Operator's Manual
24V MAX* Lithium-ion Cordless Blower CLBL2417A
Save this manual for future reference.
* Maximum initial battery workload voltage (measured without a workload) is 24 volts.
Nominal voltage is 21.6 volts.
Battery Model Number is 24LB4005-CN
Charger Model Number is 24LFC14-ETL
Read all safety rules and instructions carefully before operating this tool.
Distributed By: Suzhou Cleva Electric Appliance Co., Ltd.
NO.8 Ting Rong Street 215122 Suzhou - China
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LawnMaster CLBL2417A
Summary of Contents for LawnMaster CLBL2417A
- Page 1 Operator's Manual 24V MAX* Lithium-ion Cordless Blower CLBL2417A Save this manual for future reference. * Maximum initial battery workload voltage (measured without a workload) is 24 volts. Nominal voltage is 21.6 volts. Battery Model Number is 24LB4005-CN Charger Model Number is 24LFC14-ETL Read all safety rules and instructions carefully before operating this tool.
- Page 2 TABLE OF CONTENTS Section Page TABLE OF CONTENTS SPECIFICATIONS IMPORTANT SAFETY INSTRUCTIONS SYMBOLS KNOW YOUR BLOWER 10-11 ASSEMBLY 12-14 BATTERY PACK AND CHARGER 15-17 OPERATION 18-19 MAINTENANCE 20-21 ENVIRONMENTALLY SAFE BATTERY DISPOSAL TROUBLESHOOTING ® LAWNMASTER WARRANTY EXPLODED VIEW PARTS LIST NOTES...
- Page 3 SPECIFICATIONS 24V MAX* CORDLESS BLOWER Type Cordless, Battery-powered Max Air Volume 335 CFM Max Air Speed 100 MPH Weight with Battery 8.3 lbs (3.76 kg) BATTERY PACK Model Number 24LB4005-CN Rated Voltage of Battery 24 V Max* D.C Capacity of Battery 4.0 Ah Battery Type Lithium-ion...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury: ■ Know your blower. Read the Operator’s Manual carefully. Learn its applications and limitations, as well as the specific potential hazards related to this blower.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS pack, picking up or carrying the blower. Carrying the blower with your finger on the switch invites accidents. ■ Disconnect the battery pack from the blower before making any adjustments, changing accessories, or storing blower. Such preventive safety measures reduce the risk of starting the blower accidentally.
- Page 6 24LB2004, 24LB2004-CN,24LB2605, or 24LB4005 lithium-ion batteries. BATTERY PACK ® ■ The battery pack is only compatible with LawnMaster 24LFC14-ETL, 24LFC02-ETL or 24LSC01- ETL chargers. ■ Recharge only with the charger specified by the manufacturer and listed in this manual. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS ■ Keep cord and charger away from heat to prevent damage to housing or internal parts. ■ Do not operate the charger with a damaged cord or plug, which could cause shorting and electric shock. If damaged, immediately discontinue use. Replace the charger with the identical unit as listed in the Parts List of this manual.
- Page 8 SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency(cycles per second)
- Page 9 SYMBOLS SYMBOL NAME DESIGNATION/EXPLANATION Do not expose battery packs to heat in excess of Heat Alert 140°F (60°C). This product uses lithium-ion batteries. Local, state, or federal laws may prohibit disposal of batteries in Recycle Symbol ordinary trash. Consult your local waste authority for information regarding available recycling and/or disposal options.
- Page 10 KNOW YOUR BLOWER...
- Page 11 KNOW YOUR BLOWER Components 1. Handle 2. Power Trigger 3. Blower Tube 4. Handle 5. Battery Release Button 6. Battery Pack 7. Battery Charger KNOW YOUR BLOWER The safe use of this product requires an understanding of the information on the product labeling and in this Operator’s Manual as well as a knowledge of the project you are attempting.
- Page 12 ASSEMBLY UNPACKING This product requires assembly. ■ Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. ■ Inspect the product carefully to make sure no breakage or damage occurred during shipping. ■...
- Page 13 ASSEMBLY ATTACHING THE BLOWER TUBE 1. Align the widest end of the blower tube with the front opening on the blower. 2. Slide the blower tube over the opening until it snaps in place (Fig. 1). Make sure the blower tube is firmly secured.
- Page 14 ASSEMBLY Release Button Fig. 2 WARNING Follow these instructions in order to avoid injury and to reduce the risk of electric shock or fire: ■ Replace the battery pack or the charger immediately if the battery case or charger cord is damaged. ■...
- Page 15 BATTERY PACK AND CHARGER BATTERY CHARGING ® 1. Use only with 24V LawnMaster battery chargers. The battery charger supplied is specifically designed for the lithium-ion battery used in this tool. 2. Check the power voltage! Battery chargers operate on 120V.
- Page 16 BATTERY PACK AND CHARGER b) If the temperature range is correct and flashing red LED light continues, then remove and reinstall the battery pack. If the LED status repeats a second time, try to charge another identical battery. If the battery charges normally, dispose of the defective battery pack (see Environmental Safe Battery Disposal section).
- Page 17 BATTERY PACK AND CHARGER WARNING If any part of the charger is missing or damaged, do not operate it! Replace the charger with a new one. Failure to heed this warning could result in possible serious injury. Check the voltage! The voltage must comply with the information on the rating label. 1.
- Page 18 OPERATION STARTING / STOPPING THE BLOWER 1. Make sure the battery pack is installed properly. 2. Hold the blower with one hand on the handle. Wrap your thumb around the handle. 3. To start the blower, press the power trigger with your index finger and hold it there. 4.
- Page 19 2. Gather grass clippings, straw, or leaves into piles. Remove debris from corners, around joints, and between bricks. ® NOTE: Your Lawnmaster blower is designed to blow and clean hard surfaces, such as patios, driveways, decks, garages, and sidewalks. Fig. 5...
- Page 20 MAINTENANCE WARNING When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. WARNING Always wear eye protection with side shields marked to comply with ANSI Z87.1, along with hearing protection. Failure to do so could result in objects being thrown into your eyes, resulting in possible serious injury.
- Page 21 MAINTENANCE CHARGER MAINTENANCE 1. Keep the charger clean and clear of debris. Do not allow foreign material into the recessed cavity or on the contacts. Wipe with a dry cloth. Do not use solvents, water, or place in wet conditions. 2.
- Page 22 ENVIRONMENTALLY SAFE BATTERY DISPOSAL The following toxic and corrosive materials are in the batteries used in this battery pack: lithium-ion, a toxic material. WARNING All toxic materials must be disposed of in a specific manner to prevent contamination of the environment.
- Page 23 TROUBLESHOOTING Suspected malfunctions are often due to causes that the user can fix themselves. Therefore, check the product using this section. In most cases the problem can be solved quickly. WARNING Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorized service center or a similarly qualified specialist if you cannot solve the problem yourself! PROBLEM POSSIBLE CAUSE...
- Page 24 ® LAWNMASTER WARRANTY...
- Page 25 EXPLODED VIEW...
- Page 26 PARTS LIST Key Number Part Number Description Quantity Blower Tube Diffusion Barrel Assembly Guide Cone Fairing Assembly Guide Cover Motor Housing Assembly 211070122 Battery 221024107 Charger Replacement parts highlighted in grey are available for after sales purchase. Replacement of repair or internal parts should only be done by a qualified service professional.
- Page 27 NOTES...
