TTM313 User Manual
Copyright Information
Copyright © 2024 by SHENZHEN SMARTSAFE TECH CO.,LTD. All rights reserved. No
part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical, photocopying, recording or otherwise,
without the prior written permission of SMARTSAFE.
Neither SMARTSAFE nor its affiliates shall be liable to the purchaser of this unit or third
parties for damages, losses, costs, or expenses incurred by purchaser or third parties as
a result of: Accident, misuse, or abuse of this unit, or unauthorized modifications, repairs,
or alterations to this unit, or failure to strictly comply with SMARTSAFE operating and
maintenance instructions. SMARTSAFE shall not be liable for any damages or problems
arising from the use of any options or any consumable products other than those
designated as Original SMARTSAFE Products or SMARTSAFE Approved Products by
SMARTSAFE.
All information, specifications and illustrations in this manual are based on the latest
information available at the time of printing. SMARTSAFE reserves the right to make
changes at any time without prior written or oral notice.
Trademark Information
is a registered trademark of SHENZHEN SMARTSAFE TECH CO.,LTD. in
China and other countries. All other SMARTSAFE trademarks, service marks, domain
names, logos, and company names referred to in this manual are either trademarks,
registered trademarks, service marks, domain names, logos, company names of
SMARTSAFE or are otherwise the property of SMARTSAFE or its affiliates. In countries
where any of the SMARTSAFE trademarks, service marks, domain names, logos and
company names are not registered, SMARTSAFE claims other rights associated with
unregistered trademarks, service marks, domain names, logos, and company names.
Other products or company names referred to in this manual may be trademarks of their
respective owners. You may not use any trademark, service mark, domain name, logo,
or company name of SMARTSAFE or any third party without permission from the owner
of the applicable trademark, service mark, domain name, logo, or company name. You
may contact SMARTSAFE by visiting the website at www.newsmartsafe.com, or writing
to SHENZHEN SMARTSAFE TECH CO.,LTD., 3310, Building 11, Tianan Cloud Park,
Bantian Street, Longgang District, Shenzhen, Guangdong, China, to request written
permission to use Materials on this manual for purposes or for all other questions
relating to this manual.
Safety Warnings
Please read all safety warnings and operating information carefully. To avoid personal
injury, property loss or accidental damage to the product caused by improper operation,
please pay attention to the following points when using this product:
I

Advertisement

loading
Need help?

Need help?

Do you have a question about the TTM313 and is the answer not in the manual?

Questions and answers

Summary of Contents for Smartsafe Tech TTM313

  • Page 1 TTM313 User Manual Copyright Information Copyright © 2024 by SHENZHEN SMARTSAFE TECH CO.,LTD. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of SMARTSAFE.
  • Page 2 TTM313 User Manual  Always conduct vehicle detection in a safe environment.  Never operate the detection device while driving a vehicle to avoid distraction and thus cause a car accident.  Before starting the engine, the handbrake should be pulled, especially the front wheel...
  • Page 3 Table of Contents 1. Packing List ....................1 2. Product Introduction ................2 2.1 Overview ....................2 2.2 TTM313 Main Unit ................. 2 2.3 Technical Parameters ................3 3. First Use ..................... 4 3.1 Charging ....................4 3.2 Power On ....................4 3.3 Main Interface ..................
  • Page 4 TTM313 User Manual 9.1 Report Management ................21 9.2 Report Viewing and Sharing ............... 21 Warranty .......................23...
  • Page 5 TTM313 User Manual 1. Packing List The following product configuration list is for reference only. For details, please consult the local dealer or check the accompanying packing list. Name Picture for Reference Quantity Main unit Power Adaptor USB cable (Type-C)
  • Page 6 TTM313 User Manual 2. Product Introduction 2.1 Overview The TTM313 handheld tire tread detection equipment is a device developed by SmartSafe for detecting vehicle tire tread and analyzing wear conditions. The device supports two functional modes: full tread detection and single groove detection, accurately and quickly assessing tire wear conditions.
  • Page 7 TTM313 User Manual 2.3 Technical Parameters Parameter Item Parameter Description Processor RK3326-s Memory Storage Screen 3.97-inch LCD touch screen, resolution 480*800 Battery 5000mAh / 3.7V Measuring Camera 2 million pixels Photography Camera 8 million pixels Measurement Accuracy 0.1 mm Maximum Measurement Width 180 mm 2.4GHz/5GHz dual-band Wi-Fi...
  • Page 8 TTM313 User Manual 3. First Use 3.1 Charging Connect one end of the USB cable (Type-C) to the power adaptor and the other end to the Type-C charging port of the main unit, then plug the power adaptor into the power outlet to charge the main unit.
  • Page 9 TTM313 User Manual 3.3 Main Interface 3.4 Precautions The main interface of the TTM313  Avoid using the handheld tire main unit includes functional tread detection equipment in modules such as Full Tread, direct sunlight or other strong Single Tread, Report, Detection, light environments to prevent Calibration, and Settings.
  • Page 10 TTM313 User Manual 4. Full Tread from "outside → inside", and the values of each groove are displayed from "left → right", as The full tread can sequentially shown in the figure below: detect all tires of 4-tire or 6-tire...
  • Page 11 TTM313 User Manual of the detection equipment should be attached to the center of the corresponding tire tread, and care should be taken to avoid the laser line of the detection equipment being projected onto the secondary grooves. Refer to the diagram below for the correct and incorrect measurement methods.
  • Page 12 TTM313 User Manual 4.1.2 Single Groove Mode function module on the main interface to enter the operation Single groove mode supports prompt interface. independent detection of a single groove, allowing for the sequential acquisition of the depth of each individual tire groove.
  • Page 13 TTM313 User Manual 4. The system defaults to detecting 3. Click the button to enter the from the front left wheel of the more detection options interface, vehicle, but you can also where you can input tire status manually select any tire for (photo), production date/warranty detection.
  • Page 14 TTM313 User Manual detection, the scanning cursor pop-up will appear on the screen will automatically jump to the indicating measurement failed. next tire icon in a Please confirm that the magnetic counterclockwise direction. head of the detection equipment is in contact with the tire tread, and then press the function button again to re-measure.
  • Page 15 TTM313 User Manual 5. Single Tread Single tread supports the selection of a single tire for detection on 4- tire or 6-tire passenger vehicles. It supports two detection methods: all tread mode and single groove mode. 5.1 Measurement Methods and Readings...
  • Page 16 TTM313 User Manual 1. When conducting detection in all tread mode, the magnetic head of the detection equipment should be attached to the center of the corresponding tire tread, and care should be taken to avoid the laser line of the...
  • Page 17 TTM313 User Manual 5.1.2 Single Groove Mode function module on the main interface to enter the operation Single groove mode supports prompt interface. independent detection of a single groove, allowing for the sequential acquisition of the depth of each individual tire groove.
  • Page 18 TTM313 User Manual 4. Click the tire name under the tire 3. Click the button to enter the icon to select any tire for more detection options interface, detection. After selecting the tire, where you can input tire status attach the magnetic head of the...
  • Page 19 TTM313 User Manual end the detection and click the button to view and save the single tire detection report. For more details on viewing and managing detection reports, refer Chapter 9 Report. If a detection failure occurs, a pop-up will appear on the screen indicating measurement failed.
  • Page 20 TTM313 User Manual 6. Detection Switch the display unit of the detection results to Unit metric or imperial Click "Detection" on the main according to the interface to enter the following requirements. interface: Parameter Set safety values and settings danger values as needed.
  • Page 21 TTM313 User Manual 7. Calibration This function is used to perform calibration of the detection equipment. 1. Click "Calibration" on the main interface, and follow the on- screen prompts to correctly place the detection equipment on the calibrator, ensuring that the...
  • Page 22 TTM313 User Manual 8. Settings Click "Settings" on the main interface to enter the following interface. Swipe up on the screen to see more setting options. In the settings interface, click "Network Connection", then click the WLAN button, and the user can select the network they want to connect to.
  • Page 23 TTM313 User Manual 8.3 Brightness Adjustment 8.5 Sleep Mode This function is used to adjust This function is used to set the screen brightness. waiting time for starting the system sleep mode. 8.4 One-click Upgrade 8.6 Automatic Power Off This function is used for equipment version upgrade.
  • Page 24 TTM313 User Manual off. detection equipment. Restoring the factory settings will delete all personal data. Please proceed with caution. 8.7 Language Settings This function is used to switch system language. 8.9 About This function is used to view equipment model, product serial...
  • Page 25 TTM313 User Manual 9. Report This functional module is used to view and share detection reports. Click "Report" on the main interface to view the list of historical detection reports. 9.2 Report Viewing and Sharing Clicking a single detection report in the detection report list will open the details of that report.
  • Page 26 TTM313 User Manual Click the button at the bottom Display Description of the screen, then enter the order Item number and click the button to Displays the tread data upload the report and generate a for each tire, including QR code.
  • Page 27 TTM313 User Manual Warranty This WARRANTY applies only to customers and dealers who have purchased SmartSafe products through normal procedures. Within one year from the date of delivery, SmartSafe Company shall guarantee the defects of its electronic products caused by materials or processes. Damage of the equipment or components caused by abuse, unauthorized modification, use for purposes other than the design of the product, or failure to operate in the way specified in the instruction shall not be covered by this warranty.
