Page 1 User reference guide Daikin room air conditioner ATXF60F2V1B ATXF71F2V1B...
Page 2 8.1.4 Symptom: A whistling sound is heard ......................8.1.5 Symptom: A clicking sound during operation or idle time is heard ............. 8.1.6 Symptom: A clapping sound is heard ......................User reference guide ATXF-F Daikin room air conditioner 4P513685-13J – 2024.09...
Page 3 Symptom: The units can give off odours....................... 8.1.9 Symptom: The outdoor fan rotates while the air conditioner is not in operation........Solving problems based on error codes ........................9 Disposal 10 Glossary ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 4 User reference guide: Detailed step-by-step instructions and background information for basic and advanced usage Format: Digital files on https://www.daikin.eu. Use the search function find your model. Latest revisions of the supplied documentation may be available on the regional Daikin website or via your installer.
Page 5 For more information, see the installer and user reference guide. The unit contains rotating parts. Be careful when servicing or inspecting the unit. Symbols used in the documentation: ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 6 Example: " 1–3 Figure title" means "Figure 3 in chapter 1". Indicates a table title or a reference to it. Example: " 1–3 Table title" means "Table 3 in chapter 1". ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 7 Do NOT place any objects containing water on the unit. CAUTION ▪ Do NOT place any objects or equipment on top of the unit. ▪ Do NOT sit, climb or stand on the unit. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 8 10 cm. CAUTION Do NOT insert fingers, rods or other objects into the air inlet or outlet. When the fan is rotating at high speed, it will cause injury. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 9 CAUTION Do NOT operate the system when using a room fumigation-type insecticide. Chemicals could collect in the unit, and endanger the health of people who are hypersensitive to chemicals. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 10 If damaged, the unit may fall and result in injury. CAUTION Do NOT touch the heat exchanger fins. These fins are sharp and could result in cutting injuries. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 11 Stop operation and shut OFF the power if anything unusual occurs (burning smells etc.). Leaving the unit running under such circumstances may cause breakage, electrical shock or fire. Contact your dealer. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 12 INFORMATION The following figures are examples and may NOT completely match your system layout. a Air inlet b Air outlet c Flap (horizontal blade) ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 13 Curtains. Make sure that curtains or other objects do NOT block the signal between the unit and the wireless remote control. NOTICE ▪ Do NOT drop the wireless remote control. ▪ Do NOT let the wireless remote control get wet. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 14 Operation mode = Automatic Operation mode = Drying Operation mode = Heating Operation mode = Cooling Operation mode = Fan only Powerful operation is active Econo operation is active Operation is active ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 15 Result: When the indoor unit receives a signal from the wireless remote control, you will hear a sound: Sound Description Beep-beep Operation starts. Beep Setting changes. Long beep Operation stops. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 16 1 Choose a place where the signals reach the unit. 2 Attach the holder with screws to the wall or a similar location. 3 Hang the wireless remote control on the holder. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 17 4.4 To turn on the power supply 1 Turn the circuit breaker on. Result: The flap of the indoor unit will open and close to set the reference position. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 18 To adjust the airflow direction (swing or fixed Airflow direction position). To adjust the amount of air blown into the Airflow rate room. To run more quietly. Advanced features ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 19 In that case, the system automatically switches to defrosting operation to remove the frost. During defrosting operation, hot air is NOT blown from the indoor unit. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 20 5 airflow rate levels, from " " to " " Automatic airflow rate operation Indoor unit quiet operation. When the airflow rate is set to " ", the noise from the unit will be reduced. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 21 Flap range in fan only operation 5.5.1 To adjust the airflow direction 1 To use auto swing, press Result: will appear on the LCD. Result: The flap (horizontal blade) will begin to swing. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 22 Note: Comfort airflow operation is NOT available in Fan only mode. 2 Press to stop. Result: The flap will return to the position from before the Comfort airflow mode; disappears from the LCD. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 23 This function is useful for cases in which attention should be paid to ensure a circuit breaker will not trip when the product runs alongside other appliances. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 24 Use this feature if the unit is operating and you want to stop operation after a certain time. 1 Press to start. Result: is displayed on the LCD and the timer lamp lights up. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 25 For details on specifications, setting methods, FAQ, troubleshooting tips, visit app.daikineurope.com. The customer is responsible for providing: ▪ Smartphone or tablet with minimum supported version of Android or iOS, specified on app.daikineurope.com. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 26 2 Follow the directions on the screen to install the ONECTA app. INFORMATION Scan the QR code to download and install the ONECTA app on your mobile phone or tablet: ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 27 Adjust the air flow direction to avoid cool air from gathering on the floor or warm air against the ceiling. (Up during cooling or dry operation to the ceiling and down during heating operation.) ▪ Avoid direct air flow to room inhabitants. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 28 Energy saving and optimum operation ▪ Operate the system within the recommended temperature range (26~28°C for cooling and 20~24°C for heating) to save energy. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 29 (e.g. open flames, an operating gas appliance, or an operating electric heater). The room size shall be as specified in the General safety precaution. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 30 Contact your dealer. 1 Clean with a soft cloth. If it is difficult to remove stains, use water or a neutral detergent. 7.4 To clean the front panel ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 31 2 Pull out the air filters. 3 Wash the air filters with water or clean them with a vacuum cleaner. 4 Soak in lukewarm water for about 10 to 15 minutes. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 32 Maintenance costs shall be borne by the customer. In certain operating conditions the inside of the unit may get dirty after several seasons of use. This results in poor performance. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 33 ▪ The air conditioner may stop operating after sudden large voltage fluctuations to protect the system. It automatically resumes operation after about 3 minutes. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 34 After checking all the items above, if it is impossible to fix the problem yourself, contact your installer and state the symptoms, the complete model name of the unit (with manufacturing number if possible) and the installation date. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 35 30 seconds for system protection. ▪ While the air conditioner is not in operation. When the outdoor temperature is very high, the outdoor fan starts to rotate for system protection. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 36 Indoor unit PCB abnormality Freeze-up protection or high-pressure control Fan motor (DC motor) abnormality Indoor heat exchanger thermistor abnormality Room temperature thermistor abnormality Outdoor unit Error code Description 4-way valve abnormality ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 37 Discharge pipe thermistor abnormality Outdoor heat exchanger thermistor abnormality Electrical parts heat error Radiation fin temperature rise Inverter instantaneous overcurrent (DC) Radiation fin thermistor abnormality Compressor internal temperature error ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 38 Do NOT try to dismantle the system yourself: dismantling of the system, treatment of the refrigerant, oil and other parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. ATXF-F User reference guide Daikin room air conditioner 4P513685-13J – 2024.09...
Page 39 Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with the product according to the instructions in the accompanying documentation.
Page 40 4P513685-13J 2024.09...
