Safety Instruction The following symbols or words may be found in this manual. Symbols/Words Description Indicates a medium or low potential hazardous situation which , Warning if not avoided, will or could result in slight or moderate injury Indicates a potential risk which, if not avoided, will or could Caution result in device damage, data loss, lower performance or unexpected results...
Power Source', 'LPS' on unit, output rated minimum 12V/2 A or POE 48V/ 350mA, no more than 2000m altitude of operation and Tma=60 Deg.C. As for the modes with PoE function, the function of the ITE being investigated to IEC 60950-1 standard is considered not likely to require connection to an Ethernet network with outside plant routing, including campus environment and the ITE is to be connected only to PoE networks without routing to the outside plant.
and effective manner and clarify the monitoring range. As the device user or data controller, you might collect the personal data of others, such as face, car plate number, etc. As a result, you shall implement reasonable and necessary measures to protect the legitimate rights and interests of other people, avoiding data leakage, improper use, including but not limited to, setting up access control, providing clear and visible notice to inform people of the existence of the surveillance area, providing required...
addresses were used to log in your system and what was accessed. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 6
Directive 94/62/EC: The Directive aims at the management of packaging and packaging waste and environmental protection. The packaging and packaging waste of the product in this manual refers to must be disposed of at designated collection points for proper recycling and environmental protection.
Table of Contents Introduction ........................1 1.1 Main Features........................1 1.2 Description of Buttons ....................1 Network Connection ....................... 3 2.1 Wired Network Connection ..................... 3 2.2 Wi-Fi Connection ......................5 2.3 WAN ..........................7 Live View via Web ......................9 Configuration via Web ....................
Page 8
Video Intercom Door Station User Manual 4.7.3 OSD Configuration ....................33 4.8 Alarm Configuration ..................... 34 4.8.1 Video Exception ..................... 34 4.8.2 Exception Alarm ....................36 4.8.3 Alarm In ......................... 37 4.8.4 Alarm Out....................... 39 4.9 Network Configuration ....................40 4.9.1 TCP/IP ........................
Video Intercom Door Station User Manual Introduction 1.1 Main Features Max. resolution: 2MP (1920× 1080) H.265+/H.265/H.264+/H.264/MJPEG coding Face recognition distance: 0.3m-2m Support face detection technology distinguishing real faces from non-real face spoof attacks Support 3D DNR, HWDR, BLC, HLC, Defog, etc. ...
Page 10
Video Intercom Door Station User Manual Description Keypad Press it to delete the input number or return to the live view interface Press it to call the control center/indoor station/APP Call button...
Video Intercom Door Station User Manual Network Connection 2.1 Wired Network Connection Here we take device access via Web browser for example. Web browser: IE (plug-in required)/ Firefox/Edge/ Google Chrome It is recommended to use the latest version of these web browsers. The menu display and operation of the camera may be slightly different by using the browser with plug-in or without plug-in.
Page 12
Video Intercom Door Station User Manual IP-CAM. After you read the privacy statement, check and click “Already Read”. Then activate the device. Please self-define the password of admin according to the tip. If “Activate Onvif User” is enabled, the ONVIF user can be activated simultanously. When you connect the camera through the ONVIF protocol in the third-party platform, you can use the default username and the password set above to connect.
Video Intercom Door Station User Manual If you forget the admin password, you can reset the password by clicking Forget Password on the login page. Then you can reset the password by the security questions and answers you set. You can set the account security question during the activation, or you can go to ...
Page 14
Video Intercom Door Station User Manual and then find the device via its MAC address. Then double click it. This will bring you to the login interface of the camera. Enter the default username and password to log in. ...
Video Intercom Door Station User Manual After that, you can also use the downloaded APP to scan the QR code of the device and then enter the security code to add it to the server list of the APP. 2.3 WAN To remotely access the device via Web, the setting steps are as follows: ①...
Page 16
Video Intercom Door Station User Manual port of the camera in the “Virtual Server”. Router Setup ④ Open the IE browser and enter its WAN IP and http port to access. (for example, if the http port is changed to 81, please enter “192.198.1.201:81” in the address bar of web browser to access).
Video Intercom Door Station User Manual Live View via Web After logging in, the following window will be shown. The following table is the instructions of the icons on the live view interface. Icon Description Icon Description Original size Start/stop local recording Fit correct scale Zoom in Auto (fill the window)
Page 18
Video Intercom Door Station User Manual * Those smart alarm indicators will flash only when the camera supports those functions and the corresponding events are enabled. * Plug-in free live view: the local recording is not supported and the preview mode switch (real-time/balanced/fluent mode) is not available too.
Video Intercom Door Station User Manual Configuration via Web In the Webcam client, choose “Config” to go to the configuration interface. Note: Wherever applicable, click the “Save” button to save the settings. 4.1 Door Station Settings Go to Config Intercom interface as shown below.
Video Intercom Door Station User Manual Note: Please add the door station to the indoor station before calling. Please see Appendix 1 for details. 4.2.2 Call Platform Press any digit button on the main or sub door station to enter the calling page. Press to call the platform.
Page 21
Video Intercom Door Station User Manual 2. Enable liveness detection. If enabled, the system can distinguish real faces from non-real face spoof attacks. 3. Enable “Save Source Information” or “Save Face Information”. Save Source Information: if checked, the whole picture will be saved to the SD card when detecting a face.
Page 22
Video Intercom Door Station User Manual Deduplication Period: In the set period, delete the repeated comparison results. Similarity threshold: When the similarity of the captured face picture and the face picture added into the face database exceeds the similarity threshold, alarms will be triggered. Send the face comparison data: if it is disabled, the face comparison result will be displayed neither on the screen of the terminal nor on the live interface of the web client.
Video Intercom Door Station User Manual rectangle to change its position. Click “Stop Draw” to stop drawing the area. Click “Clear” to clear the area. Then set the detectable face size by defining the maximum value and the minimum value (The default size range of a single face image occupies from 3% to 50% of the entire image).
Page 24
Video Intercom Door Station User Manual It is recommended to put the people information file and images into the same directory as shown on the below left. Click “CSV” to select the directory and then click “Choose face” to select the faces you want to import.
Video Intercom Door Station User Manual 4.3.3 Face Match View After all face comparison settings are set successfully, enter the live view interface. Click to view the captured face pictures and face comparison information. Area ①: captured face pictures; area ②: face comparison area ...
Video Intercom Door Station User Manual Fill out the relevant information and click “Entry” to add this face picture. 4.4 Unlock Door 4.4.1 Unlock by Super Password Press any digit button on the main or sub door station to enter the calling page. Enter #Super ...
Page 27
Video Intercom Door Station User Manual Common Password, any one of them Password you entered when adding a person Face Comparison + Swiping Card When the unlocking mode is set to “Face Comparison and Swiping Card” (To set the unlocking mode, see Face Database Management for details), you need to swipe a card after...
Video Intercom Door Station User Manual 4.4.4 Unlock via Web In the live view interface, click to unlock the door. 4.5 Access Control System Settings 4.5.1 Local Settings Click Config Access Control Access Control System Config to go to the following interface.
Video Intercom Door Station User Manual Select the voice you want to replace and then click “Browse” to select the desired audio file. After that, click “Upload” to upload the audio file. Rename the audio as needed. After your own voice prompt is uploaded, you can select it from the audio list and click “Listen”...
Page 30
Video Intercom Door Station User Manual system will open the door according to the pre-defined unlocking condition. “NO” means “normally open”; “NC” means “normally closed”. Alarm Linkage Type: Open or close the door when an alarm is triggered. Please select it as needed.
Video Intercom Door Station User Manual 4.5.3 Door Contact Settings Click Config Access Control Door Contact Setting to go to the following interface. Door Contact Input ID: Choose door contact 1 or 2. Door Contact Input Type: NO or NC Unlocking Delay Time: the allowable unlocking time.
Video Intercom Door Station User Manual set first in the Email configuration interface), the captured pictures and triggered event will be sent into those addresses. Trigger FTP: If “Trigger FTP” is checked, the captured pictures will be sent into FTP server address.
Video Intercom Door Station User Manual Enable “Tampering Alarm” and then set the alarm holding time and alarm trigger options. Trigger Audio Alarm: if enabled, you will hear the warning sound when the doorbell is removed or damaged by the external force. The setup steps of other alarm trigger options are similar to the face detection settings.
Video Intercom Door Station User Manual Note: You need to use a professional card enroller to encrypt the cards. If you want to use card encryption function, please purchase a card enroller and set in advance. 4.6 System Settings 4.6.1 Basic Information In the “Basic Information”...
Video Intercom Door Station User Manual Select the time zone and DST as required. Note: The time zone of the camera and the computer must be the same. It is recommended to modify the time zone of the camera according to the time zone of the computer. If the time zone of the computer is modified, the current web client needs to be closed.
Page 36
Video Intercom Door Station User Manual SD Card Management Click the “Format” button to format the SD card. All data will be cleared by clicking this button. Click the “Eject” button to stop writing data to SD card. Then the SD card can be ejected safely.
Page 37
Video Intercom Door Station User Manual Weekly schedule Set the alarm time from Monday to Sunday for a single week. Each day is divided in one hour increments. Green means scheduled. Blank means unscheduled. “Add”: Add the schedule for a special day. Drag the mouse to set the time on the timeline. “Erase”: Delete the schedule.
Video Intercom Door Station User Manual Set the format, resolution and quality of the image saved on the SD card and the snapshot interval and quantity and the timing snapshot here. Snapshot Quantity: The number you set here is the maximum quantity of snapshots. The actual quantity of snapshots may be less than this number.
Page 39
Video Intercom Door Station User Manual Brightness: Set the brightness level of the camera’s image. Contrast: Set the color difference between the brightest and darkest parts. Hue: Set the total color degree of the image. Saturation: Set the degree of color purity. The purer the color, the brighter the image is. Sharpness: Set the resolution level of the image plane and the sharpness level of the image edge.
Video Intercom Door Station User Manual can be adjusted. Gain Mode: Choose “Auto” or “Manual”. If “Auto” is selected, the gain value will be automatically adjusted (within the set gain limit value) according to the actual situation. If “Manual” is selected, the gain value shall be set manually. The higher the value is, the brighter the image is.
Video Intercom Door Station User Manual image quality will be. Video Quality: It can be adjusted when the mode is set to VBR. The higher the image quality, the more bitrate will be required. I Frame interval: It determines how many frames are allowed between a “group of pictures”. When a new scene begins in a video, until that scene ends, the entire group of frames (or pictures) can be considered as a group of pictures.
Video Intercom Door Station User Manual Set time stamp, device name, OSD content and picture overlap here. After enabling the corresponding display and entering the content, drag them to change their position. Then click the “Save” button to save the settings. Picture Overlap Settings: Check “OSD Content1”, choose “Picture Overlay”...
Page 43
Video Intercom Door Station User Manual 1. Enable the applicable detection that’s desired. Scene Change Detection: Alarms will be triggered if the scene of the monitor video has changed. Video Blur Detection: Alarms will be triggered if the video becomes blurry. Abnormal Color Detection: Alarms will be triggered if the image is abnormal caused by color deviation.
Video Intercom Door Station User Manual The sensitivity value of Scene Change Detection: The higher the value is, the more sensitive the system responds to the amplitude of the scene change. The sensitivity value of Video Blur Detection: The higher the value is, the more sensitive the system responds to the blurriness of the image.
Video Intercom Door Station User Manual IP Address Conflict 1. Go to Config Alarm Exception Alarm IP Address Collision as shown below. 2. Click “Enable” and set the alarm holding time. 3. Trigger alarm out. When the IP address of the camera is in conflict with the IP address of other devices, the system will trigger the alarm out.
Page 46
Video Intercom Door Station User Manual 1. Select the sensor ID. 2. Click “Enable” and set the alarm type, alarm holding time and sensor name. 3. Set alarm trigger options. Trigger Door Lock: you can check “Door Lock1” or “Door Lock2”. When a sensor alarm occurs, the door1/2 will be opened or closed according to the alarm linkage type of door lock ...
Video Intercom Door Station User Manual The setup steps of other alarm trigger options are the same as the alarm trigger settings of Door Contact Settings. 3. Set the schedule of the sensor alarm. The setup steps of schedule are the same as the schedule recording (See Schedule Recording).
Video Intercom Door Station User Manual Timing: Select the alarm type. Then click “Add” and drag the mouse on the timeline to set the schedule of alarm out; click “Erase” and drag the mouse on the timeline to erase the set time schedule.
Video Intercom Door Station User Manual be changed by obtaining an IP address automatically. Test: Test the effectiveness of the IP address by clicking this button. Use PPPoE-Click the “PPPoE Config” tab to go to the interface as shown below. Enable PPPoE and then enter the user name and password from your ISP.
Video Intercom Door Station User Manual HTTP Port: The default HTTP port is 80. It can be changed to any port which is not occupied. HTTPS Port: The default HTTPs port is 443. It can be changed to any port which is not occupied.
Video Intercom Door Station User Manual protocol. If “Activate Onvif User” is enabled in the device activation interface, the ONVIF user can be activated simultanously. When you connect the camera through the ONVIF protocol in the third-party platform, you can use this onvif user to connect. You can also add new users in the Onvif interface.
Video Intercom Door Station User Manual “Registration” button. Create domain name. After the domain name is successfully applied for, the domain name will be listed as below. 3. Enter the username, password, domain you apply for in the DDNS configuration interface. 4.
Video Intercom Door Station User Manual To use this function, the camera shall be connected to a switch supporting 802.1x protocol. The switch can be reckoned as an authentication system to identify the device in a local network. If the camera connected to the network interface of the switch has passed the authentication of the switch, it can be accessed via the local network.
Video Intercom Door Station User Manual Third stream: The address format is “rtsp://IP address: rtsp port/profile3?transportmode=mcast”. Audio: Having entered the main/sub stream in a VLC player, the video and audio will play automatically. If “Allow anonymous login…” is checked, there is no need to enter the username and password to view the video.
Video Intercom Door Station User Manual Sender Address: sender’s e-mail address. User name and password: sender’s user name and password. If “Anonymous login” is selected, an anonymous Email will be sent when an alarm is triggered. Server Address: The SMTP IP address or host name. Select the secure connection type at the “Secure Connection”...
Video Intercom Door Station User Manual Server Name: The name of the FTP server. Server Address: The IP address or domain name of the FTP. Upload Path: The directory where files will be uploaded to. Port: The port of the FTP server. User Name and Password: The username and password that are used to login to the FTP server.
Video Intercom Door Station User Manual * If there is a signed certificate, click “Browse” to select it and then click “Install” to install it. * Click “Create a private certificate” to enter the following creation interface. Click the “Create” button to create a private certificate. Enter the country (only two letters available), domain (camera’s IP address/domain), validity date, password, province/state, region and so on.
Video Intercom Door Station User Manual network applications. With the deficient bandwidth, the router or switch will sort the data streams and transfer them according to their priority to solve the network delay and network congestion by using this function. Go to ConfigNetworkQoS.
Video Intercom Door Station User Manual If you choose “Obtain an IP address automatically”, you shall get the IP address from the router. Or you can choose “Use the following IP address” to set the network parameters manually. Then you can use this IP address to log in mobile surveillance APP/ web client/NVMS/NVR/…...
Page 60
Video Intercom Door Station User Manual 2. Enter user name in the “User Name” textbox. 3. Enter the password in the “Password” and “Confirm Password” textbox. Please set the password according to the requirement of the password security level (Go to ...
Video Intercom Door Station User Manual 3. Enter the old password of the user in the “Old Password” text box. 4. Enter the new password in the “New password” and “Confirm Password” text box. 5. Select the user permissions for advanced or normal user. 6.
Video Intercom Door Station User Manual 4.10.3 Block and Allow Lists Go to Config Security Block and Allow Lists as shown below. The setup steps are as follows: Check the “Enable address filtering” check box. Select “Block/Allow the following address”, IPv4/IPv6 and then enter IP address in the address box and click the “Add”...
Video Intercom Door Station User Manual Weak level: Numbers, special characters, upper or lower case letters can be used. You can choose one of them or any combination of them when setting the password. Medium Level: 8~16 characters, including at least two of the following categories: numbers, special characters, upper case letters and lower case letters.
Video Intercom Door Station User Manual 1. Click “Browse” to select the save path for import or export information on the PC. 2. Click the “Import Setting” or “Export Setting” button. Note: The login password needs to be entered after clicking the “Import Setting” button. ...
Page 65
Video Intercom Door Station User Manual 2. Select the main type, sub type, start and end time. 3. Click “Search” to view the operation log. 4. Click “Export” to export the operation log.
Video Intercom Door Station User Manual Search 5.1 Image Search Click Search to go to the interface as shown below. Images that are saved on the SD card can be found here. Note: When using the plug-in free browser, the local images cannot be searched. ...
Page 67
Video Intercom Door Station User Manual Click to return to the previous interface. SD Card Image Search Choose “Picture”—“SD Card”. Set time: Select date and choose the start and end time. Choose the alarm events at the bottom of the interface. Click to search the images.
Video Intercom Door Station User Manual 5.2 Video Search 5.2.1 Local Video Search Click Search to go to the interface as shown below. Videos were recorded locally to the PC can be played in this interface. Note: When using the plug-in free browser, the local videos cannot be searched. Choose “Record”—“Local”.
Video Intercom Door Station User Manual Icon Description Icon Description Play button. After pausing the video, click this button to Pause button continue playing. Stop button Speed down Speed up Watermark display Enable / disable audio; drag the slider to adjust the volume after enabling audio.
Page 70
Video Intercom Door Station User Manual Note: cannot be displayed in the above interface via the plug-in free browser. Additionally, for plug-in free playback, playback mode switch (balanced/real-time/fluent mode) and downloading functions are not supported too. The time table can be shown in 24H/12H/2H/1H format by clicking the corresponding buttons.
Video Intercom Door Station User Manual Appendix Appendix 1 How to Call Indoor Station 5.3 Appendix 1-1 One Door Station Calls One Indoor Station Application: Install one door station and bind one indoor station. Press the preset room number and call button or press to call indoor station The setting steps are as follows: 1.
Video Intercom Door Station User Manual 5.4 Appendix 1-2 One Door Station Calls Multiple Indoor Stations Application A: Install one door station and bind multiple indoor stations with the same room number set. Press the room number and call button or press to call indoor stations.
Video Intercom Door Station User Manual station. Note: For one indoor station, up to 5 indoor extensions can be configured. The indoor station number is 0 by default. 5. Call indoor station through your door station (See Call Resident for details). All indoor stations (including indoor station and extensions) will respond at the same time.
Page 74
Video Intercom Door Station User Manual 3. Sub door station settings Log in the web client of the door station. Click Config Intercom Number Configuration to go to the following interface. Set the device type to “Sub Door Station”. Enter the actual IP address of the main door station and door station no.
Video Intercom Door Station User Manual 5. Call indoor station through your main or sub door station (See Call Resident for details). 5.6 Appendix 1-4 Multiple Door Stations Call Multiple Indoor Stations Application A: Install multiple door stations (one is main door station, others are sub door stations) and multiple indoor stations (all indoor stations are set as “Indoor Station”).
Page 76
Video Intercom Door Station User Manual Door Station No.: enter the sub door station number (ranging from 1 to 99; 0 is main station number by default). Different sub door stations should have different door station number. 4. Indoor station settings ...
Page 77
Video Intercom Door Station User Manual network parameters to the same network segment. 2. Main door station settings Log in the web client of the door station. Click Config Intercom Number Configuration to go to the following interface. Set the device type to “Main Door Station”. 3.
Page 78
Video Intercom Door Station User Manual 5. Indoor extension settings Tap Settings More Settings Configuration in the indoor station. Then enter the password of Admin to enter the following interface. Set the indoor station type (it should be set to “Indoor Extension”), indoor extension No.
Video Intercom Door Station User Manual Appendix 2 Troubleshooting How to find the password? A: The password for admin can be reset through “Edit Safety Question” function. Click “Forget Password” in the login window and then enter the corresponding answer of the selected question in the popup window.
Page 80
Video Intercom Door Station User Manual No sound can be heard. A:Audio input device is not connected. Please connect and try again. B: Audio function is not enabled at the corresponding channel. Please enable this function. How to modify IP address through IP-Tool? A: After you install the IP-Tool, run it as shown below.
Page 81
Video Intercom Door Station User Manual For example, the IP address of your computer is 192.168.1.4. So the IP address of the camera shall be changed to 192.168.1.X. After modification, please enter the password of “admin” which is set in the device activation interface in advance and then click the “Modify” button to change the network parameters.
Page 82
Video Intercom Door Station User Manual b. check whether the IP address of the main door station is set in the indoor station. 2) if it is a sub door station a. check whether there is a main door station. If not, please set it as a main door station. b.
