Overview
Junction Box View
1. Camera Mounts
Points for installing the camera to the mounting bracket.
2. Mounting hinge
Point to hold the camera to the junction box while connecting the required cables.
3. Cable hooks
Points to wrap the excess cable length around.
4. Mounting holes
Holes for securing the mounting bracket to the mounting surface.
