L70/17...L100/11
Model: E23
Assembly and Operating Instructions
en
Sun sail drive
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
2010 301 003 0b 27/02/2024
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
info@becker-antriebe.com
www.becker-antriebe.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Becker L80-11-E23
Summary of Contents for Becker L80-11-E23
- Page 1 Assembly and Operating Instructions Sun sail drive Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 2010 301 003 0b 27/02/2024 Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany info@becker-antriebe.com www.becker-antriebe.com...
- Page 2 Table of contents General .................................... 3 Warranty ..................................... 3 Safety instructions ................................ 4 Instructions for the user.............................. 4 Instructions for installation and commissioning........................ 4 Intended use .................................. 6 Assembling and disassembling the plug-in connecting cable.................... 6 Assembly .................................... 7 Setting the limit positions with the switches on the drive head .................... 9 Deleting the limit positions with the switches ........................
- Page 3 General These tubular drives are high-quality products with the following features: • Optimised for sun sail applications • Installation without stops is possible (from extended point to retracted point) • Tensile load is optimally adapted to the mechanical requirements of the sun protection system •...
- Page 4 Safety instructions The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury. Instructions for the user General information • The drive must be disconnected from its power source during cleaning and maintenance and when re- placing parts.
- Page 5 • If the drive is used for shading solutions in a specially marked area (e.g., escape routes, hazard zones, safety areas), compliance with all applicable regulations and standards must be ensured. • Once the drive has been installed, the fitter must mark the used tubular drive in the “Technical data” chapter and make a note of the installation position.
- Page 6 Intended use The type of tubular drive described in these instructions is intended solely for sun sails. It may only be used in networked systems if all the individual drives are exactly synchronised and reach the upper limit position at the same time. Using the drive for other pur- poses or for purposes beyond the above, e.g.
- Page 7 Assembly Assembling the drive Attention To connect the drive to the driven part, solely mechanical accessory components made by the drive manufacturer from the current product catalogue may be used. Prior to mounting, the fitter must ensure that the masonry and the system being motorised are sufficiently robust (drive torque plus weight of the shading solution).
- Page 8 Assembling and disassembling the drive adapter with screw connection Mounting the drive in the tube For profile shafts: In the case of some drive adapters, tolerances of the groove widths in different barrels can be offset by rotating the drive adapter into a different groove recess. These groove recesses have different sizes and allow the drive to fit exactly.
- Page 9 Setting the limit positions with the switches on the drive head Intelligent installation management Completion of installation following automatic setting of limit position "Stop" Next time the “stop” limit position is travelled to, this position will be provisionally saved as the limit position. Once the limit position has been detected at this position 3 times in a row without any problems, it will be definitively saved.
- Page 10 Deleting the limit positions with the switches Deleting individual limit positions It is only possible to delete an individual limit position if the extended point to retracted point was programmed with the switches. Any additional functions that have been set are retained.
- Page 11 Adjusting the limit positions with a rotary switch or a locking button Intelligent installation management Completion of installation following automatic setting of limit position "Stop" Next time the “stop” limit position is travelled to, this position will be provisionally saved as the limit position. Once the limit position has been detected at this position 3 times in a row without any problems, it will be definitively saved.
- Page 12 Setting the limit positions using the programming unit Intelligent installation management Completion of installation following automatic setting of limit position "Stop" Next time the “stop” limit position is travelled to, this position will be provisionally saved as the limit position. Once the limit position has been detected at this position 3 times in a row without any problems, it will be definitively saved.
- Page 13 Deleting the limit positions using the programming unit Connect the wires of the tubular drive to those of the same colour in the programming unit and switch on the power supply. Please pause for 1 sec after the last drive command before beginning the deletion se- quence.
- Page 14 Deleting both limit positions Any additional functions that may have been set are deleted at the same time, or are reset to the factory default settings. Open/close the shading solution to a point between the limit positions. Press the programming button and keep it pressed. Then press down the travel button and keep it pressed.
- Page 15 Deactivating the fabric tensioning function To deactivate it, move to the fabric tensioning limit position. Press the programming button for approx. 5 seconds. ▻ Confirmation is provided by a shift. ► The fabric tensioning function is now deactivated. Information for the electrician Tubular drives with electronic limit switching can be connected in parallel.
- Page 16 Technical data dia. 58 Tubular drive L70-17 L80-11 L100-11 Model Type C PS X3 Rated torque [Nm] Output speed [rpm] Limit switch range 64 revolutions Supply voltage 230 V AC / 50 Hz Connected load [W] Rated current consumption [A] 1.90 1.10 1.40 Operating mode S2 4 min S2 8 min.
- Page 17 Sample wiring diagram Controlling one/several drive(s) via a single switch/button 17 - en...
- Page 18 Declaration of conformity For UK-Markets: The Declaration of Conformity can be provided upon request from Becker Motors Ltd., or can be downloaded on www.beckermo- tors.co.uk. 18 - en...
