand Kit Helmet Bracket Kit 1350mAh Battery with Charging Case 2.4G Remote Control with Battery and Wrist Strap...
- Page 9 Register for Warranty Apexcam X70 Pro comes with a 2 year warranty. Please scan the QR code and activate the warranty before use. http://club.apexcam.com/clubwap.asp?action= Charging the Battery Charging the battery with cables With the battery installed, connect the camera to the AC adapter using the...
- Page 10 Format memory card (sold separately) to FAT32 Plug the card reader with the SD card inserted into the computer. Click the right mouse button and select "Format". Next you need to set "FAT32" as the file system and set the size of the allocation unit and the volume label.
- Page 11 Insert the battery/memory card into the camera Open the battery cover and insert the battery and memory card into the camera. Then close the battery cover again. Make sure the battery and memory card are properly aligned. Turn on the camera Press and hold the <...
- Page 12 List of icons on the monitor The icons and their locations shown in the illustrations may differ from the actual display and are for reference only. Recording on-screen icons [3] [4] [12] [10] [11] Shooting Modes Video Recording Photo Shooting Lapse Mode Mode Mode...
- Page 13 Duration and Numbers 11511 Number of remaining recordable photos 01:47:19 Remaining video recording time 00:00:09 Actual video shooting time WLAN function available Memory card can be recognised Battery Status Battery Life Low Battery Warning Charging Album Menu Sound Recording Available Time-Lapse Video Set Time-Lapse Recording Time [10]...
- Page 14 Playing on-screen icons Video Albums Photo Album 00:00:09 Video Recording Time 1/18 Document number Up/Down Close...
- Page 15 FILEXXX-.MOV Document name and format Delete Setting up on-screen icons Up/Down Record Video Settings Photo Settings System settings Close...
- Page 16 30fps(9:16) formats. Pre-record Mode < On / Off > Pre-record mode is a new video recording mode for Apexcam. Therefore it cannot be set on earlier camcorders. It allows you to resume 5 seconds of video before pressing the <...
- Page 17 Time-Lapse Recording Mode <Off/1min/3min/5 min> Time-lapse photography is a cinematic method of accelerating long-term recorded motion sequences in which the frame rate of the recording camera is reduced relative to the playback frequency. If played back at normal speed, the recording will appear faster. This also makes visible changes that would be impossible or difficult for humans to perceive in real time due to the slow speed.
- Page 18 Timed Selfies <Off/5sec/10sec/20sec> The self-timer delays the exposure by a few seconds. The time can be selected. The self-timer is often used in the following situations: The selfie timer allows the photographer to take a place in the group photo so that he or she can appear in the photo as well.
- Page 19 Close the back cover Close the black snap at the top of the tightly. waterproof case. Remote Control How to start/stop recording...
- Page 20 How to take photos Using WLAN function The WLAN function of the camera allows you to perform the following operations: 1) Transfers photos from the camera to the smartphone. 2) Use your smartphone as a remote control for your camera. 3) Play back photos and animations on your smartphone.
- Page 21 Press the Up button < > to activate the WiFi function. Then the SSID (WLAN network name) and password are displayed. Turn off mobile data and connect the camera and smartphone via a WLAN network. Connect the camera. To turn off the Wi-Fi function, press the Up button <...
- Page 22 The displayed illustrations may differ from the actual display and are for reference only.
- Page 23 Generally, the firmware does not need to be updated. If your camera is not working properly, sometimes the problem can be solved by updating the firmware.You can request the firmware by contacting our customer service department at supports@apexcam.com Battery Use Precautions This camera contains sensitive components such as batteries. Avoid ■...
- Page 24 Memory Card Precautions While recording, use a branded memory card with sufficient ■ performance (fast enough read/write speed) to ensure recording quality and stability. The following memory cards can be used with the camera. 1) Micro SD, Micro SDHC, or Micro SDXC 2) Class 10 or UHS-I 3) Capacity up to 64 GB (FAT32) The camera does not come with a memory card for recording.
- Page 25 Before using the waterproof case, please make sure that the waterproof ■ case is well sealed. If the white rubber seal becomes hard, deformed or damaged, please stop using the waterproof housing and contact us promptly for a new waterproof housing. Please dry the case after use, otherwise the metal buttons will get dusty ■...
- Page 26 Troubleshooting What should I do if the camera and smartphone cannot establish a ■ WLAN connection? 1）Turn off mobile data first. 2) Then make sure the smartphone is connected to the camera's Wi-Fi network, as sometimes smartphones automatically connect to other Wi-Fi networks to which they were previously connected.
- Page 27 How do I turn on the Image Stabiliser? ■ The Image Stabiliser works automatically and requires no additional settings. However, the image stabiliser is not supported in all shooting resolutions. What shooting resolutions does the Image Stabiliser support? ■ The image stabiliser supports 2.7K 30fps and 1080P 60/30fps. How long does the battery last when recording video? ■...
- Page 28 Step 3: Lift the circuit board and slide out the battery as shown in the picture. Step 4: Insert the new battery, keeping the "+" post facing Step 5: Install all 4 screws back onto the board. Step 6: Re-install all 4 screws in the cover.
- Page 29 3) If the problem still cannot be solved, please contact our customer service department to update the firmware or replace the remote control for you. Why are the time and date settings reset? ■ Since the camera cannot connect to the Internet to synchronise the time automatically, the time must be set manually.
