Page 1 StarLine A90 EN version mock manual User manual Safety Measures for Operating the Security System General Description Technical Specifications Light and sound indication Controlling the system using a remote key Operating Modes Device Registration Emergency disarming Changing the emergency disarm code...
Page 2 User manual...
Page 3 User manual Safety Measures for Operating the Security System Please read carefully! Before operating the security system, carefully read this manual and pay special attention to Screenshot 2023-11-28 163123.png sections marked with an exclamation point . To Image not found or type unknown determine if this security system is suitable for your vehicle, refer to the vehicle manufacturer's requirements and operating instructions.
Page 4 Store a spare battery in the vehicle in its original packaging. The full electronic version of the instruction manual is available on the website help.starline.ru. Mandatory Safety Measures When Using the Engine Start Function: It is important to remember that a vehicle is a potential hazard. Section 12.8 of the traffic rules states: "The driver may leave their place or leave the vehicle if necessary measures are taken to...
Page 5 Before activating the remote or automatic engine start function: Ensure the vehicle is in good condition. Ensure there is sufficient fuel, oil, coolant, etc. Set the heater, air conditioner, defroster, and other accessories to the required levels. Set the cabin air circulation to improve heating or cooling efficiency. Safety Measures When Charging Your Vehicle's Battery Keep in mind that any battery charging process involves supplying a voltage higher than the...
Page 6 This necessity arises because without measuring devices, you cannot determine the condition, state, or reason for battery discharge (such as internal short circuits or breaks). Connecting a charging device to a faulty battery poses a risk of damaging the vehicle's electronic equipment and security system due to increased voltage.
Page 7: General Description
User manual General Description The StarLine A90, Starline A60 security-telematics complexes (hereinafter referred to as the complex) are designed to protect motor vehicles from theft and armed attacks. The complex is controlled using a remote key. Key Features Built-in audible notifier for convenient owner notification.
Page 9: Technical Specifications
Remote Key Control Range Up to 1500 meters Notification Range on Remote Key Up to 2000 meters Interfaces 1 Universal StarLine Bus 1 USB 23 Configurable Channels which can be used as: 11 Outputs (0.2 A) 1 Output (2 A)
Page 10: Light And Sound Indication
User manual Light and sound indication The security complex provides various options for indicating modes such as "Disarmed", "Armed", and "Alarm": Hidden: Light and sound indicators are disabled. Silent: Only light indicators are enabled. Sound: Only sound indicators are enabled. Full: Both light and sound indicators are enabled.
Page 11: Led Indicator
icon-short.png icon-short.png Warning level alarm Image not found or type unknown Image not found or type unknown icon-short.png icon-short.png Image not found or type unknown Image not found or type unknown icon-short.png icon-short.png Image not found or type unknown Image not found or type unknown icon-short.png Image not found or type unknown icon-short.png...
Page 12 User manual Controlling the system using a remote key Remote Keys The complex's memory can be programmed with two types of remote keys: 1. Remote key with LCD (liquid crystal display). image.png image.png Image not found or type unknown Image not found or type unknown The remote key with LCD uses a AAA 1.5 V battery.
Page 13: Security Zones
Включен автоматический запуск по будильнику.jpg Image not found or type unknown Automatic start by alarm is activated Включен автоматический периодический запуск.jpg Image not found or type unknown Automatic periodic start is activated Включен автоматический запуск по температуре.png Image not found or type unknown Automatic start by temperature is activated Включен...
Page 14: Additional Information
Сработал дополнительный датчик 2.png Image not found or type unknown Additional sensor 2 activated Сработал датчик наклона.png Tilt sensor activated Image not found or type unknown Сработал датчик движения.png Image not found or type unknown Motion sensor activated Сработал предупредительный уровень датчика удара.png Warning level of shock sensor activated Image not found or type unknown Сработал...
Page 15 брелок E96.png Image not found or type unknown Numbering of buttons on the additional remote key: dop-brelok.png Image not found or type unknown The following terms of button press duration are used in this manual: Short Press Pressing a single button (or two buttons simultaneously) for less than 1.5 seconds.
Page 16 icon-short-1.png Image not found or type unknown icon-short-1.png icon-short-1.png Image not found or type unknown Image not found or type unknown Arm without confirmation sound signals icon-short-1.png Image not found or type unknown icon-short-2.png Disarm Image not found or type unknown icon-short-2.png icon-short-2.png Image not found or type unknown...
Page 17: Cursor Menu
icon-service-mode.png Image not found or type unknown Activate/deactivate service mode or cursor menu Activate/deactivate "Hands-Free" mode cursor menu icon-short-double-2-3.png Activate/deactivate button lock Image not found or type unknown icon-long-double-1-4.png icon-note-2.png Image not found or type unknown Image not found or type unknown Activate/deactivate "Button Autolock"...
Page 18: Settings Menu
Transitions between menu items, changing parameters, and exiting the menu will be confirmed by a melodic sound signal. Descriptions and management of settings are provided in the table. Icon Parameter Description Setting Step Режим «Свободные руки».png Image not found or type unknown "...
Page 19 icon-short-2.png or icon-short-3.png , respectively. The longer the press, the more units Image not found or type unknown Image not found or type unknown the value changes. Changing the parameter and exiting the menu will be confirmed by a melodic sound signal, transitions between menu items —...
Page 20 0 — no sound, 10 — maximum volume level. Setting Motion Sensor Sensitivity To adjust the motion sensor sensitivity level, select the sixth item in the settings menu. Then, using buttons icon-short-2.png and icon-short-3.png , set the desired value from 0 to 30. Image not found or type unknown Image not found or type unknown 0 —...
Page 21 Setting Tag Detection Zone Range To set the range of the tag detection zone, select the eleventh item in the settings menu. Then, using buttons icon-short-2.png and icon-short-3.png , set the desired value from 1 to 8. Image not found or type unknown Image not found or type unknown 1 —...
Page 22 Adjusting Sound Profile Settings: Enter the menu by long press of the button icon-long-3.png icon-note-2.png . After Image not found or type unknown Image not found or type unknown entering, the current profile settings will be displayed. Adjusting Command Confirmation Volume image.png image.png ...
Page 23 2 — Selected signal type volume level; 3 — Selected Sound Profile Number; 4 — Vibration Signal: Сработал тревожный уровень датчика удара.png — on, Image not found or type unknown Датчик удара отключен.png — off. Image not found or type unknown Volume adjustment is done by short pressing the buttons icon-short-2.png Image not found or type unknown icon-short-3.png...
Page 24: Setting Time And Date
By default, the BR-1 theme is set You will automatically exit the menu after 10 seconds if no buttons on the remote key are pressed Automatic Button Lock Function When this function is activated, the remote key buttons are automatically locked after the backlight turns off.
Page 25: Operating Modes
User manual Operating Modes Security modes Armed Disarmed Antihijack Alarm Panic Additional modes Hands-Free Service mode Device registration Security modes provide protection for the vehicle against theft. Additional modes are intended for adding new devices ("Device Registration" mode), disabling security functions for vehicle servicing ("Service Mode"), and convenient system control ("Hands- Free"...
Page 26: Silent Arming
If the tag or remote key battery is dead, and there is no access to the starline.online personal account and StarLine mobile app, use emergency arming: 1. Press the service button or the transceiver button 3 times. 2. Turn on the ignition. Three sound signals will follow.
Page 27: Silent Disarming
Disarmed Mode Disarming can be performed in one of the following ways: Short press on button icon-short-2.png of the remote key; Image not found or type unknown Upon detection of the tag or touching the door handle sensor ("Hands-Free" mode) By pressing the tag button once in "Armed"...
Page 28 Enabling, disabling, and configuring the "Central Locking During Travel" function is performed by an installation specialist. Central Lock Unlocking During Travel Function This function is designed for automatically unlocking the central locking system during a trip based on one of the configurable conditions: When the ignition is turned off When the gear selector is shifted to the "Park"...
Page 29: Alarm Mode
By default, the "Keyless Entry System Lock" function is disabled. Contact an installation specialist to activate it. Alarm Mode The "Alarm" mode is activated when any of the zones in the "Armed" mode is breached. The system will trigger the siren and the hazard lights for 30 seconds and notify the owner via the remote key.
Page 30: Hands-Free Mode
The algorithm works as follows: One of the security zones is breached (doors, hood, or trunk); The motion sensor is triggered; After 30 seconds, the system starts searching for the tag/remote control; If the tag/remote control is not detected within 30 seconds, the system will activate warning signals about the upcoming engine blocking with the siren and hazard lights for 10 seconds;...
Page 31 By default, the tag's operating range is set to the maximum value. To change it, please contact an installation specialist. If the tag is lost from view while the doors, hood, or trunk are open, the system will notify about this event in one or more of the following ways: Siren notification about cancellation of transition to the "Armed"...
Page 32: Service Mode
Successful disabling of the "Hands-Free" mode for 1 security cycle will be confirmed by 1 audible signal. Service mode Service Mode is intended for temporarily disabling security functions and restricting access to system settings. It is recommended during service maintenance. Enabling Service Mode is only possible from the "Disarmed"...
Page 33: Immobilizer Mode
If authorization fails, the security system will switch to the "Alarm" mode. Immobilizer mode The Immobilizer Mode prevents movement without additional owner authorization. Upon disarming or turning off the ignition, the system will wait for authorization confirmation either by the presence of the key fob in the vicinity or by entering the owner's authorization code using the vehicle's standard buttons (e.g., multimedia or window control buttons) while the ignition is on.
Page 34: Engine Start
1. Engage the parking brake while the engine is running. 2. Remove the key from the ignition switch. The engine will continue to run. 3. Exit the vehicle, close the doors, trunk, and hood, and arm the security system. The engine will be stopped.
Page 35 been stopped. Engine Stop The engine stops if: long press of button 2 on the key fob is performed: icon-long-2.png Image not found or type unknown icon-note-1.png Image not found or type unknown The factory alarm system activation button is pressed three times within a 5-second interval (availability depends on the car model, consult your installation specialist).
Page 36: Manual Mode
Function «Engine starting preheater» The function allows for engine preheating before starting. The starting preheater can be controlled both in the manual and automatic mode. Manual mode In the manual mode the starting preheater is switched on/off by a command. The starting preheater can be switched on by sequentially pressing buttons 2 and 1 on the remote key: icon-long-2.png icon-note-1.png...
Page 37: Beach Mode
In "Beach Mode," there is no need for a tag or key fob to enable/disable the security system (they can be left inside the car). Owner authorization is achieved by entering the emergency disarm code by touching the door handle with a capacitive sensor StarLine ES-1 (optional). In this mode, the...
Page 38: Video Recorder Control
system does not respond to key fob commands. To activate "Beach Mode," follow these steps: 1. Switch the system to the "Disarmed" mode and turn off the ignition. 2. Press the service button three times and turn on the ignition. This will be followed by three audible signals confirming the activation of "Beach Mode." Turn off the ignition.
Page 39 Use this mode when parking in areas with a high risk of theft. In this mode the system will require owner authorization with the factory buttons each time the system is disarmed. This mode operates independently of the "Immobilizer mode" settings. To enable/disable the mode, follow these steps: 1.
Page 40: Device Registration
User manual Device Registration To register new remote keys, tags, smartphones, use the "Device Registration" mode. To prevent unauthorized registration of new accessories, entry to registration mode is permitted in Disarmed mode only. If Immobilizer mode enabled then authorization must be passed to fully disarm a system. Tags and smartphones shall be registered in one registration cycle.
Page 41 Registration of a smartphone: 1. Enable Bluetooth in the smartphone settings. 2. Select StarLine equipment from the list of available devices. 3. Enter the code "000000" (on the iOS platform, press the "Pair" button to enter the code). If multiple registered smartphones are simultaneously in the vicinity, the system will only work with the one that connects first.
Page 42 A previously recorded smartphone in the system's memory will be automatically removed after registering a new smartphone or tag. Make sure to remove the system from the list of paired Bluetooth devices on your smartphone. Exiting the device registration mode Exiting the "Device Registration"...
Page 43: Emergency Disarming
User manual Emergency disarming Use the emergency disarmament code provided on the owner's plastic card or PIN envelope in the following situations: Depleted battery in the tag or remote key. "Antihijack" mode is activated. PIN envelope pinEnvelope.jpg Image not found or type unknown Entering emergency disarm code via the service button To emergency disarm the system, follow these steps:...
Page 44 Entering emergency disarm code via the StarLine EC-1 Capacitive Sensor The emergency disarm code can be entered using the StarLine EC-1 capacitive sensor (installed optionally). To disarm the system, follow these steps: 1. Touch the door handle 3 times. A single sound signal will follow.
Page 45 User manual Changing the emergency disarm code To change the code, you need to know the current emergency disarm code. The initial emergency disarm code is indicated on the owner's plastic card or PIN envelope included in the delivery set. PIN envelope pinEnvelope.jpg Image not found or type unknown...
Page 46 8. Repeat steps 6...7 for the remaining code digits. 9. There will be 2 flashes of the service button LED and 2 sound signals, confirming the correct entry of the current code. 10. Turn on the ignition. Press the service button a number of times corresponding to the first digit of the new emergency disarm code.
Page 47 24. Turn on the ignition. 25. Press the service button 6 times. Turn off the ignition. 26. The service button will flash three times. 27. Press the service button 3 times. Turn off the ignition. 28. The service button will flash four times. 29.
Page 48 Refer to the list of supported car buttons on the can.starline.ru website. If there is no flash of the service button LED after pressing the car's built-in button, then the button is not supported in this car.
Page 49 11. Exiting the "Device Registration" mode will be confirmed by 2 flashes of the service button LED and 2 beep sounds, after which there will be signals corresponding to the total number of registered remote keys, BLE tags, and smartphones. Deleting the owner authorization code To delete the owner authorization code, follow these steps: 1.
Page 50 Installiation manual An installiation manual is available at the link(to do). The connection diagram is available in the current instructions on the ‘Connection Diagram’ page.
Page 51: Connection Diagram
Connection diagram...
Page 52 Software All descriptions of software versions for the main unit, remote keys, and tags are available at the link: Software(to do)
