Operating Instructions U2GT002 Distance Sensor Translation of the original operating instructions Subject to change without notice Available as PDF file only Version 1.1 www.wenglor.com...
Page 2
Status Message Function ............................23 6.3.2 Error Output Function............................. 23 6.3.3 Simulation Functions .............................. 24 6.4 Condition Monitoring/Process Data..........................25 6.4.1 Process Data In ............................... 25 6.4.2 Process Data Out..............................25 6.4.3 Events..................................25 Table of Contents | U2GT002 ‒ Distance Sensor...
Page 4
The safety precautions and warnings are laid out in accordance with the following principle: SIGNAL WORD Type and source of danger! Possible consequences in the event that the hazard is disregarded. à Measures for averting the hazard. 1 ‒ General | U2GT002 ‒ Distance Sensor...
Page 5
• wenglor assumes no liability for printing errors or other inaccuracies contained in these operating in- structions unless wenglor was verifiably aware of such errors at the point in time at which the operat- ing instructions were prepared.
Page 6
• All rights are reserved by wenglor. • Commercial reproduction or any other commercial use of the provided content and information, in particular graphics and images, is not permitted without previous written consent from wenglor. 1 ‒ General | U2GT002 ‒ Distance Sensor...
Page 7
• The product is not suitable for use in potentially explosive atmospheres. • The product may be used only with accessories supplied or approved by wenglor, or in combination with approved products. A list of approved accessories and combination products can be found at www.wenglor.com on the product detail page.
Page 8
Read the operating instructions carefully before using the product. Protect the sensor against contamination and mechanical influences. Approvals and Protection Class IND. CONT. EQ 72HL / E189727 For use in class 2 circuits 2 ‒ For Your Safety | U2GT002 ‒ Distance Sensor...
Page 9
M12 × 1; 4/5-pin Output Function Error Output PNP NO Analog Output Technical Safety Data MTTFd (EN ISO 13849-1) 1452.07 a * Referring to the switching distance, at least 2 mm. 3 ‒ Technical Data | U2GT002 ‒ Distance Sensor...
Page 10
Some technical data depend on the mode set. Depending on the setting, the following data are obtained: Reflex and Through-Beam Mode Filter value Switching frequency in Hz Response time in ms 10.0 3 ‒ Technical Data | U2GT002 ‒ Distance Sensor...
Page 11
Measurement of the sonic cone on a rod with a diameter of 25 mm Characteristic curves show the position of the center or the front edge of the measured object (Ø 25 mm rod) at the time of switching. 3 ‒ Technical Data | U2GT002 ‒ Distance Sensor...
Page 12
Standard sonic cone (front edge of the measured object) INFORMATION Please note that using multiple ultrasonic sensors can cause reciprocal influence. Housing Dimensions ① = transducer Dimensions specified in mm (1 mm = 0.03937 Inch) 3 ‒ Technical Data | U2GT002 ‒ Distance Sensor...
Page 13
③ = connector plug Complementary Products wenglor offers you the right connection and mounting technology as well as other accessories for your product. You can find this at www.wenglor.com on the product details page at the bottom. Scope of Delivery •...
Page 14
• Protect the product against exposure to direct sunlight. NOTICE Risk of property damage in case of improper storage! The product may be damaged. à Storage instructions must be complied with. 4 ‒ Transport and Storage | U2GT002 ‒ Distance Sensor...
Page 15
In contrast to the optical sensors, the U2GT sensor must not be clamped directly in the mounting device. The use of other mounting technology can lead to malfunction of the sensor, for which wenglor sensoric elektronische Geräte GmbH assumes no liability. The following also applies: •...
Page 16
Interfaces-Bus A(+)/B(–) Violet Emitted Light disengageable Grey Safety Output Signal Output White Magnet activation Pink Ethernet Gigabit bidirect. data line (A-D) Input confirmation Green/Yellow Encoder 0-pulse 0-0 (TTL) Contactor Monitoring 5 ‒ Installation and Electrical Connection | U2GT002 ‒ Distance Sensor...
Page 17
1. Shut down the machine. 2. Analyze and eliminate the cause of error with the aid of the diagnostics information. 3. If the error cannot be eliminated, please contact wenglor’s support department. 4. Do not operate in case of indeterminate malfunctioning.
Page 18
To this end, the sensor is connected to a suitable IO-Link master (see product detail page/complementary products). The interface protocol and the IODD can be found at www.wenglor.com in the download area for the respective product. For information on installing and connecting the wTeach2 software and its structure, as well as information on the general functions, see the wTeach2 operating instructions.
Page 19
Sensors in reflex and through-beam mode must not be combined! Differentiation between one and two layers of thin material such as paper or foil is possible in the through- beam operating mode. 6 ‒ Settings | U2GT002 ‒ Distance Sensor...
Page 20
(240 ms) Median filter of 31 measured values and bridging of 31 missing measured values (469 ms) Median filter of 44 measured values and bridging of 62 missing measured values (992 ms) NOTE! 6 ‒ Settings | U2GT002 ‒ Distance Sensor...
Page 21
Temperature values can be transmitted to the sensor at a resolution 23°C of 1°C for temperature compensation. Parameter is used if the ex- Temperature ternal temperature compensation is to work via the parameters. –30…+60°C NOTE! Regular update of external temperature data 6 ‒ Settings | U2GT002 ‒ Distance Sensor...
Page 22
The time intervals required for this are: Activated for 2 sec. = Teach-in A1 The time intervals required for this are: • Activated for 2 sec. = Teach-in A1/4 mA/0 V • Activated for 5 sec. = Teach-in A2/20 mA/10 V 6 ‒ Settings | U2GT002 ‒ Distance Sensor...
Page 23
The status messages are OR-linked so that the output is activated when one of the defined status messages is activated. Function Possible settings Default Error output See table “Status Messages” No signal, Object too close, Object too far, Short circuit, Device error 6 ‒ Settings | U2GT002 ‒ Distance Sensor...
Page 24
According to the measured value Measured value INFORMATION Output A1 is used for IO-Link communication in this function and cannot be simulated. Simulation mode ends automatically as soon as the power supply is interrupted. 6 ‒ Settings | U2GT002 ‒ Distance Sensor...
Page 25
The following events are supported: Name Event code Type Specification Device error – unknown error 0x1000 Error IO-Link Short circuit – check installation 0x7710 Error IO-Link Supply voltage too low – check tolerances 0x5111 Warning IO-Link 6 ‒ Settings | U2GT002 ‒ Distance Sensor...
Page 26
For information on installing and connecting the wTeach2 software and its structure, as well as information on the general functions, see the wTeach2 operating instructions. They can be found online in the down- load area at www.wenglor.com under order number DNNF005. 7 ‒ wTeach2 Configuration Software | U2GT002 ‒ Distance Sensor...
Page 27
Cleaning and inspection of the plug connections at regular intervals are advisable. Do not clean the sensor with solvents or cleaning agents that could damage the product. The product must be protected against contamination during initial start-up. 8 ‒ Maintenance Instructions | U2GT002 ‒ Distance Sensor...
Page 28
Proper Disposal wenglor sensoric GmbH does not accept the return of unusable or irreparable products. Respectively valid national waste disposal regulations apply to product disposal. 9 ‒ Proper Disposal | U2GT002 ‒ Distance Sensor...
Page 29
Declarations of Conformity Declarations of conformity can be found on our website at www.wenglor.com in the product’s separate download area. 10 ‒ Declarations of Conformity | U2GT002 ‒ Distance Sensor...
