INDOOR UNIT
INDOOR UNIT
SERVICE MANUAL
Models
NAXWMT09A111AA
NAXWMT12A111AA
NAXWMT09A111AB
NAXWMT12A111AB
NAXWMT09A111AA
NAXWMT09A111AB
Revision C:
• Remote controller P.C. board has been added.
(7-2.)
OBHA820 REVISED EDITION-B is void.
Outdoor unit service manual
NAXSMT•A111AA Series (OBHA821)
CONTENTS
1. TECHNICAL CHANGES· ··································· 2
2. PART NAMES AND FUNCTIONS ····················· 3
3. SPECIFICATION ················································ 4
4. OUTLINES AND DIMENSIONS ························· 6
5. WIRING DIAGRAM ············································ 7
6. REFRIGERANT SYSTEM DIAGRAM ··············· 8
7. SERVICE FUNCTIONS ······································ 9
8. MICROPROCESSOR CONTROL ···················· 11
9. TROUBLESHOOTING ····································· 15
10. DISASSEMBLY INSTRUCTIONS ···················· 29
PARTS CATALOG (OBBA820)
No. OBHA820
REVISED EDITION-C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the American Standard NAXSMT-A111AA Series and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric American Standard NAXSMT-A111AA Series

Summary of Contents for Mitsubishi Electric American Standard NAXSMT-A111AA Series

  • Page 1: Table Of Contents

    Revision C: • Remote controller P.C. board has been added. (7-2.) INDOOR UNIT INDOOR UNIT OBHA820 REVISED EDITION-B is void. No. OBHA820 REVISED EDITION-C SERVICE MANUAL Models NAXWMT09A111AA NAXWMT12A111AA NAXWMT09A111AB NAXWMT12A111AB Outdoor unit service manual NAXSMT•A111AA Series (OBHA821) CONTENTS 1. TECHNICAL CHANGES· ··································· 2 2.
