G293-Z23-AAM1
HPC/AI Server - AMD EPYC™ 9005/9004 - 2U UP 4 x PCIe Gen5 GPUs
User Manual
Rev. 3.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the G293-Z23-AAM1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gigabyte G293-Z23-AAM1

Summary of Contents for Gigabyte G293-Z23-AAM1

  • Page 1 G293-Z23-AAM1 HPC/AI Server - AMD EPYC™ 9005/9004 - 2U UP 4 x PCIe Gen5 GPUs User Manual Rev. 3.0...
  • Page 2 (e.g. motherboard, server barebones). Please see the support section of the online product page to check the current availability of these documents. For More Information For related product specifications, the latest firmware and software, and other information please visit our website at http://www.gigabyte.com/Enterprise...
  • Page 3 Conventions The following conventions are used in this user's guide: NOTE! Gives bits and pieces of additional information related to the current topic. CAUTION! Gives precautionary measures to avoid possible hardware or software problems. WARNING! Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 4 Server Warnings and Cautions Before installing a server, be sure that you understand the following warnings and cautions. WARNING! To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature. •...
  • Page 5 Electrostatic Discharge (ESD) CAUTION! ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE, PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT- TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER WHEN HANDLING PARTS.
  • Page 6 Table of Contents Chapter 1 Hardware Installation ..................9 Installation Precautions ..................9 Product Specifications ..................10 System Block Diagram ................... 14 Chapter 2 System Appearance ..................15 Front View ...................... 15 Rear View ....................... 15 Front Panel LED and Buttons ................ 16 Rear System Button and LEDs ..............
  • Page 7 The Main Menu ....................54 Advanced Menu ..................... 57 5-2-1 CPU Configuration ....................58 5-2-2 NVMe Configuration ....................59 5-2-3 SATA Configuration....................60 5-2-4 USB Configuration ....................61 5-2-5 PCI Subsystem Settings ..................63 5-2-6 AST2600 Super IO Configuration ................65 5-2-7 Serial Port Console Redirection ................67 5-2-8 Network Stack Configuration ..................71 5-2-9...
  • Page 8 Security Menu ....................161 5-7-1 Secure Boot ......................162 Boot Menu ....................164 Save & Exit Menu ..................166 5-10 BIOS Recovery .................... 167 5-11 BIOS POST Beep code (AMI standard) ............168 5-11-1 PEI Beep Codes ....................168 5-11-2 DXE Beep Codes ....................168 - 8 -...
  • Page 9 Chapter 1 Hardware Installation Installation Precautions The motherboard/system contain numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the service guide and follow these procedures: • Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer.
  • Page 10 Product Specifications NOTE: We reserve the right to make any changes to the product specifications and product-related information without prior notice. System Š 448mm (W) x 87.5mm (H) x 800mm (D) Dimension Š AMD EPYC™ 9005 Series Processors Š AMD EPYC™ 9004 Series Processors Š...
  • Page 11 Require SAS add-in cards RAID Require RAID add-in cards Expansion Slot Riser Card CRSG627 x 2: 2 x FHFL x16 (Gen5 x16), for GPUs Š Riser Card CRSG628 x 2: 2 x FHFL x16 (Gen5 x16), for GPUs Š Riser Card CRSG01F x 2: 2 x LP x16 (Gen5 x16) Š...
  • Page 12 Power Supply Dual 2200W 80 PLUS Titanium redundant power supply AC Input: Š - 100-127V~/ 15.5A, 50-60Hz - 200-240V~/ 15.5A, 50-60Hz DC Input: (Only for China) Š - 240Vdc/ 16A DC Output: Š - Max 1000W/ 100-127V~ +12.2V/ 81A +12Vsb/ 3A - Max 2200W/ 200-240V~ or 240Vdc Input +12.2V/ 180A +12Vsb/ 3A...
  • Page 13 System Aspeed® AST2600 management controller Š Management GIGABYTE Management Console web interface Š Dashboard Š HTML5 KVM Š Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Š Sensor Reading History Data Š FRU Information Š SEL Log in Linear Storage / Circular Storage Policy Š...
  • Page 14 System Block Diagram 10/100/1G SPI Flash MLAN 32 MB PHY(1ch) ASPEED SPI Flash AST2600 32 MB NCSI 2 x 10Gb 2 x PCIe5.0 x16 LP slots (rear) BASE-T LAN Broadcom PCIe5.0 x16 BCM57416 PCIe5.0 x16 2 x USB 3.2 Gen1 PCIe5.0 x4 PCIe5.0 x4 12-Channel DDR5 RDIMM...
  • Page 15 Chapter 2 System Appearance Front View HDD #4 HDD #0 HDD #5 HDD #1 HDD #2 HDD #6 HDD #3 HDD #7 Description Front Panel LED and Buttons NOTE! Green HDD Latch Supports NVMe • Please Go to Chapter 2-3 Front Panel LED and Buttons for detail description of function LEDs. Rear View 3 4 5 6 7 Power Supply...
  • Page 16 Front Panel LED and Buttons LAN1 LAN2 LAN3 LAN4 Name Color Status Description Green System is powered on Power button with LED System is not powered on or in ACPI S5 state (power off) ID Button Press the button to activate system identification Green Solid On Link between system and network or no access.
  • Page 17 Rear System Button and LEDs Name Color Status Description Green System is powered on Power Button with LED System is not powered on or in ACPI S5 state (power off) ID Button Press the button to activate system identification Reset Button Press the button to reset the system.
  • Page 18 Power Supply Unit (PSU) LED PSU LED State Description No AC power to all power supplies 1Hz Green Blinking AC present / only standby on / Cold redundant mode 2Hz Green Blinking Power supply firmware updating mode AC cord unplugged or AC power lost; with a second power supply in parallel still with AC input power Amber Power supply critical event causing shut down:...
  • Page 19 Hard Disk Drive LEDs LED#2 LED#1 HDD Present RAID SKU Rebuilding LED1 Locate HDD Fault Access (No Access) Disk LED Green ON(*1) BLINK (*2) (LED on Back Panel) Amber No RAID configuration Green ON(*1) (via PCH, HBA) Removed HDD Slot (LED on Back Panel) Amber Green...
  • Page 20 Chapter 3 System Hardware Installation Pre-installation Instructions Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to yourself.
  • Page 21 Removing Chassis Cover Before you remove or install the system cover • Make sure the system is not turned on or connected to AC power. Follow these instructions to remove the system cover: Remove the eight screws securing the cover. Slide the cover towards the rear and remove the cover in the direction of the arrow.
  • Page 22 Removing and Installing the Fan Duct Follow these instructions to remove/install the fan duct: Lift up to remove the fan duct To install the fan duct, align the tabs at the front of the fan duct with the slots in the system fan compartment as shown in the image below, and then push down the fan duct into chassis until its firmly seats System Hardware Installation...
  • Page 23 Installing the CPU and Heat Sink Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.
  • Page 24 Removing and installing the Heat Sink Read the following guidelines before you begin to remove/install the heat sink: • Always turn off the computer and unplug the power cord from the power outlet before installing the heat sink to prevent hardware damage. •...
  • Page 25 Installing the Memory Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. • Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.
  • Page 26 3-5-2 Installing a Memory Before installing a memory module, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module. Be sure to install DDR4 DIMMs on this motherboard. Follow these instructions to install the Memory: Insert the DIMM memory module vertically into the DIMM slot, and push it down.
  • Page 27 3-5-3 DIMM Population Table EPYC Memory Speed based on DIMM Population (One DIMM per Channel) DDR5 Frequency MT/s DIMM DIMM 6400 MT/s 5600 MT/s 4800 MT/s Population Type Grade DIMM Grade DIMM Grade DIMM 1R (1 rank) 6000 5600 4800 RDIMM 2R (2 ranks) 6000...
  • Page 28 EPYC Memory Speed based on DIMM Population (Two DIMM per Channel) DIMM Population DDR5 Frequency MT/s 1,2,3 DIMM Type 6400 MT/s 5600 MT/s 4800 MT/s DIMM0 DIMM1 Grade DIMM Grade DIMM Grade DIMM 5200 4800 4800 4400 4000 4000 RDIMM 5200 4800 4800...
  • Page 29 3-5-4 Processor and Memory Module Matrix Table Memory CPU0 Q’ty D0 C0 G0 H0 I0 J0 K0 L0 1 DIMM 2 DIMM 4 DIMM 6 DIMM 8 DIMM 10 DIMM 12 DIMM NOTE! l DIMM must be populated in sequential alphabetic order, starting with bank A. When only one DIMM is used, it must be populated in memory slot C0.
  • Page 30 Installing the GPU Card • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to installing a PCI card.
  • Page 31 (For Slot1/Slot2) System Hardware Installation - 31 -...
  • Page 32 For Slot3/Slot4 Follow these instructions to install the GPU card: [For Slot3/Slot4] Loosen and remove the single screw at the top of the system and the two screws at the rear of the system securing the PCI cage. Pull the two plastic handles to lift up the PCI cage from the system. Insert the card into the selected slot.
  • Page 33 (For Slot3/Slot4) System Hardware Installation - 33 -...
  • Page 34 Installing a PCI Express Card • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to installing a PCI card.
  • Page 35 System Hardware Installation - 35 -...
  • Page 36 Follow these instructions to install a PCI Express x16 card on left side of the system: Loosen the thumbnail screw securing the PCI Express card bracket on the left side of the system. Remove the PCI Express card bracket from the system. Install the PCI Express card into the bracket.
  • Page 37 System Hardware Installation - 37 -...
  • Page 38 Reinsert the HDD tray into the slot and close the locking lever. CAUTION! We strongly recommend using enterprise level hard disk drives in the Gigabyte server system. For more information of recommended HDDs, please visit the Gigabyte website: https://www.gigabyte.com and search for the specific product QVL from Support & Downloads.
  • Page 39 Replacing the FAN Assembly CAUTION! Before you remove or install the system fans follow these steps: • Make sure the system is not turned on or connected to the AC power.. • Disconnect all necessary cable connections. Failure to observe these warnings could result in personal injury or damage to the equipment.
  • Page 40 Airflow direction Airflow direction [For SYS_FAN1/SYS_FAN2] Disconnect the fan cable and then lift up the fan assembly from the chassis. Reverse the previous steps to install the replacement fan assembly. System Hardware Installation - 40 -...
  • Page 41 Airflow direction System Hardware Installation - 41 -...
  • Page 42 3-10 Replacing the Power Supply CAUTION! • In order to reduce the risk of injury from electric shock, disconnect AC power from the power supply before removing it from the system. Follow these instructions to replace the power supply: Pull up the power supply handle and press the retaining clip on the right side of the power supply along the direction of the arrow.
  • Page 43 3-11 Cable Routing HDD4 ~ HDD7 Top/Motherboard Bo�om/Power Distribu�on Board HDD0 ~ HDD3 Front Panel IO Cable Front Switch/LED Cable Motherboard FP_1 Front IO FP_1 Board System Hardware Installation - 43 -...
  • Page 44 Motherboard / HDD Backplane Board Riser Card Riser Card (CRCG028) (CRCG027) NVMe Card#1 NVMe Card#2 (CRCG029) (CRCG029) Motherboard HDD Backplane Board#1 HDD Backplane Board#2 HDD0 ~ HDD3 HDD4 ~ HDD7 System Hardware Installation - 44 -...
  • Page 45 BP Signal Cable Motherboard BP_1 HDD Backplane Board#1 BP_1 NVMe Cable Motherboard P0_G3_S HDD Backplane Board#2 SL_CN1(MCIO 4I Cable P1) HDD Backplane Board#1 SL_CN1(MCIO 4I Cable P2) BP Signal Cable HDD Backplane Board#1 BP_SERIES HDD Backplane Board#2 BP_1 NVMe Cable Motherboard P0_G1 HDD Backplane Board#2...
  • Page 46 Motherboard / Power Distribution Board 028) rd#2 Power Distribu�on Board Motherboard ATX Power Cable (2x9) Motherboard ATX_2X9P Power Distribution Board SSI_2X9P1(A1) Power Distribution Board RS_5V_3V3(A2) ATX Power Cable (2x9) Motherboard ATX2_1 Power Distribution Board ATX2_1 SMD Cable Motherboard FP_2 Power Distribution Board F_PANEL CPU Power Cable (2x9) Motherboard ATX1_1...
  • Page 47 Power Distribution board / HDD Backplane Board Riser Card (CRCG027) Power Distribu�on Board NVMe Card HDD4 ~ HDD7 HDD0 ~ HDD3 (CRCG029 HDD Backplane Board#1 HDD Backplane Board#2 ATX Power Cable HDD Backplane Board#2 BPB_PWR1 (2x2) Power Distribution Board BPB_PWR2 HDD Backplane Board#1 BPB_PWR(B1) Power Cable...
  • Page 48 System Fan Power Cable System Hardware Installation - 48 -...
  • Page 49 Chapter 4 Motherboard Components Motherboard Components DIMM_P0_L0 DIMM_P0_K0 DIMM_P0_J0 DIMM_P0_I0 DIMM_P0_H0 BMC2 BMC1 DIMM_P0_G0 BIOS1 BIOS2 DIMM_P0_A0 DIMM_P0_B0 DIMM_P0_C0 DIMM_P0_D0 DIMM_P0_E0 DIMM_P0_F0 Item Description PCIe x16 Slot #1 PCIe x16 Slot #3 2 x 9 Pin Power Connector MCIO Connector (P0_G3_S/SATA) MCIO Connector (P0_G3_U/PCIe Gen5) MCIO Connector (P0_G1/PCIe Gen5) M.2 Slot(M2_0/PCIe Gen5)
  • Page 50 Jumper Setting HSMB_SEL BIOS Defined Default Enable PMBUS_SEL BIOS Defined Clear CMOS BIOS_PWD Clear supervisior password Normal [Default] 1 2 3 BIOS_RECOVERY BIOS recovery mode Normal [Default] DIMM_P0_L0 DIMM_P0_K0 DIMM_P0_J0 DIMM_P0_I0 DIMM_P0_H0 BMC2 BMC1 DIMM_P0_G0 BMC Readiness BIOS1 BIOS2 DIMM_P0_A0 DIMM_P0_B0 DIMM_P0_C0 DIMM_P0_D0...
  • Page 51 Backplane Board Storage Connector 4-3-1 CBPE640 Item Description MCIO Connector (U2_3) MCIO Connector (U2_2) MCIO Connector (U2_1) MCIO Connector (U2_0) MCIO Connector (SL_CN1) BP_SERIES BP_1 Motherboard Components - 51 -...
  • Page 52 Chapter 5 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the EFI on the motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters, loading the operating system etc. The BIOS includes a BIOS Setup program that allows the user to modify basic system configuration settings or to activate certain system features.
  • Page 53  Main This setup page includes all the items of the standard compatible BIOS.  Advanced This setup page includes all the items of AMI BIOS special enhanced features. (ex: Auto detect fan and temperature status, automatically configure hard disk parameters.) ...
  • Page 54 The Main Menu Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter other sub-menu. Main Menu Help The on-screen description of a highlighted setup option is displayed on the bottom line of the Main Menu.
  • Page 55 Parameter Description BIOS Information Project Name Displays the project name information. Project Version Displays version number of the BIOS setup utility. Build Date and Time Displays the date and time when the BIOS setup utility was created. BMC Information (Note1) BMC Firmware Version (Note1) Displays BMC firmware version information.
  • Page 56 Parameter Description Onboard LAN Information LAN1/LAN2 MAC Address (Note) Displays LAN MAC address information. System Date Sets the date following the weekday-month-day-year format. System Time Sets the system time following the hour-minute-second format. (Note) The number of LAN ports listed will depend on the motherboard / system model. BIOS Setup - 56 -...
  • Page 57 Advanced Menu The Advanced Menu displays submenu options for configuring the function of various hardware components. Select a submenu item, then press <Enter> to access the related submenu screen. When "Boot Mode Select" is set to Legacy in the Boot > Boot Mode Select section BIOS Setup - 57 -...
  • Page 58 5-2-1 CPU Configuration Description Parameter Enable/Disable the CPU Virtualization. SVM Mode Options available: Disabled, Enabled. Default setting is Enabled. Press [Enter] to view the memory information related to CPU 0. CPU 0 Information BIOS Setup - 58 -...
  • Page 59 5-2-2 NVMe Configuration Parameter Description NVMe Configuration Displays the NVMe devices connected to the system. Enable/Disable NVMe LED Control. NVMe LED Control Options available: System Default, Disabled, Enabled. Default setting is System Default. BIOS Setup - 59 -...
  • Page 60 5-2-3 SATA Configuration Parameter Description Displays the installed HDD devices information. System will automatically SATA Configuration detect HDD type. BIOS Setup - 60 -...
  • Page 61 5-2-4 USB Configuration (Note) This item is present only if you attach USB devices. BIOS Setup - 61 -...
  • Page 62 Parameter Description USB Configuration USB Module Version Displays the USB module version information. USB Controllers Displays the supported USB controllers. USB Devices: Displays the USB devices connected to the system. Enable/Disable the Legacy USB support function. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep Legacy USB Support USB devices available only for EFI applications.
  • Page 63 5-2-5 PCI Subsystem Settings BIOS Setup - 63 -...
  • Page 64 Description Parameter Displays the PCI Bus Driver version information. PCI Bus Driver Version U2_P0_P0/2, U2_P1_P0/1/2/3 Change PCIe lanes. OCP# Options available: Disabled, Auto, x16, x8x8, x8x4x4, x4x4x8, x4x4x4x4. Default setting is Auto. Lanes (Note1) When enabled, this setting will initialize the device expansion ROM U2_P0_P0/2, U2_P1_P0/1/2/3 for the related devices.
  • Page 65 5-2-6 AST2600 Super IO Configuration Description Parameter AST2600 Super IO Configuration Super IO Chip Displays the super IO chip information Serial Port 1 Press [Enter] for configuration of advanced items. Configuration BIOS Setup - 65 -...
  • Page 66 5-2-6-1 Serial Port 1 Configuration Description Parameter Serial Port 1 Configuration Enable/Disable the Serial Port (COM). When set to Enabled allows you to configure the Serial port 1 settings. When set to Disabled, displays no Serial Port (Note) configuration for the serial port. Options available: Disabled, Enabled.
  • Page 67 5-2-7 Serial Port Console Redirection Parameter Description Select whether to enable console redirection for specified device. Console COM1/Serial Over LAN redirection enables the users to manage the system from a remote Console Redirection (Note) location. Options available: Enabled, Disabled. Default setting is Disabled. Press [Enter] to configure advanced items.
  • Page 68 Parameter Description Parity Š – A parity bit can be sent with the data bits to detect some transmission errors. – Even: parity bit is 0 if the num of 1's in the data bits is even. – Odd: parity bit is 0 if num of 1's in the data bits is odd. –...
  • Page 69 Parameter Description Legacy Console Redirection Press [Enter] to configure advanced items. Redirection COM Port Š – Selects a COM port for Legacy serial redirection. – Default setting is COM1/SOL. Resolution Š – Selects the number of rows and columns used in Console Redirection for legacy OS support.
  • Page 70 Parameter Description Flow Control Š – Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a 'stop' signal can Serial Port for Out-of-Band be sent to stop the data flow. Once the buffers are empty, a 'start' EMS Console Redirection signal can be sent to re-start the flow.
  • Page 71 5-2-8 Network Stack Configuration Parameter Description Enable/Disable the UEFI network stack. Network Stack Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 PXE feature. Ipv4 PXE Support (Note) Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 HTTP feature. Ipv4 HTTP Support (Note) Options available: Enabled, Disabled.
  • Page 72 5-2-9 Post Report Configuration Parameter Description Post Report Configuration Error Message Report Enable/Disable the POST Error Message support. Post Error Message Options available: Enabled, Disabled. Default setting is Enabled. Halt On Options available: No Error, All Error. Default setting is No Error. BIOS Setup - 72 -...
  • Page 73 5-2-10 Trusted Computing Parameter Description Configuration Enable/Disable BIOS support for security device. OS will not show security device. TCG EFI protocol and INT1A interface will not be Security Device Support available. Options available: Disabled, Enabled. Default setting is Enabled. Select Enable to activate TPM support feature. SPI TPM Support Options available: Disabled, Enabled.
  • Page 74 5-2-11 PSP Firmware Versions The PSP Firmware Versions page displays the basic PSP firmware version information. Items on this window are non-configurable. BIOS Setup - 74 -...
  • Page 75 5-2-12 S5 RTC Wake Settings Parameter Description Enable/Disable system wake on alarm event. Options available: Disabled, Fixed Time, Dynamic Time. When Fixed Time Wake System from S5 is selected, system will wake on the hr::min::sec specified. Default setting is Disabled. BIOS Setup - 75 -...
  • Page 76 5-2-13 Graphic Output Configuration Parameter Description Selects output device type. Output Device Type Options available: First loaded Device, Onboard Device, External Device, Specific Device. Default setting is Onboard Device. BIOS Setup - 76 -...
  • Page 77 5-2-14 AMD Mem Configuration Status Description Parameter Press [Enter] to view the memory configuration status related to CPU 0. CPU 0 BIOS Setup - 77 -...
  • Page 78 5-2-15 Tls Auth Configuration Parameter Description Press [Enter] for configuration of advanced items. Enroll Cert Š – Press [Enter] to enroll a certificate • Enroll Cert Using File • Cert GUID Server CA Configuration Input digit character in 1111111-2222-3333-4444-1234567890ab format. –...
  • Page 79 5-2-16 RAM Disk Configuration Parameter Description Specifies the type of memory to use from available memory pool in system to create a disk. Disk Memory Type Options available: Boot Service Data, Reserved. Default setting is Boot Service Data. Creates a raw RAM disk. Size (Hex) Š...
  • Page 80 5-2-17 iSCSI Configuration Parameter Description Press [Enter] and name iSCSI Initiator. Only IQN format is accepted. iSCSI Initiator Name Range: from 4 to 223 Add an Attempt Press [Enter] to configure advanced items. Delete Attempts Press [Enter] to configure advanced items. Change Attempt Order Press [Enter] to configure advanced items.
  • Page 81 5-2-18 Broadcom BCM57416 10GBASE-T Network Connection Parameter Description Press [Enter] to view firmware image information. Firmware Image Menu Press [Enter] to configure advanced items. Multi-Function Mode Š – Configures the NIC Hardware Mode. – Options available: SF, NPAR 1.0. Default setting is SF. SR-IOV Š...
  • Page 82 Description Parameter Support RDMA Š – Enable/Disable RDMA support for this port. – Options available: Disabled, Enabled. Default setting is Disabled. DCB Protocol Š – Enable/Disable DCB protocol. – Options available: Disabled, Enabled (IEEE only), CEE (only), Both (IEEE preferred with fallback to CEE). Default setting is Disabled. LLDP nearest bridge Š...
  • Page 83 Parameter Description Pre-boot Wake On LAN Š – Configures Pre-boot Wake on LAN (WOL). – Options available: Disabled, Enabled. Default setting is Enabled. VLAN Mode Š – Configures the virtual LAN (VLAN) mode. – Options available: Disabled, Enabled. Default setting is Disabled. MBA Configuration Menu VLAN ID Š...
  • Page 84 5-2-19 VLAN Configuration Parameter Description Press [Enter] to configure advanced items. Create new VLAN Š VLAN ID Š – Sets VLAN ID for a new VLAN or an existing VLAN. – Press the <+> / <-> keys to increase or decrease the desired values. –...
  • Page 85 5-2-20 MAC IPv4 Network Configuration Parameter Description Indicates whether network address is configured successfully or not. Configured Options available: Enabled, Disabled. Default setting is Disabled. Options available: Enabled, Disabled. Default setting is Disabled. Enable DHCP (Note) Local IP Address Press [Enter] to configure local IP address. (Note) Press [Enter] to configure local NetMask.
  • Page 86 5-2-21 MAC IPv6 Network Configuration Parameter Description Press [Enter] to configure advanced items. Displays the MAC Address information. Š Interface ID Š – The 64 bit alternative interface ID for the device. The string is colon separated. e.g. ff:dd:88:66:cc:1:2:3. DAD Transmit Count Š...
  • Page 87 AMD CBS Menu AMD CBS menu displays submenu options for configuring the CPU-related information that the BIOS automatically sets. Select a submenu item, then press [Enter] to access the related submenu screen. BIOS Setup - 87 -...
  • Page 88 5-3-1 CPU Common Options BIOS Setup - 88 -...
  • Page 89 Parameter Description CPU Common Options Performance Press [Enter] for configuration of advanced items. Allow REP-MOV/STOS to use non-caching streaming stores for large sizes. REP-MOV/STOS Streaming Options available: Disabled, Enabled. Default setting is Enabled. Prefetcher settings Press [Enter] for configuration of advanced items. Core Watchdog Press [Enter] for configuration of advanced items.
  • Page 90 Parameter Description Controls the Secure Memory Encryption Enable (SMEE) function. SMEE Options available: Disable, Enable, Auto. Default setting is Auto. Action to take when a CCD BIST failure is detected. Action on BIST Failure Options available: Do nothing, Down-CCD, Auto. Default setting is Auto. Enhanced REP MOVSB/ Options available: Disabled, Enabled, Auto.
  • Page 91 5-3-1-1 Performance Parameter Description Performance Options available: Normal Operation, Customized. Default setting is Normal OC Mode (Note) Operation. Allows you to accept or decline enabling Custom Core Pstates. When Custom Core Pstates accepted, you can disable or customize core pstates. Allows you to accept or decline enabling CCDs, processor cores and threads.
  • Page 92 5-3-1-2 Prefetcher Settings Parameter Description Prefetcher settings Enable/Disable L1 Stream HW Prefetcher. L1 Stream HW Prefetcher Options available: Disable, Enable, Auto. Default setting is Auto. Use memory access history of individual instructions to fetch additional lines when each access is a constant distance from the previous. L1 Stride Prefetcher Enable/Disable L1 Stride Prefetcher.
  • Page 93 5-3-1-3 Core Watchdog Parameter Description Core Watchdog Enable/Disable CPU Watchdog Timer. Core Watchdog Timer Enable (Note) Options available: Disabled, Enabled, Auto. Default setting is Auto. Select the CPU Watchdog Timer interval. Options available: 2.681s, 1.340s, 669.41ms, 334.05ms, 166.37ms, Core Watchdog Timer Interval 82.53ms, 40.61ms, 20.970ms, 10.484ms,5.241ms, 2.620ms, 1.309ms, 654.08us, 326.4us, 162.56us, 80.64us, 39.68us, Auto.
  • Page 94 5-3-2 DF Common Options Parameter Description DF Common Options Memory Addressing Press [Enter] for configuration of advanced items. ACPI Press [Enter] for configuration of advanced items. Link Press [Enter] for configuration of advanced items. SDCI Press [Enter] for configuration of advanced items. Probe Filter Press [Enter] for configuration of advanced items.
  • Page 95 Parameter Description Options available: Auto, 1 Segment, 2 Segments, 4 Segment. Number of PCI Segments Default setting is Auto. Options available: Disabled, Enabled, Auto. Default setting is Auto. CCM Throttler Clean Victim FTI Cmd Options available: Disabled, Enabled, Auto. Default setting is Auto. Balancing Options available: Disabled, Enabled, Auto.
  • Page 96 5-3-2-1 Memory Addressing Parameter Description Memory Addressing Specifies the number of desired NUMA nodes per socket. Options available: NPS0, NPS1, NPS2, NPS4, Auto. Default setting is Auto. NUMA nodes per socket NOTE! • Available options may vary by system configuration. •...
  • Page 97 5-3-2-2 ACPI Parameter Description ACPI ACPI SRAT L3 Cache As Enable/Disable report each L3 cache as a NUMA Domain to the OS. Options available: Disabled, Enabled, Auto. Default setting is Auto. NUMA Domain Determines how the SLIT distances are declared. ACPI SLIT Distance Control Options available: Manual, Auto.
  • Page 98 5-3-2-3 Link Parameter Description Enable/Disable GMI link encryption. GMI encryption control Options available: Disabled, Enabled, Auto. Default setting is Auto. Enable/Disable xGMI link encryption. xGMI encryption control Options available: Disabled, Enabled, Auto. Default setting is Auto. Configures the number of xGMI2 links used on a multi-socket system. xGMI Link Configuration Options available: Auto, 3 xGMI Links, 4 xGMI Links, 2 xGMI Links + 2 PCI Links.
  • Page 99 Parameter Description xGMI Global Preset List Press [Enter] to configure the xGMI Preset list. xGMI Initial Preset Press [Enter] to configure the xGMI Initial Preset CPU0 link. xGMI TXEQ Search Mask Press [Enter] to configure the xGMI TXEQ Search Mask CPU0 link. Press [Enter] to configure the xGMI AC/DC Coupled link.
  • Page 100 5-3-2-4 SDCI Parameter Description SDCI Options available: Disabled, Enabled, Auto. Default setting is Auto. (Note) DisRmSteer Options available: Disabled, Enabled, Auto. Default setting is Auto. (Note) Advanced items prompt when this item is defined. BIOS Setup - 100 -...
  • Page 101 5-3-2-5 Probe Filter Parameter Description Specifies whether multiple memory/CXL channels will share probe filter Organization storage. Options available: Auto, Dedicated, Shared. Default setting is Dedicated. Controls PDR settings that may impact performance by workload and/or Periodic Directory Rinse (PDR) processor. Tuning Options available: Memory-Sensitive, Cache-Bound, Neutral, Adaptive, Auto.
  • Page 102 5-3-3 UMC Common Options Parameter Description UMC Common Options DDR Addressing Options Press [Enter] for configuration of advanced items. DDR Controller Configuration Press [Enter] for configuration of advanced items. DDR MBIST Options Press [Enter] for configuration of advanced items. DDR RAS Press [Enter] for configuration of advanced items.
  • Page 103 5-3-3-1 DDR Addressing Options Parameter Description DDR Addressing Options Interleaves memory blocks across the DRAM chip selects for node 0. Chipselect Interleaving Options available: Disabled, Auto. Default setting is Auto. Enable or disable bank addressing hashing. Address Hash Bank Options available: Disabled, Enabled, Auto. Default setting is Auto. Enable or disable CS addressing hashing.
  • Page 104 5-3-3-2 DDR Controller Configuration Parameter Description DDR Controller Configuration DDR Power Options Press [Enter] for configuration of advanced items. Memory Channel Disable Press [Enter] for configuration of advanced items. Refresh Management (RFM) Press [Enter] for configuration of advanced items. Memory Context Restore Options available: Disabled, Enabled, Auto.
  • Page 105 5-3-3-2-1 DDR Power Options Parameter Description DDR Power Options Enable or disable DDR power down mode. Power Down Enable Options available: Disabled, Enabled, Auto. Default setting is Auto. Sub Urgent Refresh Lower Specifies the stored refresh limit required to enter sub-urgent refresh mode. Bound Urgent Refresh Limit Specifies the stored refresh limit required to enter urgent refresh mode.
  • Page 106 5-3-3-2-2 Memory Channel Disable Parameter Description Memory Channel Disable Memory Channel Disable Bitmask CPU0/1 Channel_# Press [Enter] to enable/disable specific memory channel. BIOS Setup - 106 -...
  • Page 107 5-3-3-2-3 Refresh Management (RFM) Parameter Description Refresh Management (RFM) Configure Refresh Management. Refresh Management Options available: Enable, Disable, Auto, Force Enable. Default setting is Auto. RAA Initial Management Override Rolling Accumulated ACT Initial Management Threshold. Options available: 32, 40, 48, 56, 64, 72, 80, Auto. Default setting is Auto. Threshold RAA Maximum Management Override Rolling Accumulated ACT Maximum Management Threshold.
  • Page 108 5-3-3-3 DDR MBIST Options Parameter Description DDR MBIST Options Enable/Disable the Memory MBIST function. MBIST Enable Options available: Disabled, Enabled, Auto. Default setting is Auto. Selects MBIST Test Mode. Interface Mode: Tests Single and Multiple CS transactions and Basic Connectivity. MBIST Test Mode (Note1) Data Eye Mode: Measures Voltage vs.
  • Page 109 Parameter Description Enable/Disable memory healing BIST. Memory Healing BIST Options available: Disabled, PMU Mem BIST, Self-Healing Mem BIST, PMU and Self-Healing Mem BIST. Default setting is Disabled. DDR Healing BIST Execution Options available: One Time, Every boot. Mode Default setting is One Time. (Note2) For DRAM errors found in the BIOS memory BIST select the repair type.
  • Page 110 5-3-3-3-1 Data Eye Parameter Description Data Eye Pattern Select Options available: PRBS, SSO, Both. Default setting is PRBS. Pattern Length Determines the pattern length. The possible options are N=3..12. This item helps read the aggressors channels. Aggressor Channel Options available: One Sub-Channel, Half Channels, All Channels. Default setting is All Channels.
  • Page 111 Parameter Description Target Static Lane Select This item is configurable when Target Static Lane Control is set to Upper 32 bits Enabled. Target Static Lane Select This item is configurable when Target Static Lane Control is set to Lower 32 bits Enabled.
  • Page 112 5-3-3-4 DDR RAS Parameter Description DDR RAS Enable/Disable the Data Poisoning function. Data Poisoning Options available: Auto, Enabled, Disabled. Default setting is Auto. DRAM Boot Time Post Package Enable/Disable the DRAM Boot Time Post Package Repair function. Options available: Enabled, Disabled. Default setting is Disabled. Repair DRAM Runtime Post Package Enable/Disable the DRAM Runtime Post Package Repair function.
  • Page 113 Parameter Description Press [Enter] to configure advanced items. DRAM ECC Symbol Size Š – Configures the DRAM ECC Symbol Size. – Options available: Auto, x4, x16. Default setting is Auto. DRAM ECC Enable Š – Enable/Disable DRAM ECC. When set to Auto, it will set ECC to enable.
  • Page 114 Press [Enter] to configure advanced items. DRAM ECS Mode Š – Options available: Auto, AutoECS, ManualECS, DisableECS. Default setting is Auto. DRAM Redirect Scrubber Enable Š – Options available: Auto, Enabled, Disabled. Default setting is Auto. DRAM Scrub Redirection Limit Š...
  • Page 115 Press [Enter] to configure advanced items. DRAM ECS Mode Š – Options available: Auto, AutoECS, ManualECS, DisableECS. Default setting is Auto. DRAM Redirect Scrubber Enable Š – Options available: Auto, Enabled, Disabled. Default setting is Auto. DRAM Scrub Redirection Limit Š...
  • Page 116 5-3-3-5 DDR Bus Configuration Parameter Description DDR Bus Configuration Press [Enter] to configure advanced items. RTT_NOM_WR P-State 0 Š – Default setting is Auto. RTT_NOM_RD P-State 0 Š – Default setting is Auto. P-State 0 Dram ODT RTT_WR P-State 0 Š...
  • Page 117 Select the ODT impedance for all DBYTE IOs. Options available: Auto, High Impedance, 480 ohm, 240 ohm, 160 ohm, Processor ODT Pull Up 120 ohm, 96 ohm, 80 ohm, 68.6 ohm, 60 ohm, 53.3 ohm,48 ohm, 43.6 ohm, impedance 40 ohm, 36.9 ohm, 34.3 ohm, 32 ohm, 30 ohm, 28.2 ohm, 26.7 ohm, 25.3 ohm.
  • Page 118 5-3-3-6 Enforce POR Parameter Description Enforce POR Decline/Accept to configure the advanced items. Accept Active Memory Timing Active memory Timing Settings. Options available: Auto, Enabled. Default setting is Auto. Settings (Note) Specifies the memory target speed in MT/s. Memory Target Speed Options available: Auto, DDR3200, DDR3600, DDR4000, DDR4400, DDR4800, DDR5200, DDR5600.
  • Page 119 5-3-3-7 DDR Training Options Parameter Description DDR Training Options Specify PDA enumeration mode. DRAM PDA Enumerate ID Options available: Auto, Toggling PDA enumeration mode, Legacy PDA Programming Mode enumeration mode. Default setting is Auto. Press [Enter] to configure advanced items. Periodic Training Mode Š...
  • Page 120 5-3-3-8 DDR Security Parameter Description Security Enable/Disable Transparent SME. TSME Options available: Auto, Enabled, Disabled. Default setting is Auto. Options available: AES-128, AES-256. Default setting is AES-256. Enable/Disable Data Scrambling. Data Scramble Options available: Enabled, Disabled. Default setting is Enabled. SME-MK Options available: Enabled, Disabled.
  • Page 121 5-3-3-9 DDR PMIC Configuration Parameter Description DDR PMIC Configuration Enables support for PMIC Error Reporting. PMIC Error Reporting Options available: Auto, False, True. Default setting is Auto. Options available: Secure Mode, Programmable Mode. PMIC Operation Mode Default setting is Programmable Mode. Options available: Always, Never, Once.
  • Page 122 5-3-3-10 DDR Miscellaneous Parameter Description DDR Miscellaneous ODTS CMD Throttle Threshold Options available: Auto, > 85'C, > 90'C, > 95'C. Default setting is Auto. BIOS Setup - 122 -...
  • Page 123 5-3-4 NBIO Common Options BIOS Setup - 123 -...
  • Page 124 Parameter Description NBIO Common Options SMU Common Options Press [Enter] for configuration of advanced items. NBIO RAS Common Press [Enter] for configuration of advanced items. Options PCIE Press [Enter] for configuration of advanced items. nBif Common Options Press [Enter] for configuration of advanced items. IOMMU/Security Press [Enter] for configuration of advanced items.
  • Page 125 5-3-4-1 SMU Common Options Parameter Description SMU Common Options Power Policy Quick Options available: Standard, Best Performance, Energy Efficient. Setting Default setting is Standard. TDP Control Options available: Manual, Auto. Default setting is Auto. PPT Control Options available: Manual, Auto. Default setting is Auto. Selects use the fused Determinism or set customized Determinism.
  • Page 126 Parameter Description Enable/Disable the CPPC feature. CPPC Options available: Disabled, Enabled, Auto. Default setting is Auto. Enable/Disable the HSMP support. HSMP Support Options available: Disabled, Enabled, Auto. Default setting is Auto. SVI3 SVC Speed Control Options available: Auto, Manual. Default setting is Auto. Options available: Auto, Disable, 1 stack, 2 stack, 4 stack.
  • Page 127 5-3-4-2 NBIO RAS Common Options Parameter Description NBIO RAS Common Options NBIO RAS Control Options available: Disabled, MCA, Auto. Default setting is Auto. The value may be used to mask SyncFlood caused by NBIO RAS options. NBIO SyncFlood Generation Options available: Enabled, Disabled, Auto. Default setting is Auto. The value may be used to enable SyncFlood reporting to APML.
  • Page 128 5-3-4-3 PCIE BIOS Setup - 128 -...
  • Page 129 Parameter Description PCIE Data Object Exchange Options available: Auto, Disabled, Enabled. Default setting is Auto. Options available: Auto, Disable, Enable. Default setting is Auto. RTM Margining Support Multi Upstram Auto Speed Options available: Auto, Disable, Enable. Default setting is Auto. Change On Last Rate When enabled, allows the PCIe RP to enter Polling.Compliance state.
  • Page 130 Parameter Description Options available: Maximum Speed, GEN1, GEN2, GEN3, GEN4, GEN5, PCIE Target Link Speed Auto. Default setting is Auto. Options available: Disable, L0s, L1, Auto. Default setting is Auto. ASPM Control MCTP Enable Options available: Enable, Disable, Auto. Default setting is Disable. Options available: Enable, Disable, Auto.
  • Page 131 5-3-4-4 nBif Common Options Parameter Description RCC_DEV0 ACS Rcc_Dev0 Š – Options available: Auto, Disabled, Enabled. Default setting is Auto. AER Rcc_Dev0 Š – Options available: Auto, Disabled, Enabled. Default setting is Auto. DlfEnableStrap1 Š – Options available: Auto, Disabled, Enabled. Default setting is Auto. Phy16GTStrap1 Š...
  • Page 132 Parameter Description RCC_DEV0 P2PEgressStrap5 Š (continued – Options available: Auto, Disabled, Enabled. Default setting is Auto. DirectTranslatedStrap5 Š – Options available: Auto, Disabled, Enabled. Default setting is Auto. SsidEnStrap5 Š – Options available: Auto, Disabled, Enabled. Default setting is Auto. PriEnPageReq Š...
  • Page 133 5-3-4-5 IOMMU/Security Parameter Description Enable/Disable the SEV-SNP support. SEV-SNP Support Options available: Disable, Enable. Default setting is Disable. Enable/Disable DRTM Memory reservation. DRTM Memory Reservation Options available: Disabled, Enabled, Auto. Default setting is Auto. Enable/Disable DRTM ACPI virtual device. DRTM Virtual Device Support Options available: Disabled, Enabled, Auto.
  • Page 134 5-3-4-6 Enable Port Bifurcation Parameter Description Options available: Disable, Enable, Auto. Default setting is Auto. Enable Bifurcation (Note) Socket0 Slot Info Override Socket1 Slot Info Override (Note) Advanced items prompt when this item is defined. BIOS Setup - 134 -...
  • Page 135 5-3-4-7 Link EQ Preset Options Parameter Description Press [Enter] to configure advanced items. GEN3/4/5 Preset Search Mask Configuration Š – Options available: Custom, Auto. Default setting is Auto. BIOS Setup - 135 -...
  • Page 136 5-3-5 FCH Common Options Parameter Description FCH Common Options I3C/I2C Configuration Options Press [Enter] for configuration of advanced items. SATA Configuration Options Press [Enter] for configuration of advanced items. USB Configuration Options Press [Enter] for configuration of advanced items. AC Power Loss Options Press [Enter] for configuration of advanced items.
  • Page 137 5-3-5-1 I3C/I2C Configuration Options Parameter Description I3C/I2C Configuration Options Options available: Both Disabled, I3C Enabled, I2C Enabled, Auto. I3C/I2C 0/1/2/3 Enable Default setting is Auto. I2C 4/5 Enable Options available: Disabled, Enabled, Auto. Default setting is Auto. Release SPD Host Control Options available: Disabled, Enabled.
  • Page 138 5-3-5-2 SATA Configuration Options Parameter Description SATA Configuration Options Enable/Disable OnChip SATA controller. SATA Enable Options available: Disabled, Enabled, Auto. Default setting is Auto. SATA RAS Support Options available: Disabled, Enabled, Auto. Default setting is Auto. SATA Staggered Spin-up Options available: Disabled, Enabled, Auto. Default setting is Auto. SATA Disabled AHCI Prefetch Options available: Disabled, Enabled, Auto.
  • Page 139 5-3-5-3 USB Configuration Options Parameter Description USB Configuration Options Enable/Disable USB controller. XHCI Controller0/1 enable Options available: Enabled, Disabled, Auto. Default setting is Auto. USB ecc SMI Enable Options available: Enable, Off, Auto. Default setting is Auto. Press [Enter] for configuration of advanced items. MCM USB enable XHCI2/ XHCI3 enable (Socket1) Š...
  • Page 140 5-3-5-4 AC Power Loss Options Parameter Description AC Power Loss Options Selects the AC Loss Control Method. AC Loss Control Options available: Power Off, Power On, Last State. Default setting is Last State. Enable/Disable set FCH power failed shadow by AC Loss control policy in Set FCH Power failed ABL.
  • Page 141 5-3-5-5 Uart Configuration Options Parameter Description Uart Configuration Options Uart 0/1/2 Enable Options available: Disabled, Enabled, Auto. Default setting is Auto. BIOS Setup - 141 -...
  • Page 142 5-3-5-6 FCH RAS Options Parameter Description FCH RAS Options Enable/Disable the ALink RAS Support. ALink RAS Support Options available: Disabled, Enabled, Auto. Default setting is Auto. Enables AB to forward downstream sync-flood message to system Reset After Sync-Flood controller. Options available: Enable, Disable, Auto. Default setting is Auto. BIOS Setup - 142 -...
  • Page 143 5-3-5-7 Miscellaneous Options Parameter Description Miscellaneous Options Select whether or not Enable the Spread Spectrum Feature. FCH Spread Spectrum Options available: Disabled, Enabled, Auto. Default setting is Auto. Enable/Disable Boot Timer. Boot Timer Enable Options available: Disabled, Enabled, Auto. Default setting is Auto. BIOS Setup - 143 -...
  • Page 144 5-3-6 SOC Miscellaneous Control Parameter Description SOC Miscellaneous Control Enable/Disable the ConsoleOut function for ABL. ABL Console Out Control (Note) Options available: Disable, Enable, Auto. Default setting is Auto. ABL Console Out Serial Options available: eSPI, SOC UART0, SOC UART1, Auto. Default setting is Auto.
  • Page 145 Parameter Description Options available: False, True. Default setting is False. PSP error injection support Press [Enter] for configuration of advanced items. FAR enforcement state Š – Default setting is Enabled. Firmware Anti-rollback (FAR) SPL value in the CPU Fuse Š SPL value in the SPL table Š...
  • Page 146 5-3-7 CXL Common Options Parameter Description CXL Common Options CXL Control Options available: Auto, Enabled, Disabled. Default setting is Auto. Options available: Auto, Enabled, Disabled. Default setting is Auto. CXL SPM CXL Encryption Options available: Enabled, Disabled. Default setting is Disabled. Options available: Auto, Enabled, Disabled.
  • Page 147 Parameter Description Press [Enter] for configuration of advanced items. CXL Protocol Error Reporting Š – Options available: Disabled, SameAsPcieAer, ForceAerFwFirstIfCxlPresent. Default setting is SameAsPcieAer. CXL Component Error Reporting Š – Options available: OS First, FW-First. Default setting is FW-First. CXL RAS CXL Root Port Isolation Š...
  • Page 148 AMD PBS Menu AMD PBS Option menu displays submenu options for configuring the function of AMD PBS. Select a submenu item, then press [Enter] to access the related submenu screen. Parameter Description Protect some AMD specific variables for CBS, PBS and AOD. If locked, some AMD Variable Protection utilities like RU that modify variable at runtime do not work.
  • Page 149 5-4-1 RAS Parameter Description Enable/Disable the Periodic SMI for polling [MCA Threshold] error. RAS Periodic SMI Control Options available: Disabled, Enabled. Default setting is Enabled. SMI Threshold Configures the SMI Threshold value. SMI Scale Configures the SMI Scale value. Defines the unit of time scale. SMI Scale Unit Options available: millisecond, second, minute.
  • Page 150 Parameter Description PCIe Root Port UnCorr Err Initialize the PCIe AER Uncorrected Error Mask register of Root Port. Mask Reg PCIe Root Port UnCorr Err Initialize the PCIe AER Uncorrected Error Severity register of Root Port. Sev Reg PCIe Device Corr Err Mask Initialize the PCIe AER Corrected Error Mask register of PCIe device.
  • Page 151 5-4-2 Range Encryption Parameter Description Range_# Enter memory base address and limit address. Range_# Memory Base Start CXL Range Encryption Start to encrypt all memory ranges. BIOS Setup - 151 -...
  • Page 152 Chipset Setup Menu Chipset Setup menu displays submenu options for configuring the function of the North Bridge. Select a submenu item, then press <Enter> to access the related submenu screen. Parameter Description PCIe Compliance Mode Options available: Off, On. Default setting is Off. Enable/Disable program all VR on MB.
  • Page 153 5-5-1 North Bridge Parameter Description North Bridge Configuration Memory Information Total Memory Displays the total memory information. CPU 0 Information Press [Enter] to view information related to CPU 0 BIOS Setup - 153 -...
  • Page 154 Server Management Menu Parameter Description Enable/Disable FRB-2 timer (POST timer). FRB-2 Timer Default setting is Enabled. FRB-2 Timer Configures the FRB-2 Timer timeout. timeout Default setting is 20 minutes. Configures the FRB-2 Timer policy. FRB-2 Timer Policy Options available: Do Nothing, Reset, Power Down, Power Cycle. Default setting is Do Nothing.
  • Page 155 Parameter Description System Event Log Press [Enter] to configure advanced items. View FRU Press [Enter] to view the FRU information. Information BMC VLAN Press [Enter] to configure advanced items. configuration BMC network Press [Enter] to configure advanced items. configuration IPv6 BMC Network Press [Enter] to configure advanced items.
  • Page 156 5-6-1 System Event Log Parameter Description Enabling / Disabling Options Change this item to enable or disable all features of System Event SEL Components Logging during boot. Options available: Disabled, Enabled. Default setting is Enabled. Erasing Settings Choose options for erasing SEL. Erase SEL Options available: No/Yes, On next reset/Yes, On every reset.
  • Page 157 5-6-2 View FRU Information The FRU page is a simple display page for basic system ID information, as well as System product information. Items on this window are non-configurable. (Note) The model name will vary depends on the product you purchased BIOS Setup - 157 -...
  • Page 158 5-6-3 BMC VLAN Configuration Description Parameter BMC VLAN Configuration Select to configure BMC VLAN ID. The valid range is from 0 to 4094. When BMC VLAN ID set to 0, BMC VLAN ID will be disabled. Select to configure BMC VLAN Priority. The valid range is from 0 to 7. BMC VLAN Priority When BMC VLAN ID is set to 0, BMC VLAN Priority will not be selected.
  • Page 159 5-6-4 BMC Network Configuration Parameter Description BMC network configuration Lan Channel 1 Selects to configure LAN channel parameters statically or dynamically (DHCP). Do nothing option will not modify any BMC network parameters Configuration Address source during BIOS phase. Options available: Unspecified, Static, DynamicBmcDhcp. Default setting is DynamicBmcDhcp.
  • Page 160 5-6-5 IPv6 BMC Network Configuration Parameter Description IPv6 BMC network configuration IPv6 BMC Lan Channel 1 Enable/Disable IPv6 BMC LAN channel function. When this item is disabled, the system will not modify any BMC network during BIOS IPv6 BMC Lan Option phase.
  • Page 161 Security Menu The Security menu allows you to safeguard and protect the system from unauthorized use by setting up access passwords. There are two types of passwords that you can set: • Administrator Password Entering this password will allow the user to access and change all settings in the Setup Utility. •...
  • Page 162 5-7-1 Secure Boot The Secure Boot feature is applicable if supported by your Operating System. If your Operating System is not supporting Secure Boot, the system will hang when starting the Operating System. Parameter Description System Mode Displays if the system is in User mode or Setup mode. Enable/ Disable the Secure Boot function.
  • Page 163 Parameter Description Press [Enter] to configure advanced items. Please note that this item is configurable when Secure Boot Mode is set to Custom. Factory Key Provision Š – Allows to provision factory default Secure Boot keys when system is in Setup Mode.
  • Page 164 Boot Menu The Boot menu allows you to set the drive priority during system boot-up. BIOS setup will display an error message if the legacy drive(s) specified is not bootable. Parameter Description Boot Configuration Number of seconds to wait for setup activation key. 65535 (0xFFFF) Setup Prompt Timeout means indefinite waiting.
  • Page 165 Parameter Description FIXED BOOT ORDER Priorities Press [Enter] to configure the boot priority. By default, the server searches for boot devices in the following sequence: Hard drive. Boot Option #1 / #2 / #3 / #4 / #5 CD-COM/DVD drive. USB device.
  • Page 166 Save & Exit Menu The Save & Exit menu displays the various options to quit from the BIOS setup. Highlight any of the exit options then press <Enter>. Parameter Description Save Options Saves changes made and closes the BIOS setup. Save Changes and Exit Options available: Yes, No.
  • Page 167 5-10 BIOS Recovery The system has an embedded recovery technique. In the event that the BIOS becomes corrupt the boot block can be used to restore the BIOS to a working state. To restore your BIOS, please follow the instructions listed below: Recovery Instruction: 1.
  • Page 168 5-11 BIOS POST Beep code (AMI standard) 5-11-1 PEI Beep Codes # of Beeps Description Memory not Installed. Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available...
