Summary of Contents for AERMEC WLRC10
- Page 1 2 3 / 0 4 – 5 0 4 4 5 7 1 _ 0 5 T r a n s l a t i o n o f O r i g i n a l i n s t r u c t i o n s WLRC10 User manual REMOTE CONTROL w w w .
- Page 2 Dear customer,Thank you for choosing an Aermec product. It is the fruit of many years of experience and special design studies and has been made of the highest grade materials and with cutting edge technology.In addition, all our products bear the CE mark indicating that they meet the requirements of the European Machine Direc- tive regarding safety.
- Page 3 USER NOTICE — The wired controller is universal. — By pressing a key for a function that is not available, the unit will not change the operating status. — Never install the wired controller in the moist circumstance or expose it directly under the sunlight. —...
- Page 4 TABLE OF CONTENTS 1. User Notice .....................p. 3 2. Remote control ..................p. 5 User interface (buttons) ...............p. 5 User interface (display) .................p. 6 3. Functions available through the remote control .....p. 7 Switching the indoor unit ON and OFF ..........p. 7 Selecting an operating mode ............p. 7 Setting the operating setpoint ............p. 8 Setting the ventilation speed ............p. 8 Setting the motorised discharge fin (SWING) ......p. 9...
- Page 5 REMOTE CONTROL Attention: — Some of the buttons of the remote control are not used for the required air conditioner and are therefore not described in these instructions. Pressing of these keys will not affect the operation of the air conditioner. —...
- Page 6 2.2 USER INTERFACE (DISPLAY) Remote control display icons available 15 16 22 23 Table of contents Functions represented by the icons Indicates the AUTOMATIC mode is active Cooling mode Dry mode Indicates the VENTILATION mode is active Heating mode Indicates the SLEEP function is active Indicates the room air and setpoint temperatures are active on the display of the indoor unit Indicates which temperature is shown on the display of the indoor unit (internal temperature or setpoint temperature) Indicates the state of the SWING function (vertical)
- Page 7 FUNCTIONS AVAILABLE THROUGH THE REMOTE CONTROL 3.1 SWITCHING THE INDOOR UNIT ON AND OFF 3.2 SELECTING AN OPERATING MODE By pressing the button it is possible to switch the unit on or off. When off Sets the operating mode some information is still displayed on the remote control: the operating setpoint of the last operating mode used, and switch on timers programmed (ON) and any icons tied to the function active during the last switch on of the unit (enabling the display of the indoor unit, etc.) Once switched on the unit uses the settings selected...
- Page 8 3.3 SETTING THE OPERATING SETPOINT 3.4 SETTING THE VENTILATION SPEED All the operating modes (except the automatic one) require an room air tempera- Setting the ventilation speed ture value to control to: this is called the operating setpoint. If the unit is on (and the automatic mode is not selected), pressing the buttons allows decreasing or increasing the operating setpoint.
- Page 9 3.5 SETTING THE MOTORISED DISCHARGE FIN (SWING) 3.6 SETTING A SYSTEM TIME These units are equipped with an internal clock which can display the current time; Motorised discharge fin setting by pressing on the key the clock icon will start to flash (this flashing will last 5 seconds, after this if no key is pressed you automatically exit the time modification mode);...
- Page 10 3.7 SETTING OR CANCELLING A PROGRAMMED SWITCH 3.8 SETTING OR CANCELLING A PROGRAMMED SWITCH OFF (TIMER OFF) ON (TIMER ON) The units possess a timer used to program switching off by specifying the time The units possess a timer used to program switching on by specifying the time that that you want the unit to deactivate.
- Page 11 3.9 ACTIVATING / DEACTIVATING THE EXTENDED 3.10 VIEW THE AMBIENT AIR, SET POINT OR OUTDOOR AIR VENTILATION (IN THE DISPLAY OF THE INDOOR UNIT) During the operation in COOLING or DEHUMIDIFICATION mode the condensate Through the use of the remote control it is possible to display the room tempera- caused by the humidity in the air is formed on the heat exchanger within the unit.
- Page 12 3.11 ACTIVATING / DEACTIVATING THE TURBO FUNCTION 3.12 ACTIVATING / DEACTIVATING THE NIGHT-TIME COMFORT FUNCTION The unit allows the setting of three fan speeds during the various operating modes (except the automatic mode and the dehumidification mode). There is an addition- The night-time comfort function controls the air conditioner in an optimal way dur- al speed called TURBO.
- Page 13 3.13 ACTIVATING / DEACTIVATING THE INDOOR UNIT’S 3.15 SETTING THE UNIT OF MEASUREMENT DISPLAY The unit can display the temperature values in °C or in °F. To change the unit of The display on the indoor unit must be activated using the remote control; To ac- measurement simultaneously press the ;...
- Page 14 3.17 ACTIVATING / DEACTIVATING THE ENERGY SAVING 3.18 ACTIVATING / DEACTIVATING THE IFEEL FUNCTION FUNCTION The IFEEL function uses a temperature probe inside the infrared remote control in order to comunicate the room temperature to the unit and therefore it sets the The energy saving function makes it possible to reach the set temperature with operation of the unit, to give the maximum comfort to the user.
- Page 15 REPLACING THE REMOTE CONTROL’S 3.19 ACTIVATE OR DEACTIVATE THE WIFI FUNCTION (ONLY WITH THE WIFI ACCESSORY INSTALLED) BATTERIES The units can be controlled by a WIFI system, if the accessory WIFI has been To replace the batteries of the infra red remote control proceed as follows: planned;...
- Page 16 SCARICA L’ULTIMA VERSIONE: DOWNLOAD THE LATEST VERSION: TÉLÉCHARGER LA DERNIÈRE VERSION: http://www.aermec.com/qrcode.asp?q=13756 http://www.aermec.com/qrcode.asp?q=13757 http://www.aermec.com/qrcode.asp?q=13758 A e r m e c S . p . A . V i a R o m a , 9 9 6 - 3 7 0 4 0 B e v i l a c q u a ( V R ) - I t a l i a T e l .
