LENCO XBB-050 Manual

2.1 multimedia subwoofer system

SET UP INSTRUCTIONS

Do not insert the AC power plug into the wall outlet until all

connections are made.

1. Connect the satellite link cables with the signal output port at

the back board of the Subwoofer.

2. Insert one end of the signal input cable into the "output"

port of audio player, then connect another end with "input"

port at the back of the subwoofer cabinet.

3. Plug the connector for power.

All stereo information is heard from the satellite speakers.

The subwoofer contains no stereo information and sound is non-

directional. As a result, the subwoofer does not necessarily have

to be placed in any particular relationship to the satellites.

Placing the subwoofer on the floor close to a wall or corner of a

room provides maximum bass efficiency.

Table of Contents

Do you have a question about the XBB-050 and is the answer not in the manual?

Page 1 SET UP INSTRUCTIONS Do not insert the AC power plug into the wall outlet until all connections are made. 1. Connect the satellite link cables with the signal output port at the back board of the Subwoofer. 2. Insert one end of the signal input cable into the “output” port of audio player, then connect another end with “input”...
Page 2 2.1 multimedia subwoofer system DESCRIPTION Welcome to the extraordinary world of LENCO high fidelity sound, The XBB-050 is an amplified speaker system featuring a subwoofer for extended low frequency response. The system is especially designed for multimedia computer near field monitoring.
Page 3 FEATURES HIGHLIGHT UNIQUE AMPLIFIER CIRCUIT DESIGN • Ensure crisp, clear and full-bodied audio with extended reflec tive bass PORTED SUBWOOFER • Feel the exceptional low frequency bass from a 4”front–firing, long-throw woofer with a ferrite magnet set in a solidly-built wooden cabinetHIGH PERFORMANCE 3”...
Page 4 SPECIFICATIONS Output Power(RMS) : 15W+5Wx2 Frequency response : 30Hz-18kHz Function : Bass, Treble, Volume,Mp3&Auxinput Input Sensitivity : >10k Ohms Input Impedance : 4 Ohm S/N. Ratio : ? 75dB Satellite speaker : 3”(full range) Subwoofer speaker : 4”long-throw woofer Power supply : AC220V-240V/50Hz SAFETY INSTRUCTIONS Location...
