- Page 1 OWNER’S GUIDE & SERVICE MANUAL M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N Model: MPDR424-IS71A...
- Page 2 Got a Marvelous Design? located inside the cabinet on the left side near the top. We would love to see how your Marvel product looks in its new home. You can send us photos of your installed prod- uct at marketing@marvelrefrigeration.com, and we might...
- Page 3 TABLE OF CONTENTS Tip: Click on any section below to jump directly there Installation Integrated Panel Dimensions Integrated Panel Installation...
- Page 4 INTEGRATED PANEL DIMENSIONS 1"(25 mm) diameter counter bore ⁄ " (6 mm) deep 2 places, top drawer only. Panel 19" ⁄ " ⁄ " thickness (483 mm) (60 mm) (603 mm) ⁄ " (30 mm) This side ⁄ " (379 mm) facing interior ⁄...
- Page 5 INTEGRATED PANEL INSTALLATION CAUTION It is important to use the factory provided grille that came with the product to assure proper air flow is maintained through the condenser. The use of a custom grille is not recommended and will void the warranty. Full Overlay Panel Installation Instructions Determine Wood Screw Requirements 1.
- Page 6 INTEGRATED PANEL INSTALLATION Step 1: Remove Drawers from unit. 1. Begin by pulling out the top drawer. Remove screws securing drawer to slides. Pull drawer forward, lift up .35/.31 and out to clear clips in rear of drawer. Move drawer (9 mm/7.5 mm) forward about 1"...
- Page 7 INTEGRATED PANEL INSTALLATION Step 3: Attach the Overlay Panel to the Drawer 1. Set the overlay panel on drawer front face and align edges. The custom overlay panel should be flush with the top of the drawer and centered on the width of the drawer.
