- Page 1 RELAISKARTE (Plug-In Modul) Schnellstartanleitung Stand: 10/2024 RELAY CARD (plug-in module) Quick start guide Stand: 10/2024 SCHEDA RELÈ (Modulo plug-in) Guida rapida Stand: 10/2024 www.online-usv.de • www.online-ups.com • www.online-ups.it...
-
Page 2: Table Of Contents
Inhaltsverzeichnis Produktübersicht ............................. 4 Produktbeschreibung ............................. 4 Installation ................................ 4 Spezifikation ..............................5 Interne Schaltung, Öffner / Schließer ......................6 Anwendungsbeispiel ............................6 Kompatibilitätsliste ............................6 Impressum ................................13 Content Product overview ............................. 7 Product description ............................7 Installation ................................ 7 Specification ..............................8 Internal circuit, opener / closer ........................ - Page 3 Installazione ..............................10 Specifiche ................................ 11 Circuito interno, funzionamento NC / NA ....................12 Esempio di applicazione ..........................12 Elenco di compatibilità ..........................12 Sedi .................................... 13 Schnellstartanleitung Relaiskarte Seite 3 •...
-
Page 4: Produktübersicht
1. Entfernen Sie die Schrauben an der Abdeckung des Slots an der USV-Anlage. 2. Schieben Sie die AS400-/Relaiskarte in den Slot. Die USV sollte während der Installation ausgeschaltet sein. Die Karte ist jedoch „HOT PLUG“-fähig, kann also auch während des USV-Betriebes installiert werden. -
Page 5: Spezifikation
4 Spezifikation Tabelle 1: Spannungen und Ströme Diode Sperrspannung Durchlassstrom 50 mA Durchlassstrom, max. Relais Spannungs-Kontaktbelastbarkeit 24 V DC Strom-Kontaktbelastbarkeit 1 A DC Tabelle 2: PIN-Beschreibung Funktion Bemerkung Nicht verwendet Bypass GND/-Pol für Remote Shutdown Remote Shutdown: Liegt hier im Batteriebetrieb eine Spannung von Eingang 6 –... -
Page 6: Interne Schaltung, Öffner / Schließer
Positionieren Sie den vorinstallierten Jumper bei Bedarf gemäß Tabelle 3 neu. Abbildung 3: Jumperstellung Öffner (AO) Abbildung 4: Jumperstellung Schließer (AC) 6 Anwendungsbeispiel Kompatibilitätsliste Die AS400-/Relaiskarte ist kompatibel zu den fol- genden USV-Modellen der ONLINE USV-Systeme AG: ZINTO-Serie, Modell 2017: Art.-Nr. Z800, Z1000, Z1500, Z2000, Z3000 XANTO-Serie, Modell 2017: Art.-Nr. X700/R, X1000/R, X1500/R, X2000/R, X3000/R,... -
Page 7: Product Overview
1. Remove the screws on the cover of the slot on the UPS system. 2. Push the AS400 / relay card into the slot. The UPS should be switched off during installation. However, the card is “HOT PLUG”-compatible, meaning it can also be installed while the UPS is running. -
Page 8: Specification
4 Specification Table 1: Voltages and currents Diode Cut-off voltage On-state current 50 mA On-state current, max. Relay Voltage contact rating 24 V DC Current contact rating 1 A DC Table 2: PIN description Function Remark Not used Bypass mode GND / pole for remote shutdown Remote shutdown: If there is a voltage of 6 –... -
Page 9: Internal Circuit, Opener / Closer
If necessary, reposition the pre-installed jumpers as set out in Table 3. Figure 3: Jumper position for opener (AO) Figure 4: Jumper position for closer (AC) 6 Example application Compatibility list The AS400 / relay card is compatible with the follo- wing UPS models from ONLINE UPS systems AG: ZINTO series, model 2017: Art.no. Z800, Z1000, Z1500, Z2000, Z3000 XANTO series, model 2017: Art. -
Page 10: Panoramica Del Prodotto
Descrizione del prodotto La scheda AS400 / relè è un modulo per lo scambio di segnali a potenziale zero tra un UPS (ZIN-TO, XANTO) e un sistema di controllo. È possibile ricevere segnali / stati operativi dal sistema UPS o inviare un comando di shutdown al sistema UPS. -
Page 11: Specifiche
4 Specifiche Tabelle 1: Spannungen und Ströme Diodo Tensione inversa Corrente diretta 50 mA Corrente diretta max. Relè Caricabilità dei contatti (tensione) 24 V CC Caricabilità dei contatti (corrente) 1 A CC Tabella 2: Descrizione dei pin Funzione Osservazione Non utilizzato Bypass Polo GND / - per shutdown in remoto Shutdown remoto: se quando l'UPS è... -
Page 12: Circuito Interno, Funzionamento Nc / Na
Figura 4: Config. ponticello Normalmente chiuso (AO) per Normalmente aperto (AC) 6 Esempio di applicazione Elenco di compatibilità La scheda AS400 / relè è compatibile con i seguenti modelli UPS di ONLINE USV-Systeme AG: Serie ZINTO, modello 2017: cod art. Z800, Z1000, Z1500, Z2000, Z3000 Serie XANTO, modello 2017: cod art. X700/R, X1000/R, X1500/R, X2000/R, X3000/R, X6000, X10000, X1000031 Guida rapida Scheda relè... -
Page 13: Impressum
All rights reserved. Unauthorised reproduction in part or in whole is not permitted without consent. Il contenuto è soggetto al diritto d'autore Copyright © 2024 della ONLINE USV-Systeme AG. Tutti i diritti riservati. Riproduzione per intero o parziale non consentita senza autorizzazione. - Page 14 www.online-usv.de • www.online-ups.com • www.online-ups.it...
