CAMPER TROLLEY (EN)
Model 4500
Congratulations on the purchase of your new Camper Trolley, and thank you for choosing a product from
It is important that you read this manual thoroughly before using your Camper Trolley. Unauthorized use or maintenance
may result in voidance of the guarantee.
Charge the battery completely before first use!
The Lithium battery installed in this machine has only been charged to part of its capacity (as freight
regulations prescribe). It is vital that you charge the battery to its full capacity before operating the machine
to ensure high performance and long life. Charging for the first time may take 6-8 hours (see recharging
instructions).
Always recharge fully after use until the LED light turns green!
Recharge Periodically!
If the Camper Trolley goes unused for more than two months, it is highly recommended to inspect and
charge the battery until the LED on the charger changes from red to green, in order to maintain maximum
battery life and performance.
Do not store the Camper Trolley in direct sunlight or at high temperatures. High temperatures may drain the
battery quickly.
Failure to follow these instructions will damage the battery and void the battery's warranty!
Batteries: Charging and changing
Battery for Camper Trolley
1. To charge the Camper Trolley battery, connect the charger to the Camper Trolley by placing the
charging plug in the outlet on the back end cover.
2. The battery charger displays a constant red light while charging is in progress. Completion of battery
charging is indicated by a constant green light.
WARNING NOTICE FOR BATTERY
Charging
Outlet
More information https://www.caravansplus.com.au
Battery Charger
Charging
Kronings Aps
.
Battery Charger
Fully Charged
Page 1 of 8
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for kronings 4500
Summary of Contents for kronings 4500
- Page 1 CAMPER TROLLEY (EN) Model 4500 Kronings Aps Congratulations on the purchase of your new Camper Trolley, and thank you for choosing a product from It is important that you read this manual thoroughly before using your Camper Trolley. Unauthorized use or maintenance may result in voidance of the guarantee.
- Page 2 Replace the old battery with a new one of the same type. Remember to protect the environment when disposing of batteries – do not dispose of them with ordinary household waste. Technical Data Model 4500 Battery voltage Battery type Lithium Battery capacity Approx.
- Page 3 EC DECLARATION OF CONFORMITY No.: 1 The manufacturer, and/or any authorized representative of the manufacturer within the European Community, hereinafter referred to as Kronings ApS Susaavaenget 1, DK-6710 Esbjerg V declares that the products Camper Trolley CT4500 have been manufactured in conformity with the provisions of the following EC directives ·...
- Page 4 EN 13857:2008 Safety distances to prevent hazard zones being reached by upper and lower limbs EN 60204-1:2006 Safety of Machinery - Electrical equipment of machines - Part 1: General requirements Kronings ApS Susaavaenget 1, DK-6710 Esbjerg V, Denmark Page 4 of 8 More information https://www.caravansplus.com.au...
- Page 5 A2. There must be minimum 10-15 cm inner overlap of the Outer and Inner mounting tubes.) Clamp and support plate for female mounting bracket only come with Model 4500 if it is included in the order. Page 5 of 8...
- Page 6 – so you can try out the different maneuvering options. Load: The Camper Trolley is designed for moving caravans weighing up to approx. 4500 kg (Model CT4500). In order for Camper Trolley to function optimally, the ball weight must be at least 75-85 kg. This ball weight creates about 120-150 kg of pressure on the Camper Trolley.
- Page 7 Activating and Pairing the Camper Trolley with the remote control The Camper Trolley comes pre-paired with the remote control. Turn on the Camper Trolley by simply pressing the Start/Stop button for maximum 1-2 seconds. Turn on the remote control by pushing the forward button () once. The Camper Trolley is now ready to use.
- Page 8 Note that children under age 3 should not play with any plastic bags or small parts from the Camper Trolley, as there is a risk of suffocation. Children should not tow the caravan with the remote control. Kronings ApS Susaavaenget 1, DK-6710 Esbjerg V, Denmark www.kronings.com...
