0608ME All Operation Manual

Manual No: 501089100002-EN

Manual Version: A

Jan. 2024

Translated version

Preface to 0608ME All Operation Manual

Operation

Manual

产品说明书

PRODU

C T MAN U AL

0608ME All/1932ME All

0608E (2132E)

G T JZ

0808E (2732E)

G T JZ

0808E (2732E)

G T JZ

0808E (2732E)

Table of Contents

Need help?

Do you have a question about the 0608ME All and is the answer not in the manual?

Questions and answers

Summary of Contents for Sinoboom 0608ME All

Page 1 0608ME All Operation Manual Operation Manual No: 501089100002-EN Manual Version: A Jan. 2024 Manual 产品说明书 Translated version Preface to 0608ME All Operation Manual PRODU C T MAN U AL 0608ME All/1932ME All 0608E (2132E) G T JZ 0808E (2732E) G T JZ...
Page 3 Operating, servicing and maintaining this vehicle or equipment can expose you to chemicals including engine exhaust, carbon monoxide, phthalates and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure and avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle or equipment in a well-ventilated area and wear gloves or wash your hands...
Page 4 Sales Tel:+86 400-601-5828/+86-0731-87116222 Service Tel:+86 400-608-1289/+86-0731-87116333 E-mail:info@sinoboom.com/sales@sinoboom.com Address: No.128, East Jinzhou Avenue, Ningxiang High-tech Industrial Park, Changsha, Hunan, China Postal code:410600 Copyright©Hunan Sinoboom Intelligent Equipment Co., Ltd. Hunan Sinoboom Intelligent Equipment Co., Ltd. retains the right of final interpretation of the manual.
Page 5 To Users Thank you for choosing and using the machinery of Hunan Sinoboom In- telligent Equipment Co., Ltd. Use this machine only to transport tools to work locations and for performing tasks on the work platform. Only authorized personnel who have received appropriate MEWP training may operate this machine.
Page 6 Manual Revision History: Version Date Description Original issue Jan. 2024...
Page 7 Imperial Trade Model Serial No. Name Name 0108900100 to present 0608ME All 0608ME All 1932ME All Note: • Check the machine model and serial number on the machine nameplate. The location of the name- plate can be found in the Decals Diagram section of the Operation Manual.
Page 9: Table Of Contents
Control System) ....33 Pre-delivery Inspection (PDI) ..54 © Jan. 2024 0608ME All Operation Manual...
Page 10 Maintenance ....55 Inspection and Preventive Mainte- nance Schedule ..... 55 © Jan. 2024 0608ME All Operation Manual...
Page 11: Safety Warning Symbols And Signs
Indicates an imminently hazardous situation that, if not avoided, could result in death or serious injury. Indicates an imminently hazardous situation that, if not avoided, could result in minor or moderate injury. NOTICE Indicates information directly or indirectly related to personal safety, machine damage, or property loss. © Jan. 2024 0608ME All Operation Manual...
Page 13 Lashing point Tire ground pressure flames/sparks flames/sparks Tool or weight Forklift pocket position Close the chassis Fast/high speed Slow/low speed door Platform load capacity Respective load capacity of main platform and platform extension © Jan. 2024 0608ME All Operation Manual...
Page 15: Important Safety Rules
Without the written permission of Hunan Sinoboom Intelligent Sinoboom cannot foresee all the potential hazards re- Equipment Co., Ltd., this machine shall not be used in lated to this machine, so all parties involved should place high importance on safety issues.
Page 16: Operation Safety
Functional test : Make sure that all functions of the machine are working properly. It is forbidden to alter or modify the machine without the written permission of Hunan Sinoboom Intelligent Equipment Co., Ltd. © Jan. 2024 0608ME All Operation Manual...
Page 17 • Never disassemble, modify or ret- rofit the machine or its parts. • Never disable any safety devices of the machine. • Never place objects on the plat- form guardrails. © Jan. 2024 0608ME All Operation Manual...
Page 18 Do not use the machine as a ground wire during welding and polishing operations. Table 2-1 Minimum Safe Distance Voltage Minimum safe (Phase to Phase, distance m (ft) 0-50 3 (9.8) 51-220 4 (13.1) 221-500 5 (16.4) © Jan. 2024 0608ME All Operation Manual...
Page 19 • Do not allow oil, sludge or other slippery substances to remain on work shoes and platform floor. • Keep the platform floor unobstructed. © Jan. 2024 0608ME All Operation Manual...
Page 20 In- forklifts, or other suitable creasing the windward area will equipment. lead to reduced machine stability. © Jan. 2024 0608ME All Operation Manual...
Page 21 47-54 If wind speed exceeds 12.5 m/s (28 mph) after the platform has been raised, the platform should be retracted immediately, all power sources should be disconnected, and the machine should be stopped. © Jan. 2024 0608ME All Operation Manual...
Page 22 • Understand braking distances at all travel speeds. When traveling at high speed reduce the travel speed before stopping. • Do not use the high speed setting when traveling in areas with © Jan. 2024 0608ME All Operation Manual...
Page 23: Towing, Hauling And Lifting
The machine can only be lifted from the specific position with lift- ing equipment with sufficient lift- ing capacity. Care should be taken to prevent the machine from col- liding with surrounding objects. © Jan. 2024 0608ME All Operation Manual...
Page 24: Maintenance Safety
Do not direct water or steam ejected from the flushing equip- ment at electrical components, as this may cause short-circuits or electrical shocks. • After maintenance is completed, thoroughly clean up any spilled © Jan. 2024 0608ME All Operation Manual...
Page 27 10%) or battery under-voltage caused by long-term non-charging (battery with level of less than 10% not charged for more than three days), resulting in battery capacity attenuation and failure, are not covered by the warranty. © Jan. 2024 0608ME All Operation Manual...
Page 29: Responsibilities Of Relevant Parties
3.3 TRAINER’S RESPONSIBILITIES • The trainer must be accredited by Sinoboom, have comprehensive knowledge training on the machine, and must have the required skills related to machine repair and maintenance. •...
Page 30 RESPONSIBILITIES OF RELEVANT PARTIES This Page Intentionally Left Blank © Jan. 2024 0608ME All Operation Manual...
Page 31: Technical Parameters
Platform dimensions (L×W×H) 1.64 m×0.76 m×1.1 m 5 ft 4.6 in×2 ft 6 in×3 ft 7 in AU&NZ platform dimensions (L×W×H) 1.64 m×0.76 m×0.96 m 5 ft 4.6 in×2 ft 6 in×3 ft 1.8 in © Jan. 2024 0608ME All Operation Manual...
Page 32 1543 lb Ground pressure 178 psi 1230 KPa Environment Maximum allowable lateral force (indoor/ 400 N/200 N 90 lbf/45 lbf outdoor) Maximum allowable wind speed (indoor/ 0 mph/28 mph 0 m/s/12.5 m/s outdoor) © Jan. 2024 0608ME All Operation Manual...
Page 33: Function Speed
Raise the platform: With the platform unloaded, raise the platform (with the scissor arms from fully retracted position to fully raised position). Perform this maneuver for two times. © Jan. 2024 0608ME All Operation Manual...
Page 35: Pre-Operation Inspection
A pre-operation inspection must be performed before each operation, before resuming operations, and before changing operators, as well as after each repair. Please carefully check each item according to the content of this section. © Jan. 2024 0608ME All Operation Manual...
Page 36: Basic Machine Components
PRE-OPERATION INSPECTION 5.1 BASIC MACHINE COMPONENTS Fig. 1 © Jan. 2024 0608ME All Operation Manual...
Page 37: Machine Positions
3. Operation Manual and Maintenance Manual – en- sure that the Operation Manual and Maintenance © Jan. 2024 0608ME All Operation Manual...
Page 38: Functional Test
1) Make sure that the screen is turned on and speed (if equipped with Sinoboom control shows no error message during the entire func- system).
Page 39 (if equipped with DTC speed for the raised position automatically. or Kuanhui control system). © Jan. 2024 0608ME All Operation Manual...
Page 41: Controllers And Indicators
Neutral/OFF position Platform control position Key switch Set the switch to neutral position: the machine will be powered (ground/platform control selector off. switch) © Jan. 2024 0608ME All Operation Manual...
Page 42 Platform Down key Control platform down function Platform Up key Control platform up function Enter key Enter the next interface of the ground display screen Down arrow key Scroll down the ground display © Jan. 2024 0608ME All Operation Manual...
Page 43: Platform Controller
CONTROLLERS AND INDICATORS 6.2 PLATFORM CONTROLLER (SINOBOOM CONTROL SYSTEM) Fig. 2 Platform Controller (Sinoboom Control System) Table 6-2 Description Name Move and hold the switch – all functions will be enabled to Enable switch operate. Left turn thumb button Press the button to steer the machine to the left.
Page 44 Display battery level, alarm message and fault codes. Lift/drive and steer function enable Move the switch up to enable platform lift/lower mode; switch Move the switch down to enable travel and steer mode. © Jan. 2024 0608ME All Operation Manual...
Page 45: Operation Instructions
2. Pull out the emergency stop button at the ground controller to the ON position. 3. Pull out the emergency stop button at the platform controller to the ON position. Uphill/downhill: 25 %/14 ° © Jan. 2024 0608ME All Operation Manual...
Page 46: Charging The Battery
0 °C; other- Indications wise the battery capacity will decay rapidly, and battery life will be affected. The battery level indication on the platform display is as follows: Charging lead-acid (maintenance required) batteries © Jan. 2024 0608ME All Operation Manual...
Page 47: Charger Led Description
For example: 24.0 (V). • A (charge current indicator light) represents the cur- rent charge current, the number indicates the current value. For example: 36.0 (A). © Jan. 2024 0608ME All Operation Manual...
Page 48: Traveling
Activating Drive and Steer Mode • Sinoboom Control System: Move the lift/drive and steer function enable switch down, the indicator under the switch will illuminate. The machine will en- ter drive and steer mode.
Page 49: Extending And Retracting
1 m (3 ft) from the machine. Folding Platform Fold down the platform guardrails: Fig. 2 © Jan. 2024 0608ME All Operation Manual...
Page 50 Fold the access gate inward. 4. Pull out the two wire rope safety pins at the rear of the platform, and fold the guardrails on both sides of the platform inward. © Jan. 2024 0608ME All Operation Manual...
Page 51: Turning Off And Stopping
1. Park the machine on a firm, flat, and level surface, 4. Pull out the two wire rope safety pins at the access and make sure the area is adequately protected. gate of the platform. Fold the access gate inward. © Jan. 2024 0608ME All Operation Manual...
Page 52: Transport And Lifting
2. The rigging equipment must be attached to the ma- parked on a horizontal surface or secured. chine’s specified lifting point. 8. The machine may only be lifted from a specific posi- tion with a forklift or crane with sufficient lifting © Jan. 2024 0608ME All Operation Manual...
Page 53 3. Lift the machine by 0.4 m (16 in) and then tilt the forks backward slightly to keep the machine stable. 4. Keep the machine horizontal when lowering the fork frame. © Jan. 2024 0608ME All Operation Manual...
Page 54: Storage
10. For a machine stored for more than one and a half years, a comprehensive inspection and mainte- nance on the machine should be carried out before use, aging seals and filter elements should be re- placed as appropriate. © Jan. 2024 0608ME All Operation Manual...
Page 55: Emergency Procedures
8.1 REPORTING ACCIDENTS emergency stop button to stop the machine. In case of any accident involving Hunan Sinoboom Intel- 8.3 EMERGENCY LOWERING ligent Equipment Co., Ltd. products, Hunan Sinoboom Intelligent Equipment Co., Ltd. must be notified immedi- ately.
Page 56: Emergency Towing
7. Reinstall the removed components and the brake must be parked on a horizontal surface or will operate effectively. secured. Method 2 (for Sinoboom Control System): Method 1: 1. Place the machine on firm, level ground and secure the wheels with chocks to prevent the machine from moving.
Page 57 10. After towing, place the machine on firm, level ground and secure the wheels with chocks to pre- vent the machine from moving. 11. Turn on the machine, so the brake can be operated properly. © Jan. 2024 0608ME All Operation Manual...
Page 63: Maintenance
Check each rim for damage, deformation or cracked choose not to use the replacement tires recommended welds. Replace the rim if necessary. by Hunan Sinoboom Intelligent Equipment Co., Ltd., the following specifications should be adhered to: Checking Wheel Nuts •...
Page 64: Replacing Tires
SCHEDULE Equipment Co., Ltd. recommends this task be per- formed by a factory-trained service technician, a person recognized by Sinoboom as one who, by qualification, This section provides safety and other vital information certificate and training, has successfully demonstrated for machine operators. To extend the service life of the...
Page 65 Schedule for items requiring a PDI. Refer to the corre- Preventive maintenance procedures shall be performed sponding section of this manual to perform inspection by qualified Sinoboom technicians. The frequency of the and maintenance procedures. inspection and maintenance must be increased as re-...
Page 66 1, 3, 4, 7, 10 1, 3, 4, 7, 10 1, 3, 4, 7, 10 Ground controller Function control lock, secondary 1, 3, 10 1, 3, 10 1, 3, 10 guarding device and brake © Jan. 2024 0608ME All Operation Manual...
Page 67 1, 2 1, 2 1, 2 and covers Greasing and lubricating according to specifications Functional test of all systems Paint and appearance Inspection date stamped on the chassis Notify Sinoboom of machine ownership (change) © Jan. 2024 0608ME All Operation Manual...
Page 68 5. Clean and free of foreign objects 6. Check for correct level, sealing and leaks 7. Labels complete, clear and secure 8. Check for appropriate dimensions/tolerances 9. Fully charged 10. Verify/perform 11. Correctly lubricated © Jan. 2024 0608ME All Operation Manual...
Page 71 For B et t er A ccess Solution s Alw ays For B et t er A ccess Solution s ess Solution s Always for Better Access Solutions Hunan Sinoboom Intelligent Equipment Co., Ltd. AS/N ZS 长沙市宁乡高新技术产业园区金洲大道东 128 号...
