- Page 1 Katherm QK nano ► Assembly, installation and operating instructions Keep these instructions in a safe place for future use! Issue03/24EN SAP No.1254735...
-
Page 3: Table Of Contents
Table of contents 1 General ..........................5 1.1 About these instructions ........................1.2 Explanation of Symbols.......................... 2 Safety............................ 6 2.1 Correct use............................. 2.2 Limits of operation and use........................2.3 Risk from electrocution!......................... 2.4 Personnel requirements - Qualifications ....................2.5 Personal Protective Equipment ......................3 Transport, storage and packaging.................. - Page 4 9 Operation..........................35 9.1 Operation of electromechanical control ....................35 9.2 Operation of the KaController........................ 35 9.2.1 Function keys, display elements ........................ 35 9.2.2 KaController type 3210001, type 3210002, type 3210006 ................ 38 10 Maintenance ......................... 39 10.1 Securing against reconnection ....................... 39 10.2 Maintenance Schedule:..........................
-
Page 5: General
Katherm QK nano Assembly, installation and operating instructions General About these instructions These instructions ensure the safe and efficient handling of this equipment. These instructions form an integral part of the equipment and have to be kept in the direct vicinity of the equipment and available to personnel at all times. -
Page 6: Safety
Katherm QK nano Assembly, installation and operating instructions Safety This section provides an overview of all important safety aspects to ensure optimum protection of personnel as well as safe and trouble-free operation. In addition to the safety instructions in these operating instructions, the valid safety, accident pre- vention and environmental protection regulations must be observed for the area of use of the unit. - Page 7 Katherm QK nano Assembly, installation and operating instructions Limits of operation and use Limits of operation Min./max. water temperature °C 15-90 Min./max. air intake temperature °C 15-40 Min./max. air humidity 15-75 Min. operating pressure bar/kPa Max. operating pressure bar/kPa 10/1000 Min./max.
-
Page 8: Risk From Electrocution
Katherm QK nano Assembly, installation and operating instructions IMPORTANT NOTE! Danger of frost in cooling mode! There is a risk of the heat exchanger freezing when used in unheated rooms. Make sure that the unit is equipped with a frost protection sensor and/or thermostat in this case. -
Page 9: Personnel Requirements - Qualifications
Katherm QK nano Assembly, installation and operating instructions Personnel requirements - Qualifications Expertise The installation of this product requires specialist expertise in heating, cooling, ventilation, installation and electrical engin- eering. As this knowledge is normally acquired through professional training in one of the above fields, it is not dealt with further here. -
Page 10: Transport, Storage And Packaging
IMPORTANT NOTE! Warranty claims can only be made within the applicable period for complaints. (More information is avail- able in the T&Cs on the Kampmann website) IMPORTANT NOTE! 2 people are needed to transport the unit. Wear personal protective clothing when transporting the unit. -
Page 11: Storage
Katherm QK nano Assembly, installation and operating instructions Storage Store packaging under the following conditions: Do not store outdoors. Store in a dry and dust-free place. Store in a frost-free place. Do not expose to aggressive media. Protect from direct sunlight. -
Page 12: Technical Data
Weight [kg] 8.2 - 19.1 6.7 - 18.1 Tab. 4: Technical data for Katherm QK nano at LPHW 75 / 65 °C, t = 20°C, with fan-assisted convection The sound pressure level was calculated with an assumed room insulation of 8 dB(A). This corresponds to a dis- tance of 2 m, a room volume of 100 m³... -
Page 13: Construction And Function
Brief description Katherm QK nano are decentralised units for the heating of room air, for use in hotels, offices and business premises, among others. Secondary air is drawn in by the fan and passed through the copper/aluminium heat exchanger. The temperature-con-... -
Page 14: Installation And Wiring
Katherm QK nano Assembly, installation and operating instructions Installation and wiring Requirements governing the installation site Only install and assemble the unit if the following conditions are met: Make sure that the unit is securely suspended/standing. Ensure that the airflow can circulate freely. -
Page 15: Installation Steps
Katherm QK nano Assembly, installation and operating instructions 6.2.1 Installation steps... - Page 16 Katherm QK nano Assembly, installation and operating instructions overall length...
- Page 17 Katherm QK nano Assembly, installation and operating instructions Expansion joint on site provided by the customer...
- Page 18 Katherm QK nano Assembly, installation and operating instructions...
-
Page 19: Screed Work
Katherm QK nano Assembly, installation and operating instructions 6.2.2 Screed work The following work needs to have been completed before screeding can begin: Water has been correctly connected. The electrical connections have been correctly wired. The unit is correctly positioned and levelled. -
Page 20: Connection To The Pipe Network
Katherm QK nano Assembly, installation and operating instructions 6.3.1 Connection to the pipe network Katherm QK nano, 230 V electromechanical and KaControl control configurations, trench height 70 mm Front view Side view Window side Room side Top view (without cover panel) - Page 21 Katherm QK nano Assembly, installation and operating instructions Katherm QK nano, 24 V electromechanical control configuration, trench height 70 mm Side view Front view Window side Room side Top view (without cover panel) Supply Return Valve kit type 442100, consisting of valve body, axial, 1/2" pre- Unit shown with roll-up grille settable, 24 V actuator, and 1/2"...
-
Page 22: Electrical Connection
Katherm QK nano Assembly, installation and operating instructions Electrical connection Maximum electrical rating values Katherm QK nano, 24 V electromechanical version (*24) Trench Nominal Mains fre- Nominal Nominal Leakage cur- Ri analogue IP class Protection length [mm / voltage [V... -
Page 23: Electromechanical Connection, 24 V (*24)
Katherm QK nano Assembly, installation and operating instructions Electromechanical connection, 24 V (*24) - Page 24 Katherm QK nano Assembly, installation and operating instructions...
- Page 25 Katherm QK nano Assembly, installation and operating instructions...
-
Page 26: Electromechanical Connection, 230 V (*00)
Katherm QK nano Assembly, installation and operating instructions Electromechanical connection, 230 V (*00) - Page 27 Katherm QK nano Assembly, installation and operating instructions...
- Page 28 Katherm QK nano Assembly, installation and operating instructions...
-
Page 29: Kacontrol (*C1)
Katherm QK nano Assembly, installation and operating instructions KaControl (*C1) 7.4.1 KaController installation Fig. 3: Installation of flush-mounted back box Electrical connection Connect the KaController to the nearest KaControl unit in line with the wiring diagram. The maximum bus length between the KaController and the KaControl master unit is 30 m. -
Page 30: Connection (*C1)
Katherm QK nano Assembly, installation and operating instructions 7.4.2 Connection (*C1) General information Route all low voltage cables along the shortest route. Ensure that low-voltage and power cables are separated, using metal partitions on cable harnesses. Wrong! Use only shielded cables as low-voltage and bus cables. - Page 31 Katherm QK nano Assembly, installation and operating instructions...
- Page 32 Katherm QK nano Assembly, installation and operating instructions...
- Page 33 Katherm QK nano Assembly, installation and operating instructions...
-
Page 34: Pre-Commissioning Checks
Katherm QK nano Assembly, installation and operating instructions Pre-commissioning checks Before initial commissioning, check whether all the necessary conditions have been met so that the unit can operate safely and properly. Structural tests Check that the unit is securely standing and fixed. -
Page 35: Operation
Katherm QK nano Assembly, installation and operating instructions Operation Operation of electromechanical control Room thermostat type 194000342924 Electronic room thermostat with infinitely variable speed adjustment, sur- face-mounted on in-wall box with visually unobtrusive design With thermal return, room temperature setting and speed pre-setting with... -
Page 36: Function Keys, Display Elements
Katherm QK nano Assembly, installation and operating instructions 9.2.1 Function keys, display elements All menus can be selected and set using the navigator dial. The LED background lighting is automatically switched off 5 seconds after the KaController is last used. The LED background lighting can be permanently disabled using a parameter setting. - Page 37 Katherm QK nano Assembly, installation and operating instructions KaController without operating keys (one-button operation) type 3210001 1. Display with LED background lighting 2. Navigator dial Change settings Call up menus Fig. 9: KaController type 3210001 KaController, black without function keys (one-button opera- tion) type 3210006 1.
-
Page 38: Kacontroller Type 3210001, Type 3210002, Type 3210006
Katherm QK nano Assembly, installation and operating instructions 9.2.2 KaController type 3210001, type 3210002, type 3210006 Press and hold down the navigator dial for 3 seconds to move from one menu to the next. Switching on the unit Option 1: Turn the navigator dial. -
Page 39: Maintenance
Katherm QK nano Assembly, installation and operating instructions Maintenance 10.1 Securing against reconnection DANGER! Risk of death by unauthorised or uncontrolled restart! Unauthorised or uncontrolled restarting of the equipment can result in serious injury or death. Before restarting, ensure that all safety devices are fitted and working properly and that there is no haz- ard to humans. -
Page 40: Maintenance Work
Katherm QK nano Assembly, installation and operating instructions 10.3 Maintenance work 10.3.1 Clean the inside of the unit Check all elements that come into contact with air (internal surfaces of the unit, outlet elements etc.) for dirt or deposits dur-... -
Page 41: Faults
Katherm QK nano Assembly, installation and operating instructions Faults The following chapter describes possible causes of faults and the work needed to rectify them. Should faults occur frequently, shorten the maintenance intervals in line with the actual loading on the unit. -
Page 42: Kacontrol Faults
Katherm QK nano Assembly, installation and operating instructions 11.2 KaControl faults Code Alarms Priority Faulty control sensor. Motor fault. Room frost protection. Condensation alarm. General alarm. Sensor AI1, AI2 or AI3 faulty. Unit frost protection. EEPROM error. Offline slave in the CAN bus network. -
Page 43: List Of Kacontrol Parameters
Katherm QK nano Assembly, installation and operating instructions List of KaControl parameters 12.1 Parameter list Parameter Function Standard Min. Max. Unit Katherm QK nano * P000 Software version P001 Basic setpoint for setpoint input ± 3K °C P002 Switch-on and switch-off hysteresis for valves... - Page 44 Katherm QK nano Assembly, installation and operating instructions Parameter Function Standard Min. Max. Unit Katherm QK nano * P037 Display P038 Lock/disable function on the control unit P039 Function of digital output V2 (in a 2-pipe system) P040 Valve control by pulse width modulation...
- Page 45 Katherm QK nano Assembly, installation and operating instructions Parameter Function Standard Min. Max. Unit Katherm QK nano * P078 Serial address of slave 8 P079 Serial address of slave 9 P080 Serial address of slave 10 P081 Dependence of the hydronic algorithms, slave 1...
- Page 46 Hysteresis for outside temperature to switch between heat- P133 K/10 ing/fan mode Threshold for outside temperature to switch between heat- P134 °C ing/fan mode P135 Activate virtual sensor P136 Activate external ventilation Tab. 12: Parameter key Katherm QK nano, standard revision 1.024 from 10.07.2020...
-
Page 47: Kacontroller Parameter List
Katherm QK nano Assembly, installation and operating instructions 12.2 KaController parameter list Para- Function Standard Min. Max. Unit Comment meter Address in Mod- t001 Serial address bus network Baud rate 0 = Baud rate 4800 t002 1 = Baud rate 9600... -
Page 48: Certificates
Katherm QK nano Assembly, installation and operating instructions Certificates EU-Konformitätserklärung EU Declaration of Conformity Déclaration de Conformité CE Deklaracja zgodności CE EU prohlášení o konformite KAMPMANN Wir (Name des Anbieters, Anschrift): GMBH & Co. KG Friedrich-Ebert-Str. 128-130 We (Supplier’s Name, Address):... - Page 49 Katherm QK nano Assembly, installation and operating instructions Gemäß den Bestimmungen der Richtlinien: Following the provisions of Directive: Conformément aux dispositions de Directive: Zgodnie z postanowieniami Dyrektywy: Odpovídající ustanovení směrnic: 2014/30/EU EMV-Richtlinie 2014/35/EU Niederspannungsrichtlinie Hendrik Kampmann Lingen (Ems), den 01.09.2020...
- Page 50 Katherm QK nano Assembly, installation and operating instructions Table Tab. 1 Limits of operation ..............................7 Tab. 2 Operating voltage ..............................7 Tab. 3 Water quality................................7 Tab. 4 Technical data for ..............................12 Tab. 5 Maximum electrical rating values ......................... 22 Tab.
- Page 52 Country Contact Kampmann UK Ltd. Dial House, Govett Avenue Shepperton, Middlesex, TW17 8AG T +44 1932/ 228592 Great Britain F +44 1932/ 228949 E info@kampmann.co.uk W Kampmann.co.uk...
