A1000 Hardware Guide
16 days ago · Updated
Follow
Instructions
Please read the following instructions carefully before setting up the Aurender Music Player.
Be careful not to drop the device to avoid internal damage.
Do not disassemble the device.
Keep magnetic materials away from Aurender to prevent any damage to data.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Aurender A1000
Summary of Contents for Aurender A1000
- Page 1 Aurender > > Latest Articles Search Articles in this section A1000 Hardware Guide 16 days ago · Updated Follow Instructions Please read the following instructions carefully before setting up the Aurender Music Player. Be careful not to drop the device to avoid internal damage. Do not disassemble the device. Keep magnetic materials away from Aurender to prevent any damage to data.
- Page 2 Unplug power cord during severe lightning storms or when unused for a long period of time. Unplug the device from the outlet only after completely turning off the unit. Always turn the power off before connecting or disconnecting any cables. Please note that hard drives can fail break down. It is important to backup your music collection periodically to a separate memory device. In the event of drive failure, Aurender is not responsible for any loss of data. The drive manufacturer will only replace faulty drives under warranty and will not compensate for any loss of data. Positioning Place your device on a flat, horizontal, and stable surface.
- Page 3 1. ON/OFF/Standby Pressing the illuminated power button will power the unit on and off. To power the A1000 on from standby, press the button once, so the Aurender display shows "Aurender A1000". If the A1000 is powered on, enter Standby mode by pressing the front panel button once, and the unit will turn off with a display message that says "shutting down, please wait".
- Page 4 the playlist is selected, press button 9 again to start playback. Once the playlist is selected, buttons 8 and 10 can be used to select songs within the selected playlist. 8. Play Previous button Press to skip to the previous track. 9.
- Page 5 5. Digital Audio Output - Coaxial SPDIF (RCA) 6. Digital Audio Input - Coaxial SPDIF (RCA) 7. Digital Audio Input - Optical SPDIF 8. TV ARC Audio Input 9. USB Audio Input 10. 1Gbps LAN port 11. 12V Trigger Output 12.
- Page 6 1. Power ON/OFF 2. MUTE 3. Play Previous 4. Play / Pause 5. Play Next 6. Volume Up 7. Volume Down 8. Display Menu...
- Page 7 9. Input — Aurender (SSD/HDD) 10. Output — Analog 11. Output — Digital 12. Input — Google Cast 13. Input — BT 14. Input — USB 15. Input — Optical 16. Input — Coaxial 17. Input — TV ARC ...
- Page 8 PCM. 4. A1000 will now be operated from your TV via CEC commands from TV. This will allow you to use you TV-remote to adjust volume of the A1000 and also the A1000 will power ON and OFF together with your TV.
- Page 9 The LCD will show “pairing request” message. 4. Please turn on BT on your phone and search for “A1000”, then select it. 5. It will show “connecting” on LCD when trying to connect and show “connected” when done.
- Page 10 Streaming audio playback Google Cast playback: 1. Make sure your playback device is on the same network as your A1000. 2. From any Google Cast supported App, you can find the Google Cast symbol, if it is on the same network as your A1000 system.
- Page 11 Power Supply Full Linear Toroidal Quad-core 2.0Ghz CPU (ARM Coretex-A55) 4GB DRAM Library Storage Capacity 1x 2.5” SSD for System & Cache 32G eMMC for System, 120GB NVMe for Cache Data USB Ports 1x for external storage Software Suite Aurender Conductor...
- Page 12 Ethernet Port 100/1000 (Gigabit) Power Consumption Play (15W), Peak (20W), Standby (1.4W) 1x ARC-in for TV ARC port 12V Trigger 1x for external equipment Audio Specifications Analog Outputs RCA (Unbalanced) DAC Chipset AKM4490REQ Dual Mono Analog Outputs Supported Up To 32-bit / 768 KHz, DSD512(Native) Format Digital Outputs COAX RCA, USB external DAC Support...
- Page 13 D/A-omvandlare och andra enheter. Was this article helpful? 2 out of 2 found this helpful Have more questions? Submit a request Return to top Recently viewed articles N150 Hardware Guide Related articles Aurender Hardware Manual Aurender Quick Start Guide...
- Page 14 SSD/HDD Recommendations & Installation Guide Setting up a NAS server shared folder for use with Aurender Conductor What is the proper way to shut down my Aurender? Comments 0 comments Article is closed for comments. Aurender Powered by Zendesk...
