Vivo V2419 Quick Start Manual

V2419 V2419
Quick Start Guide Quick Start Guide
Hızlı Başlangıç Kitapçığı Hızlı Başlangıç Kitapçığı
Version: V1.0 5131049 FXXX
Welcome to vivo
Please read this Quick Start Guide before using your phone, and
keep it for future reference.
This Quick Start Guide tells you how to set up your phone and use
its key features. For more detailed instructions, turn on your
phone, and then go to Settings > About phone > Customer
service > Manual. You can also learn more useful information on
vivo's official website.
For legal information, go to Settings > About phone > Legal
information.
The features and images shown in this guide are for reference
only. They may differ from the actual product.
It is recommended that the device be charged for at least 30
minutes before turning it on for the first time.
SAR Value
0.75 W/kg (Head)
CE SAR
0.95 W/kg (Body)
Product Technical Specifications
Product name Mobile phone
Product model V2419
Front: 5 MP
Camera
Rear: 50 MP + 0.08 MP
Battery 5500 mAh (3.89V) (TYP)
×
Dimensions 165.75 76.10
Screen 16.96 cm (6.68") 1608
Optimum operating temperature is 0°C to 35°C and optimum
storage temperature is -20°C to 45°C. Extreme heat or cold
may damage your device or accessories.
Product Standard Accessories
Phone × 1 Eject tool × 1
Charger × 1 Warranty card × 1
USB cable × 1 Quick start guide × 1
Phone case × 1
Frequency Bands and Power
1. Frequency bands in which the radio equipment operates:
some bands may not be available in all countries or regions.
Please contact the local operators for more details.
2. Maximum radio-frequency power transmitted in the frequency
bands in which the radio equipment operates: the maximum
power for all bands is less than the highest limit value specified
in the related Harmonized Standard. The frequency bands and
transmitting power (radiated and/or conducted) nominal limits
applicable to this radio equipment are as follows:
GSM 900:35dBm
GSM 1800:32dBm
WCDMA B1/B8:25.7dBm
LTE B1/B3/B7/B8/B20/B28/B38/B40/B41:25dBm
Bluetooth 2.4GHz:20dBm
Wi-Fi 2.4GHz:20dBm
Wi-Fi 5G:
5150-5250MHz:23dBm
5250-5350MHz:20dBm
5470-5725MHz:20dBm
5725-5850MHz:13.97dBm
×
8.10 mm
×
720
