Philips ArenaVision BVP425 Mounting Instructions page 12

Installation of drivers boxes on cabinet
ORIENTATION
Each driver box in the
cabinet has to be in
vertical position
TEMPERATURES
MAXIMUM Relative Humidity:
95% -> Storage & Transport
90% -> Operating (no condensation allowed)
A temperature sensor must be installed inside the cabinet between two driver boxes.
The temperature measured by the sensor has to be lower than 45°C.
We recommend a cabinet protected against solar action.
An active cooling can be added in the cabinet to guarantee a maximum temperature of
Cables
45°C all along the year
DISTANCES
The distances between driver box-
es or wall have to be higher than:
Item Distance
1, 3 Min 50mm
2 Min 80mm
4 Min 150mm
5 Min 200mm
12/16
4
3
5
1
2
