INSTALLER MANUAL

Wood Coocking Stove

KOOK 60 - KOOK 80- KOOK 90

SMART 60 - SMART 80 - FRIDA 80

Need help?

Do you have a question about the KOOK 60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cadel KOOK 60

Page 2 6.4 LEVELLING KOOK 60 ..........15 6.5 LEVELLING KOOK 80 - KOOK 90 - SMART 60 - SMART ................15 6.6 ASSEMBLY OF DOOR HINGED TO LEFT KOOK 60 ..16 6.7 ELECTRIC CONNECTION .........18 6.8 REMOVING THE STAINLESS STEEL PLINTH (KOOK 80 - KOOK 90 - SMART 60 - SMART 80) ........18...
Page 3 MANUAL SIMBOLOGY USER AUTHORISED TECHNICIAN (ONLY to interpret or the Stove-manufacturer or the Authorized Technician of Technical Assistance Service approved by the Stove-manufacturer) SPECIALIZED STOVE-REPAIRER CAUTION: READ CAREFULLY THE NOTE CAUTION: DANGER OR IRREVERSIBLE DAMAGE POSSIBILITY • The icons with the stylized figures indicates whom the subject dealt in the paragraph is addressed to (between the User and/ or the Authorized Technician and/or the Specialized Stove-repairer).
Page 4 STOVE HANDLING Both whether the stove is packed or not it is necessary to observe the following instructions for handling and transporting the stove from its sale point to its installation point and for any future movements: • The stove must be handled with idoneous means paying attention to the existing safety regulations; •...
Page 5 SMOKE DUCT (SMOKE FITTING) The smoke duct is the pipe that connects the appliance to the flue. This smoke fitting must comply in particular with the following requirements: • comply with product standard EN 1856-2; • its cross-section must be of constant diameter and no less than that of the appliance outlet, from the firebox outlet up to the connection in the flue;...
Page 6 • The chimney flue must be provided CE in accordance with EN 1443 regulation. Please find attached an example of label: Fig. 3 - Example of label CHIMNEY POT The chimneypot, meaning the end part of the flue, must meet the following characteristics: •...
Page 7 COMBUSTION AIR AIR INLET It is mandatory to provide an adequate external air inlet that supplies the combustion air required for the product to work properly. The flow of air between the outside and the installation room can take place with a free air inlet or by channelling the air directly to the outside (***).
Page 8 EXAMPLES OF CORRECT INSTALLATION Fig. 8 - Example 1 LEGEND Fig. 8 Insulating material Exhaust stub pipe Inspection plug Minimum safety distance = 0,5 mt Damper • Chimney flue installation Ø150 mm with an enlarged drilling for pipe transit. Fig. 9 - Example 2 LEGEND Fig.
Page 9 LEGEND Fig. 9 Damper • Old chimney flue with an inserted pipe of minimum Ø150 mm and with an external door which enables the chimney cleaning. Fig. 10 - Example 3 LEGEND Fig. 10 Insulating material Inspection plug Minimum safety distance = 0,5 mt Damper •...
Page 10 The sealed stove in a sealed installation is compatible with the presence of forced ventilation or premises that might have negative pressure with respect to the outside. OVERALL DIMENSIONS Fig. 11 - Overall dimensions: Kook 60 KOOK60 - KOOK80 - KOOK90 - SMART60 - SMART80 - FRIDA 80...
Page 11 Please find here following the table with the measures for each stove model (see Fig. 11): POS. KOOK 60 60 cm 85/90 cm 60 cm 30 cm 12,7 cm 30 cm 75,5/80,5 cm Exhaust fumes d.14 cm 30 cm 41/46 cm Hole combustion air inlet d.8 cm...
Page 12 POS. KOOK 80 - 80V - 80S - 80 VS - FRIDA 80 KOOK 90 72,8 cm 72,8 cm Scarico fumi d.14 cm Scarico fumi d.14 cm 15,9 cm 25,9 cm 32 cm 32 cm Presa aria comburente d.8 cm Presa aria comburente d.8 cm Fig.
Page 13 Fig. 14 - Overall dimensions: SMART 80 Please find here following the table with the measures for each stove model (see Fig. 14): POS. SMART 80 - SMART 80V - SMART 80S - SMART 80VS 79,5 cm 86 cm 60 cm 15 cm 16,5 cm 13,5 cm...
Page 14 Fig. 15 - General installation LEGEND Fig. 15 Stove Distance from side panels under the hot plate = 2.5 mm (**except SMART 60 = 20 mm) Thickness of rear flammable panel insulating material = 40 mm + Insulating material 1000 mm 50 mm 300 mm Fig.
Page 15 • You can also adjust the plinth profile: loosen the screws, lower the profile and then lock the screws at the desired height (see Fig. 18). Fig. 17 - Feet adjustment: Kook 60 Fig. 18 - Plinth profile adjustment: Kook 60 You can also adjust the wood drawer plinth, so that it is aligned with the side plinths. Proceed as follows: •...
Page 16 ASSEMBLY OF DOOR HINGED TO LEFT KOOK 60 The hinges on the fire door can be moved to the other side if required.
Page 17 Fig. 28 - Remove the support Fig. 29 - Fix the support • Unscrew the door pin support (see Fig. 28) and screw it on the left side of the cooker (see Fig. 29). Fig. 30 - Remove the handle Fig.
Page 18 Fig. 34 - Fix the door locking screw Fig. 35 - Hook the door on again • Fasten the door stop (see Fig. 34) and hook the door in its new position (see Fig. 35). • NB: the screws removed from the one side must all be fastened on the other side (there must not be any empty holes in the stove).
Page 19 Fig. 36 - Undo the screw Fig. 37 - Plinth removal If you wish you can remove the front plinth and replace it with that fitted on the kitchen units. • Undo the screws above the front plinth (see Fig. 38). •...
Page 20 Fig. 42 - Feet assembly 1 Fig. 43 - Feet assembly 2 Fig. 44 - Feet assembly 3 6.11 MOUNTING THE FLUE GAS EXHAUST STUB PIPE All stoves have the possibility to discharge the flue gas at the top or at the back. •...
Page 21 • In case of replacement of damaged pieces please ask for the original spare part at the Autorized Retailer. FUME PASSAGES CLEANING KOOK 60 Clean on a yearly basis (and if necessary every month) the inside of the oven flue gas pass.
Page 22 Fig. 51 - Locking lever Fig. 52 - Oven door removal • Open the oven door and rotate the locking lever (see Fig. 51). • Remove the complete oven door (see Fig. 52). • Then clean as indicated in FUME PASSAGES CLEANING KOOK 90 - KOOK 80 - SMART 80 (KOOK 87) a pag. 22. FUME PASSAGES CLEANING KOOK 90 - KOOK 80 - SMART 80 (KOOK 87) Clean on a yearly basis (and if necessary every month) the inside of the oven flue gas pass.
Page 23 FANS CLEANING For models with ventilation, clean every the year the room fan from ash or dust which can cause a blade unbalance and a greater noise. To clean the fan, proceed as follows: • Remove the plug from the mains. •...
Page 24 For an efficient oven light it is necessary to execute a periodical light protection cleaning. HEART BREAK KOOK 60 Probable cast iron or refractory heart break are due to an excessive overheating caused by too much fuel or by too much combu- stion air.
Page 25 Fig. 64 - Remove the screws Fig. 65 - Remove the profile • Remove the screws (see Fig. 64). • Remove the profile and replace the damaged refractory material (see Fig. 65). Use exclusively original spare parts. 7.10 HEART BREAK (KOOK 80 - 90) (SMART 60 - 80) (FRIDA 80) VALID FROM 2021 Probable cast iron or refractory heart break are due to an excessive overheating caused by too much fuel or by too much combu- stion air.
Page 26 • Remove the cast iron/ceramic glass top. • Undo the screw of the profile that locks the refractory material in place (see Fig. 66). • Remove the steel profile (see Fig. 67). • Remove the broken refractory material and replace it (see Fig. 68 Fig. 69 Fig. 70). Use exclusively original spare parts.
Page 27 IN CASE OF ANOMALY PROBLEM SOLVING In case of doubts regarding the use of the stove, please contact ALWAYS the Authorized Technician on order to avoi irreparable damages! PROBLEM CAUSE SOLUTION INTERVENTO Use small and well dried wood logs during ignition, before bigger Too large wood wood logs.
Page 28 PROBLEM CAUSE SOLUTION INTERVENTO Lack of chimney Open the registers completely. (If the problem persists, contact and draught expert stove repairer who will check the chimney flue efficiency). Too humid wood Use well seasoned wood The glass blackens excessively Too slow combustion Open air registers in order to increase the fire and fume output temperature.
Page 29 FEATURES DESCRIPTION KOOK 60 KOOK 80 KOOK 90 KOOK 80 S WIDTH 59,5 cm 79,5 cm 89,5 cm 79,5 cm DEPTH 60 cm 60 cm 60 cm 60 cm HEIGHT 85-90 cm 86 cm 86 cm 86 cm WEIGHT 121,6 kg...
Page 30 DESCRIPTION KOOK 60 V KOOK 80 V KOOK 90 V KOOK 80 VS WIDTH 59,5 cm 79,5 cm 89,5 cm 79,5 cm DEPTH 60 cm 60 cm 60 cm 60 cm HEIGHT 85-90 cm 86 cm 86 cm 86 cm...
Page 31 DESCRIPTION FRIDA 80 KOOK 80S KOOK 80VS WIDTH 79,5 cm 79,5 cm 79,5 cm DEPTH 60 cm 60 cm 60 cm HEIGHT 86 cm 86 cm 86 cm WEIGHT 152 kg 138.2 kg 138.2 kg NOMINAL HEAT OUTPUT (Max) 7,5 kW 7,5 kW 7,5 kW THERMAL EFFICIENCY (Max)
Page 32 DESCRIPTION SMART 60 SMART 60S SMART 80 SMART 80S WIDTH 59,5 cm 59,5 cm 79,5 cm 79,5 cm DEPTH 60 cm 60 cm 60 cm 60 cm HEIGHT 86 cm 86 cm 86 cm 86 cm WEIGHT 123 kg 123 kg 152 kg 152 kg NOMINAL HEAT OUTPUT (Max)
Page 33 DESCRIPTION SMART 60V SMART 60VS SMART 80V SMART 80VS WIDTH 59,5 cm 59,5 cm 79,5 cm 79,5 cm DEPTH 60 cm 60 cm 60 cm 60 cm HEIGHT 86 cm 86 cm 86 cm 86 cm WEIGHT 123 kg 123 kg 152 kg 152 kg NOMINAL HEAT OUTPUT (Max)
Page 34 NOTE...
Page 35 NOTE...
Page 36 Rev. 00- 2024 CADEL srl www.cadelsrl.com 31025 S. Lucia di Piave - TV www.free-point.it Via Martiri della Libertà, 74 - Italy Tel. +39 0438 1520200...
