- Page 1 100G QSFP28 & SFP-DD Transceiver Module Installation Guide V1.0.2410A Innovation · Expertise · Agility...
- Page 2 Preface Audience: This installation note provides instructions for installing FS Quad Small Form-factor Pluggable 28 (QSFP28) and Small Form-factor Pluggable Double Density (SFP-DD) transceiver modules. These modules are hot- swappable input/output (I/O) devices that plug into 100GBASE ports, connecting the module to a fiber-optic or copper network.
- Page 3 Preface The table below lists the optical module part number for QSFP28 and SFP-DD packages: Part Number QSFP-SR4-100G QSFP-LR4-100G QSFP-CWDM4-100G QSFP-BIDI-100G QSFP-ER4L-100G QSFP-DR-100G Q28-40/100G-SM4 QSFP-LR-100G QSFP-PSM4-100G QSFP-ELR4-100GM QSFP-PLR4L-100G QSFP-ZR4-100G QSFP-LR4-100GM QSFP-FR-100G QSFP-ESR4-100G QSFP-ER4-100GM QSFP-4W10-100G QSFP-ER4L-100GM QSFP-PLR4-100G QSFP-ERL-100G QSFP-SR1.2-100G Q28-100G-BX40 Q28-100G-BX10...
- Page 4 1.2 Product Part Numbers and Descriptions 1.3 Optical Transmit and Receive Specifications 2. Safety 3. Required Tools 4. Installing QSFP28 and SFP-DD Transceiver Modules 5. Connect Fiber Optic Network Cables 6. Removing QSFP28 and SFP-DD Transceiver Modules Innovation · Expertise · Agility...
- Page 5 These transceivers connect the module's circuitry to the fiber-optic network. • You can use any combination of QSFP28 and SFP-DD transceiver modules supported by FS devices. The only restriction is that each port must match the wavelength specifications of the other end of the fiber or cable, and the cable must not exceed the specified length to ensure reliable communication.
- Page 6 100GBASE LR4 QSFP28 Transceiver, Duplex LC, 10km over SMF QSFP-CWDM4-100G 100GBASE IR4 QSFP28 Transceiver, Duplex LC, 2km over SMF QSFP28-BIDI-100G 100G-SR SWDM4 BiDi QSFP28 Transceiver, Duplex LC, 100m OM4 MMF QSFP-ER4L-100G 100GBASE ER4 QSFP28 Transceiver, Duplex LC, 40km over SMF QSFP-DR-100G 100GBASE DR QSFP28 Transceiver, Duplex LC, 500m over SMF Innovation ·...
- Page 7 100GBASE LR QSFP28 Transceiver, Duplex LC, 10km over SMF QSFP-PSM4-100G 100GBASE PSM4 QSFP28 Transceiver, MTP/MPO, 500m over SMF QSFP-ELR4-100GM 100GBASE LR4 and 112GBASE OTU4 QSFP28 Transceiver, Duplex LC, 20km over SMF QSFP-PLR4L-100G 100GBASE PSM4 QSFP28 Transceiver, MTP/MPO, 2km over SMF QSFP-ZR4-100G...
- Page 8 Part Number Description QSFP-SR4-100GM 100GBASE SR4 and 112GBASE OTU4 QSFP28 Transceiver, MPO-12, 100m over MMF 100GBASE LX4 QSFP28 Transceiver, Duplex LC, 2km over SMF and 100m over QSFP-LX4- QSFP-LX4-100G 100G OM3 MMF QSFP-ER-100G 100GBASE ER QSFP28 Transceiver, Duplex LC, 40km over SMF...
- Page 9 QSFP-ZR-100G-S 100GBASE ZR QSFP28 Transceiver, DCO, CMIS QSFP-ZR-100G 100GBASE ZR QSFP28 Transceiver, DCO, SFF-8636 DWDM2-Q28100G-80 100GBASE DWDM QSFP28 Transceiver, CS, 80km over SMF 100G SFP-DD Transceiver SFPDD-DR-100G 100GBASE-DR SFPDD Transceiver, Duplex LC, 500m over SMF SFPDD-FR-100G 100GBASE-FR SFPDD Transceiver, Duplex LC, 2km over SMF...
- Page 10 Transmit Receive Power Transmit and Receive Part Number Transceiver Type Power (dBm) (dBm) Wavelength (nm) 100GBASE-DR Single QSFP-DR-100G -2.9~4 -5.9~4 1304.5-1317.5 Lambda,1310nm SMF 100G: L0：-9.5Min L1：-9.4Min L2：-9.4Min L0 844~858 40/100GBASE-SM4 Dual 100G:-7.5~2 40G:- L3：-9.4~3.4 L1 874~888 Q28-40/100G-SM4 Rate,850nm MMF 7.5~3 40G：...
- Page 11 Transmit Receive Power Transmit and Receive Part Number Transceiver Type Power (dBm) (dBm) Wavelength (nm) 100GBASE-SR1.2,850nm 844~863 QSFP-SR1.2-100G -6.2~4 -8.2~4 900~918 100GBASE-BX40-D Q28-100G-BX40 BiDi,1309.14nm- 1.7~7.1 -13.8~-3 1304.58+/- 1.01309.14+/- 1.0 TX/1304.58nm-RX SMF 100GBASE-BX10-D 1264.5- 1277.5 Q28-100G-BX10 BiDi,1331nm-TX/1271nm- -1.9~4.8 -26~4.8 1324.5- 1337.5 RX SMF L0 1273.55（1272.55-1274.54）...
- Page 12 Transmit Receive Power Transmit and Receive Part Number Transceiver Type Power (dBm) (dBm) Wavelength (nm) L0 1295.56 (1294.53-1296.59) 100GBASE- L1 1300.05 (1299.02-1301.09) QSFP-4W40-100G-E -2.5~6.5 -20.5~-3.5 4W40,1310nm SMF L2 1304.58 (1303.54-1305.63) L3 1309.14 (1308.09-1310.09) L0 1271 (1264.5-1277.5) 100GBASE-FR Single L1 1291 (1284.5-1297.5) QSFP-FR-100G-29 -3.1~4 -7.1 ~4...
- Page 13 Transmit Receive Power Transmit and Receive Part Number Transceiver Type Power (dBm) (dBm) Wavelength (nm) 100GBASE-FR Single SFPDD-FR-100G -3.1~4 -7.1~4 1304.5- 1317.5 Lambda,1310nm SMF 100GBASE-LR Single SFPDD-LR-100G -1.9~4.8 -8.2~4 1304.5- 1317.5 Lambda,1310nm SMF 2. Safety Moisture-proof caution Do not disassemble or modify Wear anti-static gloves Avoid viewing fiber optic port Qualified personnel only for installation or replacement...
- Page 14 Step 2 Remove the QSFP28 / SFP-DD transceiver module from its protective packaging. Step 3 Check the label on the QSFP28 / SFP-DD transceiver module body to verify that you have the correct model for your network.
- Page 15 Inserting an 100G SFP-DD Transceiver Module into a Module Socket Module Socket Step 6 Firmly press the front end of the QSFP28 or SFP-DD transceiver with your thumb to fully secure the transceiver in the module's transceiver slot. (As shown in Figures 5 and 6.) Figure 5:...
- Page 16 Tips: For complete information on inspecting and cleaning fiber connections, please see this URL: https://resource.fs.com/mall/resource/800g400g-transceiver-acceptance-testing-guide.pdf Step 3 Remove the dust plug from the optical port of the QSFP28 or SFP-DD transceiver module. Step 4 Immediately connect the network interface cable MPO connector to the QSFP28 transceiver module ( Figure 7) or the duplex LC connector to the SFP-DD transceiver module ( Figure 8).
- Page 17 Step 1 For optical QSFP28 or SFP-DD transceivers, disconnect the network interface cable from the QSFP28 or SFP-DD transceiver connector. Step 2 For QSFP28 or SFP-DD transceivers equipped with a pull-tab latch (see Figures 9 and 10, bottom view): • Immediately install the dust plug into the transceiver's optical port.
- Page 18 FS has invested resources in product R&D, quality control, intelligent manufacturing, industry-leading experts, professional technical support, and networking solutions. All is to provide customers with higher-performance, lower-power consumption, and the most cost- effective products, promoting clients' network upgrades. For more information and technical support, welcome to contact us at www.fs.com/contact_us...
