Operating instructions
Compact disc harrow
Rubin 10 TF
Rubin 10 TF/400
Rubin 10 TF/500
Rubin 10 TF/600
Rubin 10 TF/700
70217215, 69210271, 69210272, 69210273, 69210274, 69210275, 69210276, 69210277, 69210278, 69210279, 69210280, 69210281, 69210282, 69210283, 69210284, 69210285,
69210286, 69210287, 69210288, 69210289, 69210290, 69210291, 69210292, 69210293, 69210294, 69210295, 69210296, 69210297, 69210298, 69210299, 69210300
BA 70217215 | 69210276 en_GB | Rev_ | 2024-04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rubin 10 TF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LEMKEN Rubin 10 TF

Summary of Contents for LEMKEN Rubin 10 TF

  • Page 1 Operating instructions Compact disc harrow Rubin 10 TF Rubin 10 TF/400 Rubin 10 TF/500 Rubin 10 TF/600 Rubin 10 TF/700 70217215, 69210271, 69210272, 69210273, 69210274, 69210275, 69210276, 69210277, 69210278, 69210279, 69210280, 69210281, 69210282, 69210283, 69210284, 69210285, 69210286, 69210287, 69210288, 69210289, 69210290, 69210291, 69210292, 69210293, 69210294, 69210295, 69210296, 69210297, 69210298, 69210299, 69210300...
  • Page 2 Pass these instructions to all users / owners. Original instructions © 2024 | This documentation is copyright protected. The copyright remains with LEMKEN GmbH & Co. KG, Weseler Straße 5, D-46519 Alpen. The texts, diagrams and drawings must not be duplicated, distributed or disclosed in any other way, either in...

  • Page 3: Table Of Contents

    Table of contents Table of contents About these instructions............Introduction.
  • Page 4 Table of contents Commissioning............. . . 34 Preparing an attachment.
  • Page 5 Table of contents Maintenance and repair work..........74 Maintaining the machine properly.
  • Page 6 LEMKEN overview of operating materials........

  • Page 7: About These Instructions

    Validity range These operating instructions describe operation of the machine after initial commissioning by the LEMKEN sales partner and hand‐ over to the operator. Prior to operation, initial commissioning and instruction in opera‐ tion, setting/adjustment and maintenance must have been carried out.

  • Page 8: Target Groups

    About these instructions Target groups Position of the type plate on the machine: Chapter 3 Design and description on page 21 ⮫  Explanation of the full type plate content: Appendix A Type plate variants on page 113 ⮫  Equipment variants The machines can be equipped differently at the factory.

  • Page 9: Applied Presentations

    About these instructions Applied presentations 1.3.1 Signal words and hazard statements Warning of personal injury The following signal words and hazard statements are used to label warning signs and to warn of residual risks: Signal word Meaning DANGER Indicates an immediate hazardous situa‐ tion that may result in serious injury or death.

  • Page 10: Symbols And Text Markings

    About these instructions Applied presentations 1.3.2 Symbols and text markings Symbol, text Meaning marking In front of and in texts Marking for routine maintenance tasks ● Activities that demand the help of service staff. Listing [1], Position numbers ‘Settings’ Example: Software element [OK] Example:...

  • Page 11: Further Applicable Documents

    For partially assembled or disassembled delivery: Mounting ■ instructions Latest versions of the LEMKEN docu‐ The latest versions of the LEMKEN documents can be found in the ments LEMKEN Online Information System (LEONIS). Users can access LEONIS via the QR code or the LEMKEN website.

  • Page 12: Safety

    Safety Machine limits Safety Machine limits Intended use The machine is used for soil cultivation on agricultural land. It may only be used in accordance with the recognised rules of good agricultural practice. The permitted working depth is limited to the cultivatable soil horizons.

  • Page 13: Requirements Of Operators, Users And Service Personnel

    Safety Hazardous area The machine and the area in the immediate vicinity of the machine is deemed a hazardous area. This includes the space over the entire width, length and height of the machine, as well as an additional safety distance of two metres to the machine. The hazardous area varies in the operating position and the trans‐...

  • Page 14: General Safety Information

    Safety General safety information Qualified specialists For the purposes of these instructions, qualified specialists are all persons who, on the basis of their professional training and experience, carry out the tasks assigned to them in a professional manner. Qualified specialists have knowledge of the relevant stand‐ ards and regulations, recognise possible hazards and avoid hazards independently.
  • Page 15 Safety Safety equipment Existing and fully functional safety devices protect against death or serious personal injury. Keep the labels legible and renew them, if necessary. Replace damaged safety devices. Install dismantled safety devices before commissioning. Move the safety devices to the protective position. In case of doubt whether all safety devices are properly installed and fully functional: Commission a specialist work‐...

  • Page 16: Safety Information On Hazardous Areas Of The Machine

    Safety Safety information on hazardous areas of the machine Hydraulic assembly The hydraulic assembly might be under high pressure. Hydraulic oil leaking under pressure can penetrate through the skin into the body. Injury to body parts, face, eyes and unprotected skin may result. The hydraulic assembly might be hot.
  • Page 17 Safety Dangerous situations may occur if several persons operate the machine functions at the same time. Observe the hazardous areas. Pay attention to other persons in the vicinity of the machine. Area between the tractor and When standing between the tractor and machine, there is a risk machine due to tractor movements or sudden machine movements.
  • Page 18 Safety Safety information on hazardous areas of the machine In addition, maintain a safety distance of 2 m from the machine. While driving on the field, observe the entire hazardous area. Stop if required. Folding range Fig. 2: Hazardous areas when folding the implement There should be NO persons present in the folding range.

  • Page 19: Safety Information On Structural Modifications

    Safety Safety information on structural modifications Structural modifications Structural modifications and extensions can impair the function‐ ality and operational safety of the machine. This may result in death or injuries. Auxiliary equipment and spare parts must comply with the manu‐ facturer's requirements.

  • Page 20: Driving Behaviour

    Safety Safety information on situations Behaviour during flashover of over‐ Flashovers cause high electrical voltages on the outside of the head lines tractor-machine combination. Large voltage differences occur on the ground around the tractor-machine combination. Large steps, lying down or supporting yourself on the ground may cause life- threatening electrical currents (step voltage).

  • Page 21: Design And Description

    Design and description Design and description Machine overview The machines can be equipped differently at the factory. − Standard components, special equipment or optional accessories are not marked sepa‐ rately. − Contents in this document may differ from the actual equipment of the machine. −...

  • Page 22: Appendix A Type Plate

    113 Machine safety 3.2.1 Position of the label Fig. 3: Rubin 10 TF - Overview of safety symbols, warning stickers and other symbols 3.2.2 Meaning of the labels This section explains the information and warning signs that have been affixed to the machine.
  • Page 23 Design and description Reading the operating instructions Incorrect use or operation of the machine can result in death or serious injury. Before commissioning: Read and observe the operating instructions. Follow the instructions for action. Turn off the engine A tractor with the engine running can cause unintentional move‐ ments.
  • Page 24 Design and description Machine safety Jack positioning points Positioning points for jack Lashing points Lashing points for fixing during transport Lifting points for fork-lift truck Lifting points for fork-lift truck Hydraulic equipment Connection overview of hydraulic hoses Control units Coupling Line Consumer Single...

  • Page 25: Safety Devices

    Design and description 3.2.3 Safety devices Lighting equipment and identification The marking and the lighting equipment increase safety while driving on the road. For public road traffic, the machine must be equipped with the following components in accordance with national regulations: Marking ■...
  • Page 26 Design and description Machine safety Warning board Depending on national regulations, a warning board may be required for slow-moving vehicles. Lateral safety guards In transport position, protective gratings offer protection against protruding outer edges. The protection extends to a height of 2 m (measured from the ground).
  • Page 27 Design and description Stand - headstock The wheel chocks are carried on the machine in the area of the lamp holder when the machine is mounted. Protection against unauthorised use The protection against unauthorised use ensures that only author‐ ised persons can attach the machine to a tractor. The following versions are available: for cross shafts for ball-shaped couplings...

  • Page 28: Safety Chain

    Design and description Headstock for drawbar eyes Safety chain For machines without a braking system, a safety chain may be required, depending on the national regulations. NOTICE − Use the safety chain only as a safety device. Headstock The headstock with top link pin and cross shaft  has been designed according to ISO 730.

  • Page 29: Hydraulic Drawbar

    The solo axle is only used to transport the implement and to insert and lift the implement when working in the field. Only fit small implements approved by LEMKEN (e.g. intercrop spreaders) to or on this implement version. Always observe the permissible technical data of the implement.
  • Page 30 Design and description Compressed air brake Overview Compressed air tank Drain valve Manoeuvring valve (double release valve) Park valve (double release valve) Brake force regulator Brake cylinder Guiding screw Guiding screw retainer Piston rod Brake lever BA 70217215 | 69210276 en_GB | Rev_ | 2024-04...

  • Page 31: Touch Wheels

    Design and description Touch wheels The touch wheels mounted on the outside of the frame stabilise the machine during soil cultivation. The touch wheels are used for sensing only. The working depth of the machine is guided at the front via the lifting hydraulics of the tractor or via the hydraulic drawbar and at the rear via the rollers.

  • Page 32: Concave Discs

    Design and description Concave discs Tool Description Rollers Ensure reconsolidation and additional crumbling of the soil. When the machine is lowered for working, the rollers bear the weight of the machine and ensure precise depth control. The permissible roller types are shown in the technical data. Chapter 12.12 Permissible roller types on page 103 ⮫ ...

  • Page 33: Depth Adjustment

    Design and description 3.13 3.11 Depth adjustment The working depth is set hydraulically. The depth adjustment is used to lower or raise the rollers. The further the rollers are lowered, the less the working depth. Raised rollers result in a greater working depth. During hydraulic depth adjustment, the hydraulic rams hold the rollers in the selected position.

  • Page 34: Commissioning

    Commissioning Preparing an attachment Commissioning Preparing an attachment 4.1.1 Checking suitability of the tractor WARNING Risk of accident due to unsuitable tractor If the tractor is not suitable for the machine, components of the machine may be overloaded and the tractor-machine combina‐ tion may not be steered safely.
  • Page 35 Commissioning Assembly group Requirement Check Hydraulic oil Chapter 12.8 ⮫  The hydraulic oils of the machine and the tractor are compatible. Operating materials on page 99 The axle loads and the required ballasting have been determined Axle loads and taken into account. Tyre load capacities The carrying capacity index of the tractor tyres is compatible with Chapter 12.9...

  • Page 36: Preparing Braking System

    Commissioning Preparing an attachment Assembly group Requirement Check Hydraulic oil Chapter 12.8 ⮫  The hydraulic oils of the machine and the tractor are compatible. Operating materials on page 99 Braking system Chapter 12.10 Com‐ The braking systems of the machine and the tractor are compat‐ ⮫ ...

  • Page 37: Attaching The Machine

    Commissioning Seal the opening in the brake cylinder with the protecting Insert the guiding screw into the retainer at the brake cylinder. Secure the guiding screw with a peg and nut. Attaching the machine DANGER Risk of accident due to deactivated brake cylinders For unloading and manoeuvring without a compressed air supply, parts of the braking system are deactivated when deliv‐...
  • Page 38 Commissioning Attaching the machine Attaching a machine with headstock Switch the rear lifting gear of the tractor to position control. Adjust the lifting rods to the same length, lock and secure them. Back the tractor straight up to the machine. ��...
  • Page 39 Commissioning 14. Fold in and secure the stand. �� The machine has been mounted. Attaching a machine with drawbar Move the tractor straight backwards up to roughly 30 cm in front of the machine. The drawbar eye  and the tractor drawbar  are arranged one in front of the other.
  • Page 40 Commissioning Attaching the machine Connect hydraulic hoses for the hydraulic drawbar to the tractor. Use the hydraulic drawbar to set the ball-shaped coupling approx. 5 cm higher than the hitch ball. Drive the tractor slowly backwards until the ball-shaped cou‐ pling (machine) is positioned above the hitch ball (tractor).
  • Page 41 Commissioning If the machine has a compressed air brake: Initially connect the yellow compressed air connection  ▶ to the tractor. Then connect the red compressed air connection  to the ▶ tractor. Prepare for driving. Preparing for driving on page 41 ⮫ ...

  • Page 42: Road Travel

    Road travel Preparing for road travel Road travel Information on road travel Laws on driving on public roads differ in many countries. Operators and users are responsible for adherence to applicable laws. Observe the following legal requirements: Dimensions ■ Weights ■...
  • Page 43 Road travel Checklist Outer concave discs Chapter 6.3.3 Adjusting the Swing in the outer concave discs. ⮫  ■ at machines with 7 m outer concave discs on page 57 working width Depth adjustment Machine without memory function of the Chapter 6.3.2 Carrying out ⮫ ...
  • Page 44 Road travel Preparing for road travel Mounting the lateral safety guards for transport WARNING Risk of injury due to concave discs or harrow tines Other road users may be injured by the concave discs or harrow tines. Always mount the safety guards before driving on public roads. WARNING Risk of injury from heavy parts falling down during the mounting process...

  • Page 45: Preparing The Lighting Equipment For Road Travel

    Road travel Push the safety guard  with its holder  into the respective device  �� The safety guard covers the cutting edge of the lowest concave disc  Hook the tensioning strap into the safety guard  Fasten the other end of the tensioning strap to the device  with the hook.
  • Page 46 Road travel Preparing the lighting equipment for road travel Check the tell-tale lights in the tractor. �� If the tell-tale light for the direction indicator on the tractor and the tell-tale light for the direction indicator on the machine flash, the lighting equipment has been con‐ nected correctly.

  • Page 47: Operation

    Operation Operation Basic operation 6.1.1 Folding the machine Information on synchronising the memory function Chapter 6.3.2 Carrying out depth adjustment ⮫  on page 54 Folding in Preconditions: NO overhead lines in the folding range ✓ NO persons in the folding range ✓...

  • Page 48: Folding Out

    Operation Basic operation Folding out Preconditions: NO overhead lines in the folding range ✓ NO persons in the folding range ✓ Tractor has stopped. ✓ Hydraulic assembly provides a volumetric flow of at least 40 l/ ✓ min. Ensure that the tractor-machine combination is standing on solid and level ground.
  • Page 49 Operation Pull the pin  of the edge bracket  upwards against the spring pressure. Swivel the edge bracket with the outer concave disc  to the front. Secure the edge bracket with the pin  of the limiting disc in the folded-in position. Secure the pin with the linch pin.

  • Page 50: Operate The Compressed Air Brake

    Operation Basic operation Swivel the edge bracket  with the outer concave disc  the rear. Pull the pin  of the edge bracket  upwards against the spring pressure. Secure the edge bracket  in the folded-out position with the pin  of the edge bracket. Lift the limiting disc ...

  • Page 51: Changing The Setup State

    Operation Information on rapid emergency If the brake lines are interrupted when the machine is pulled off the brake tractor, braking is initiated via the air in the supply tank. Operate the parking brake The parking brake is used by the user to secure the machine against rolling away.
  • Page 52 Operation Changing the setup state Mounting the weed harrow The weed harrow  must always be mounted on a trailing roller. Brackets  and U-bolts  are available for mounting. There is one harrow segment for each trailing roller segment. Fig. 10: Example image Position both U-bolts ...

  • Page 53: Adjusting The Machine

    Operation Adjusting the machine 6.3.1 Adjusting the draw point Three height positions (draw point positions) are available for adjusting the draw point. Draw point position Selection criteria Deep For tractors with crawler ■ trailer In case of excessive relief of ■...

  • Page 54: Carrying Out Depth Adjustment

    Operation Adjusting the machine 6.3.2 Carrying out depth adjustment The working depth of the machine can be adjusted variably and steplessly. NOTICE Material damage due to excessive working depth If the working depth is too great, the load placed on parts of the machine may be excessive.
  • Page 55 Operation The display offers a guide value. The working depth display may fluctuate while working due to actual oscillation. The adjusted maximum working depth is kept constant. Machine with headstock Lift the machine. Set shallowest working depth. �� Pointer for roller position to Position 1 Move the tractor-machine combination in the field to the operating position.
  • Page 56 Operation Adjusting the machine Undo the wing nuts  on the position display for the hydraulic drawbar. Adjust the pointer  to position 1 of the display. Fix the wing nuts  in this position. Depending on the wear of the concave discs, repeat calibration from time to time.

  • Page 57: Adjusting The Outer Concave Discs

    Operation Synchronising the depth adjustment Synchronise the depth adjustment daily before working in the field. Lift the machine. Move the depth adjustment from position  (flat) to posi‐ tion  (deep) and continue to hold the control unit for ten seconds. Move the depth adjustment from position  (deep) to posi‐...

  • Page 58: Adjust The Brake Force Regulator

    Operation Adjusting the machine 6.3.4 Adjust the brake force regulator The brake force regulator has seven adjustment positions. The adjustment positions not enabled for this machine are mechanically locked. Adjust the braking force with the lever   of the brake force regulator.

  • Page 59: Adjusting The Rebound Harrow

    Operation Rolling circumference Tyres [3092 mm - 3254 mm] Setting Actual axle load [kg] from 2401 3000 3001 4300 4301 5100 5101 6100 7 (locked) Chapter 12.9 Tyres and wheels on page 99 ⮫  6.3.5 Adjusting the rebound harrow Adjustment options The rebound harrows slow down the flow of soil from the front row of discs.
  • Page 60 Operation Adjusting the machine Undo the screw connections  on both sides of the rebound harrow  Move the perforated plates  on the lateral sections  verti‐ cally and in longitudinal direction. Select the same holes on the right and left. ▶ For the front position: Use the holes ▶...

  • Page 61: Inclination Adjustment

    Operation Undo the screw connections on both sides of the rebound harrow Move the toothed racks  on the lateral sections  in longi‐ tudinal direction. For the front position: Use the holes  ▶ For the rear position: Use the holes  ▶ Tighten the screw connections ...

  • Page 62: Adjusting The Levelling Harrow

    Operation Adjusting the machine 6.3.6 Adjusting the levelling harrow The height of the levelling harrow can be adjusted. Preconditions: Tractor-machine combination is secured against rolling away. ✓ The lifted out machine has been secured with suitable supports ✓ against unintentional lowering. The tractor engine has been switched off.

  • Page 63: Adjusting Depth

    Operation Deactivating the straw harrow Preconditions: The machine has been lifted fully. ✓ The lifted out machine has been secured with suitable supports ✓ against unintentional lowering. Tractor-machine combination is secured against rolling away. ✓ The tractor engine has been switched off. ✓...

  • Page 64: Adjust The Weed Harrow

    Operation Adjusting the machine Deactivate straw harrow. Undo the bolted connections between the harrow holder and the frame Remove the bolted connection Move the harrow holder to the desired position CAUTION: Straw harrow and harrow holder are heavy. Per‐ ■ form work with 2 persons.

  • Page 65: Adjust Height

    Operation Adjust height Preconditions: Machine has been lowered. ✓ The tractor engine has been switched off. ✓ Tractor-machine combination is secured against rolling away. ✓ Machines with depth guiding wheels: The working depth has ✓ been adjusted via the depth guiding wheels. Remove the linch pins ...

  • Page 66: Adjusting The Limiting Discs

    Operation Adjusting the machine Secure the pin with a linch pin  �� The height of the weed harrow has been adjusted. 6.3.9 Adjusting the limiting discs The limiting discs feature a three-stage height adjustment. With increasing wear: Set the limiting discs lower. Secure the tractor and machine to prevent them from ■...

  • Page 67: Adjusting The Knife Roller

    Operation 6.3.10 Adjusting the knife roller Working depth of the knives Preconditions: Tractor-machine combination is secured against rolling away. ■ Lifted parts are secured to prevent them from lowering. ■ Ignition key is removed. ■ On both sides of the roller: Relieve the top pin.

  • Page 68: Working With The Machine

    Operation Working with the machine Position of the knife bar The knife bar  has two mounting positions. Upper mounting position  (lower hole): ■ – Default setting – Adjustment for extremely sticky soils – Adjustment for light soils Lower mounting position  (upper hole): ■...
  • Page 69 Operation Working in the field Move the tractor-machine combination to the operating posi‐ tion. If present, remove the safety guards. With folding machine: Fold out the machine. Set the machine. Synchronise the hydraulic rams of the depth adjustment daily before working in the field. For a hydraulic system without memory function: Move the depth adjustment to position 1.

  • Page 70: Driving On The Headland

    Operation Working with the machine 6.4.2 Driving on the headland A few metres before reaching the headland: Briefly actuate the function for lifting the machine. �� An existing straw harrow is swivelled in. �� The concave discs continue working the straw in. ��...

  • Page 71: Cleaning And Care

    Cleaning and care Cleaning and care Cleaning with high-pressure cleaner The user can clean the machine with the high-pressure cleaner. When cleaning, the user must observe the following: NOTICE Damage due to cleaning with a high-pressure cleaner Components may be damaged when cleaning with a high-pres‐ sure cleaner.

  • Page 72: Decommissioning

    Decommissioning Detaching the machine Decommissioning Detaching the machine If the machine is to be parked in the folded-in position: Fold in the machine prior to detaching. Chapter 6.1.1 Folding the machine on page 47 ⮫  For transport to the parking place: Prepare the machine for driving.
  • Page 73 Decommissioning 12. Machine with drawbar eye: Remove the pin from the tractor drawbar and the drawbar eye. Do not yet move the tractor and the machine away from each other. 13. Switch the hydraulic assembly to depressurised. WARNING Hydraulic oil under pressure may squirt out of the hydraulic hoses when they are connected and disconnected.

  • Page 74: Maintenance And Repair Work

    ■ Marked in the SERVICE PERSONNEL column in the maintenance ■ schedule Latest versions of the LEMKEN spare Current LEMKEN spare parts lists are available from agroparts . parts lists agroparts . The QR code takes the user directly to Free registration is required for use.

  • Page 75: During The Maintenance And Repair

    Maintenance and repair work Preparations before working on the Turn off the engine. machine Engage the parking brake of the tractor. Remove the ignition key. Secure the tractor-machine combination to prevent it from rolling away. When working on raised machines: Secure the machines against lowering (e.g.

  • Page 76: Maintenance

    Maintenance and repair work Maintenance Maintenance 9.2.1 Maintenance schedule Chap. Task to execute 9.2.2 Checking the top link pin                       ● 9.2.2 Checking the cross shaft          ...
  • Page 77 Maintenance and repair work Chap. Task to execute 9.2.4 Checking safety sticker                       ● 9.2.4 Checking other safety                       ● equipment 9.2.4 Checking hydraulic-...

  • Page 78: Tractor Connection

    Maintenance and repair work Maintenance SERVICE PERSONNEL Chap. Page 9.2.2 Checking the cross shaft 9.2.2 Checking the ball-shaped coupling or the drawbar eye Maintaining braking system Check the compressed air couplings 9.2.5 Replacing hydraulic hoses 9.2.2 Tractor connection Checking the top link pin Visual inspection of the top link pin for: Damage ■...

  • Page 79: Trailer

    Maintenance and repair work Checking the ball-shaped coupling or Personnel: the drawbar eye Service personnel ■ Visual inspection by the user Wear ■ Damage ■ Peculiarities when driving ■ Have a damaged, deformed or worn ball-shaped coupling or drawbar eye replaced immediately. Use a torque wrench to tighten fastening screws (user).

  • Page 80: Bolted Connections

    Maintenance and repair work Maintenance Draining compressed air tank Target: Remove condensation from the compressed air tank. Ensure that the compressed air tank is aligned horizontally. Push the pin of the drain valve  to the side. �� Compressed air forces the condensation water out of the compressed air tank ...

  • Page 81: Electrics

    Maintenance and repair work Replacing hydraulic hoses Personnel: Service personnel ■ Replace hydraulic hoses every 6 years (according to date of manufacture). �� Only use hydraulic hoses approved by the manufacturer, see spare parts list. Checking hydraulic connections Check the hydraulic connections for the following when pres‐ sureless: Damage ■...

  • Page 82: Rollers

    Maintenance and repair work Maintenance Check the concave discs Visual inspection Damage ■ Wear ■ Immediately replace damaged concave discs. Replace worn concave discs that measure less than 460 mm in diameter. Chapter 9.4.2 Replacing concave discs on page 91 ⮫  Checking soil cultivation implements Visual inspection Damage...

  • Page 83: Lubricating

    Maintenance and repair work Lubricating 9.3.1 Lubrication schedule Chap. Task to execute 9.3.2 Lubricate the pivot bearing at the head‐         ● ● stock 9.3.2 Lubricate the drawbar eye         ● ● 9.3.2 Lubricating ball-shaped coupling  ...
  • Page 84 Maintenance and repair work Lubricating Lubricate the pivot bearing at the headstock Lubricate a lubricating point at the pivot bearing. Lubricate the drawbar eye Lubricate a lubricating point at the drawbar eye. Lubricating ball-shaped coupling Lubricate a lubricating point at the ball-shaped coupling. Lubricating wheel bearings Lubricate a lubricating point at each wheel bearing.
  • Page 85 Maintenance and repair work Lubricate hydraulic rams Lubricate two lubricating points  at all hydraulic rams. Lubricate folding joints of the lateral sections Lubricate four lubricating points at the folding joints of the lateral sections (red). Lubricate the joints of the trailer Lubricate two lubricating points at the joints of the trailer (green).

  • Page 86: Greasing Components

    Maintenance and repair work Lubricating Lubricate the bearings of the drawbar Lubricate two lubricating points at the bearings of the basic frame and the drawbar (yellow). 9.3.3 Greasing components Grease top link pin Dismantle, grease and reassemble the top link pin. Grease pin Dismantle pin, grease and reassemble.

  • Page 87: Work Instructions

    Maintenance and repair work Lubricate the contact surfaces with a brush. Work instructions 9.4.1 Clean compressed air filter Preparing cleaning Preconditions: The machine is standing on a flat and level surface.  ✓ The machine is secured with wheel chocks against rolling away. ✓...
  • Page 88 Maintenance and repair work Work instructions Cleaning the filter of the yellow com‐ pressed air coupling Place a collector under the yellow compressed air coupling . Dismantle the compressed air coupling: Press down the screw-in plug using an Allen key and turn ▶...
  • Page 89 Maintenance and repair work Mount the compressed air coupling: Press down the screw-in plug using an Allen key and turn ▶ 90° clockwise. �� The screw-in plug closes flush with the edge of the housing. �� The compressed air coupling has been mounted. Cleaning the filter of the red com‐...
  • Page 90 Maintenance and repair work Work instructions Carefully loosen both screws  , as a spring under tension is located between the cover  and filter screen in the housing. Put the components to one side: Cover  ■ Screws  ■ Spring  ■ Clean the filter screen  Blow out filter screen with compressed air.

  • Page 91: Replacing Concave Discs

    Maintenance and repair work 11. Mount the components and fix them in place with the screws  Cover  ■ Spring  ■ Upper plate  ■ �� The compressed air coupling has been mounted. After cleaning Couple the compressed air coupling to the tractor in the following order: 1.

  • Page 92: Replacing The Harrow Tines Of The Rebound Harrow

    Maintenance and repair work Work instructions Wear suitable protective gear: Safety gloves ■ Safety shoes ■ CAUTION Worn components may have sharp edges. There is therefore a risk of cuts. Carefully clean the concave disc  and bearing flange  NOTICE After dismantling the concave disc, a section of the bearing is openly accessible.

  • Page 93: Replacing The Levelling Harrow

    Maintenance and repair work Remove the screws at the harrow tine holder. Remove the harrow holder Tap the spring out from below using a hammer. Push down the harrow laterally from the harrow holder. Push a new harrow onto the harrow holder Re-insert the spring from the top using a hammer.

  • Page 94: 10 Troubleshooting And Error Correction

    Troubleshooting and error correction Finding and eliminating errors correctly 10 Troubleshooting and error correction 10.1 Finding and eliminating errors correctly Necessary deviations from this procedure are described in the respective chapters on trouble‐ shooting. Park the tractor-machine combination. Secure the tractor-machine combination to prevent it from rolling away.

  • Page 95: 11 Final Decommissioning

    Final decommissioning 11.2 11 Final decommissioning 11.1 Shutdown When the machine can no longer be used, it is dismantled and broken down into its components. Special knowledge is required to dismantle the machine. CAUTION Risk of accidents due to discharge of stored energy Springs are under tension.

  • Page 96: 12 Technical Data

    Technical data Permissible mass and loads 12 Technical data 12.1 Dimensions Rubin 10 TF /400 /500 /600 /700 Transport length Maximum [cm] Transport length Minimum [cm] Transport width Maximum [cm] Transport height Maximum [cm] Working width approx. [cm] To determine the actual dimensions: Measure the machine.

  • Page 97: Required Drawbar Load

    At least 4% of the weighed machine weight or 500 kg 12.5 Performance data Ambient conditions and operating conditions Transport speed Maximum [km/h] Operating temperature range minimum...maximum [°C] 0...50 Operating data Rubin 10 TF minimum...maximum 2...25 [km/h] Operating speed recommended [km/h] Maximum Working depth [cm] Tractor power...

  • Page 98: Connection Data

    Technical data Noise, airborne sound 12.6 Connection data 12.6.1 Electrical connections Tab. 6: Voltage sources Consumer Voltage Connection directly on Power socket the tractor battery Lighting equipment According to DIN ISO 1724 Lighting equipment According to (Canada, USA) ISO 1185 Voltage tolerance range: 10...15 V 12.6.2 Hydraulic connections and control units Control units...

  • Page 99: Operating Materials

    Hydraulic assembly Grease nipple (according to lubrication schedule) Appendix C LEMKEN overview of operating * See LEMKEN overview of operating materials in the Annex: ⮫  materials on page 118 Chapter 9.3.1 Lubrication schedule on page 83 Intervals, see lubrication schedule: ⮫ ...

  • Page 100: 12.10 Compressed Air Brake

    Two-line compressed air brake ● Tractor coupling heads according to ISO 1728 12.11 Connecting systems at the machine Permitted categories for cross shafts and Rubin 10 TF top link pins Rubin 10 TF Cross shaft category 3N ● ● ●...
  • Page 101 Technical data 12.11 Drawbar eyes and permitted tractor drawbars Rubin 10 TF Tractor Drawbar eye (size) Standard Tractor drawbar Swivel angle axial: ± 20° ISO 6489-3 vertical: ± 20° CAT 3 horizontal: 60° axial: ± 21° ISO 6489-3 vertical: ± 21° CAT 2 horizontal: 60°...
  • Page 102 Technical data Connecting systems at the machine Drawbar eyes with ball joint and permitted tractor drawbars Rubin 10 TF Tractor Drawbar eye with ball Standard Tractor drawbar Swivel angle joint (size) ISO 6489-3 21° CAT 3 ISO 6489-3 21° CAT 2 Æ 42 mm hole...

  • Page 103: 12.12 Permissible Roller Types

    Technical data 12.12 12.12 Permissible roller types Diameter* Rubin 10 TF Ground* [mm] Roller types */** /600 [kg] Roller Tube RSW 540 ● ● ● Tube bar roller RSW 600 ● ● ● ● Tube/Flat DRF 400/400 400/400 ● ●...
  • Page 104 Technical data Permissible roller types BA 70217215 | 69210276 en_GB | Rev_ | 2024-04...

  • Page 105: 13 Index

    Index 13 Index Air pressure Decommissioning Check......... 79 Final.
  • Page 106 Index Hydraulic control units......98 Hydraulic drawbar....... . . 29 Machine Hydraulic ram Adjust.
  • Page 107 Index Stand......... . 26, 27 lubrication.
  • Page 108 Index Weed harrow Mounting........51 Wheel Lubricate.

  • Page 109: 14 Appendix

    14 Appendix...

  • Page 111: Appendix - Table Of Contents

    LEMKEN overview of operating materials........
  • Page 112 Appendix - Table of contents BA 70217215 | 69210276 en_GB | Rev_ | 2024-04...

  • Page 113: A Type Plate Variants

    19 Type / Variant / Version near the type plate. 20 Technical conditions Permissible total mass [kg]* 21 QR code to call up LEONIS (LEMKEN Online Infor‐ 10 Permissible drawbar load [kg] (axle 0) mation System) 11 Permissible axle load [kg] (axle 1)

  • Page 114: B Tightening Torques Screws

    Tightening torques screws Bolted connections, general principles Tightening torques screws Bolted connections, general principles The following tightening torques refer to screw connections not specifically mentioned in these mounting instructions. Special tightening torques are indicated in the text. Identify screw connection: ■...

  • Page 115: Tightening Torques For Bolted Connections

    Tightening torques screws Tightening torques for bolted connections The following tightening torques apply with all bolted connections used by LEMKEN, unless specified otherwise: Tab. 7: Screws and nuts made of steel Diameter Strength category 8.8 [Nm*] 10.9 [Nm*] 12.9 [Nm*] 12.0...

  • Page 116: Tightening Torques For Wheel Bolts And Wheel Nuts

    Tightening torques screws Tightening torques for wheel bolts and wheel nuts Diameter Strength category 8.8 [Nm*] 10.9 [Nm*] 12.9 [Nm*] M24 x 2 1083 M30 x 1.5 1295 1820 2185 M30 x 2 1275 1792 2151 M36 x 1.5 2254 3170 3804 M42 x 1.5...
  • Page 117 The tightening torques are calculated for the friction values µ specified in the tables. The required tightening torque deviates: − If any screws other than LEMKEN original screws are used. − If screws are re-used. Only use LEMKEN original screws!

  • Page 118: Clemken Overview Of Operating Materials

    LEMKEN overview of operating materials LEMKEN overview of operating materials F - fluid grease LEMKEN Designation Container size Reference Specification / Standard item number LEMKEN specification ■ Lubricant code: ■ – Castrol Tribol GR Castrol Tribol GR 100-00 PD ■ 00 PD: DIN 51502 877 1595 5 kg...
  • Page 119 The latest versions of the documents can be found in the LEMKEN Online Information System (LEONIS). Users can access LEONIS directly via the QR code or the LEMKEN website. It is where the user can find spare parts for the latest versions of the documents.

  • Page 120: D Cross Shaft Overview

    Cross shaft overview Cross shaft overview To determine the cross shaft or lower link connection: Determine the dimensions shown in the sketch on the machine. ■ Compare the dimensions with the data in the table. ■ The category of the three-point linkage must match with the ■...
  • Page 122 LEMKEN GmbH & Co. KG Weseler Straße 5 D-46519 Alpen Telephone: +49 2802 81-0 Fax: +49 2802 81-220 Email: info@lemken.com Internet: www.lemken.com...

This manual is also suitable for:

Rubin 10 tf/500Rubin 10 tf/400Rubin 10 tf/600Rubin 10 tf/700

Table of Contents
