POLOCOOL Portable Room Air Conditioner
Operation & Installation Manual
MODEL
PN46CWF
REFRIGERANT
R290
by

Advertisement

loading
Need help?

Need help?

Do you have a question about the PN46CWF and is the answer not in the manual?

Questions and answers

Related Manuals for Polocool PN46CWF

Summary of Contents for Polocool PN46CWF

  • Page 1 MODEL REFRIGERANT PN46CWF R290 POLOCOOL Portable Room Air Conditioner Operation & Installation Manual...
  • Page 2 Before proceeding with the operation of your new POLOCOOL Portable Room Air Conditioner, please read this manual thoroughly and gain a full understanding of the requirements, features and operation of your new appliance. REFRIGERANT R290 Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 3 When to Call for Service ����������������������������������������������������������������������������������������������������������������������������������� 22 Installation Location ������������������������������������������������������������������������������������������������������������������������������������������������������������ 23 Duct Assembly �������������������������������������������������������������������������������������������������������������������������������������������������� 23 Window Installations ������������������������������������������������������������������������������������������������������������������������������������� 24 Condensate Drainage �������������������������������������������������������������������������������������������������������������������������������������� 25 Internal Condensate Tank ���������������������������������������������������������������������������������������������������������������������������� 25 Fixed Condensate Drainage Hose ��������������������������������������������������������������������������������������������������������������� 25 Warranty Contacts Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 4 DO NOT insert your fingers or rods into the air outlet. Take special care to warn children of these dangers. Keep the unit upright while transporting or while storing, for the compressor locates properly. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 5 Installation of damaged or incorrect appliances may contravene local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 6 The illustrations used in this manual are for explanatory purposes only and the shape of your indoor unit NOTE may vary slightly from that which is shown in this manual. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 7 If any hot work is to be conducted on the refrigeration equipment or any associated parts, appropriate fire extinguishing equipment shall be available to hand. Have a dry powder or CO fire extinguisher adjacent to the charging area. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 8 NOTE: The use of silicon sealant may inhibit the effectiveness of some types of leak detection equipment. Intrinsically safe components do not have to be isolated prior to working on them. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 9 OFN. The system shall be leak tested on completion of charging but prior to commissioning. A follow up leak test shall be carried out prior to leaving the site. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 10 The evacuation process shall be carried out prior to returning the compressor to the suppliers. Only electric heating to the compressor body shall be employed to accelerate this process. When oil is drained from a system, it shall be carried out safely. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 11 Dimensions - Packing (H x W x D) 880 x 499 x 459 Weight 35.9 Nominal Cooling Capacity 4600 Max. Input Current Max. Input Power 2000 Refrigerant Type R290 Refrigerant Volume Sound Power Level dB(A) Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 12 18. Condensate drain hose All the illustrations in this manual are for explanatory purposes only. Your appliance may be slightlydifferent. NOTE Be sure all accessories are removed from the packing before use. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 13 There are three basic operational modes available, these are COOL (chilled air operation), FAN (fan only operation) and DRY (chilled and dehumidified operation). Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 14 Press the Mode Selection button (6) until the DRY mode indicator is illuminated. The screen display will show “ ”. Press the ON/OFF button (7). Fan speed is on Auto when DRY mode. NOTE Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 15 Press the "TIMER" button (1) again or the ON/OFF button (7), This will cancel any timer settings, and the “ Timer” symbol will disappear from screen. Only one mode of operation is available at any time. NOTE Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 16 ” to regulate the temperature (the unit is 1°C) and set the time (the unit is 0.5h). The temperature ranges from 18° to 32°, and the time ranges from 0.5h to 24h. “MODE” selection button Selects the operation mode: COOL, DRY, FAN, HEAT and SMART (Auto). Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 17 The SLEEP function maintains the room at optimum temperature without excessive fluctuations in either temperature or humidity with silent operation. Fan speed is always at Low, while room temperature and humidity vary gradually to ensure the most comfort. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 18 See Figure 4 above. • Press the button again or the button. This will cancel any timer settings, and the symbol will disappear from screen. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 19 Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries. Donotdisposeofbatteriesinfire.Batteriesmayexplodeorleak. If the remote control is not be used for a certain length of time, remove the batteries. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 20 WIRELESS OPERATION Refer to the Wireless Operation Manual for App connectivity and operation. A copy of the manual may be downloaded from the POLO COOL website: http://www.mypolo.com.au/downloads/ Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 21 To reattach the Lower Air Intake Grill ensure that all the tabs are properly seated and that the grill is securely clipped back into place. The power may now be reconnected. Failuretocleanthefiltersregularlycancauseexcessivecondensationtoformandreducethe appliancesefficiency.Ifyouneedreplacementfilters,pleasecontactRinnai. NOTE Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 22 There is a burning smell and a Turn off the air conditioner, and contact Rinnai. strange sound coming from the unit. When operated if a circuit breaker (safety, ground) is thrown or a fuse is blown. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 23 Screw one end of the Exhaust Duct (14) into the Duct to Unit Adaptor (13). On the other end of the Exhaust Duct (15) fix the Window Exhaust Duct Adaptor (16). Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 24 Once a suitable window has been chosen, fit the Adjustable Slider Kit (16) into the window areas and fix the length of the kit using the supplied metal locking screw. Metal locking screw Horizontal Window Installation Vertical Window Installation A - Minimum = 520mm A - Maximum = 1000mm Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 25 The point to which the condensate is to be drained MUST BE lower than the drainage outlet point. When using a drain tray option, ensure that the capacity of the tray is greater than that of the NOTE condensate being produced. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 26 Examples of Residential & Light Commercial Applications include, homes, offices, hotels, apartments, nursing homes, hospitals, health care premises, shopping centres, and retail stores. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 27 2.9 Where a Product or failed component is replaced under warranty, the time remaining on the original Product warranty period will continue to apply and the replacement product or part will be subject to the original warranty period only. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 28 Product or any of its parts and/or servicing the Product, are expressly excluded. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 29 The benefits provided by this Warranty are in addition to any other rights and remedies available to a consumer under the Australian Consumer Law and any other law which may apply to the goods and or services. Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 30 NOTES Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 31 NOTES Rinnai PN46CWF – Portable Room AC OIM – Issue 2...
  • Page 32 With our policy of continuous improvement, we reserve the right to change, or discontinue at any time, specifications or designs without notice. Rinnai PN46CWF – Portable Room AC OIM – Issue 2, October 2024 Rinnai Portable Room AC PN46CWF OIM Issue 1 – May 2024...
