- Page 1 ASUS ROG STRIX SCAR 17 (G733P) series Service Guide...
- Page 2 LIMITATION OF LIABILITY Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property;...
- Page 3 Disclaimer ASUS is not responsible for direct, indirect, intentional or unintentional damages resulting from improper installation and operation. Safety precautions • Keep liquids or moisture away from your Notebook PC before installing or removing any components. • Ensure to place your Notebook PC on a stable surface before installing or removing any components.
-
Page 4: Table Of Contents
Table of Contents ⚫ Service Overview ⚫ ROG STRIX SCAR 17(G733P) Overview ⚫ Components Top View ⚫ Components Bottom View ⚫ Repair Overview ⚫ Appropriate Tools ⚫ Key parts and Related Parts ⚫ Disassembly steps : • BOTTOM CASE •... -
Page 5: Service Overview
Service Overview • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs. • To provide the best service, we have provided the below information for technicians from distributors and resellers to perform the complete device disassembly and assembly. -
Page 6: Rog Strix Scar 17(G733P) Overview
ROG STRIX SCAR 17(G733P) Overview Top View Bottom View ❶ Air vents ❷ Audio speakers ❸ Bottom cover ❶ Array microphones ❷ Camera indicator ❸ Camera ❹ Display panel ❺ Status indicators ❻ Capital lock Right View ❶ Air vents indicators ❼... -
Page 7: Components Top View
Components Top View ⧫ LCD COVER MODULE ⧫ 17‘ LCD ⧫ CPU FAN ⧫ MB ⧫ DDR ⧫ BATTERY CABLE ⧫ WEBCAM FPC+CABLE ⧫ TP PCB TAPE NUMPAD ⧫ LCD BEZEL ⧫ THERMAL MODULE ⧫ VGA FAN ⧫ INDICATOR BD ⧫... -
Page 8: Components Bottom View
Components Bottom View LCD COVER MODULE KEYBOARD MODULE MAIN BOARD KB BRKT LED BD CONDUCTIVE TAPE LCD CAMERA GASKET LCD BEZEL BASE CASE INDICATOR BOARD ANTENNA TP MODULE GND CONDUCTIVE TAPE ANTENNA CABLE ACETATE CLOTH MAIN LCD PANEL THERMAL MODULE ASSY LCD BEZEL ADHESIVE LCD PANEL ADHESIVE LCD BEZEL ADHESIVE UP... -
Page 9: Repair Overview
Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1. -
Page 10: Appropriate Tools
Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ROG STRIX SCAR 17(G733P) series notebook. Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade PLASTIC PICK T=0.5mm Thermal Pad PTM7958 PLASTIC CARD T=0.35mm... - Page 11 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ROG STRIX SCAR 17(G733P) series notebook. ❾ ❼ ❺ ❸ ❶ ❽ ❻ ❷ ❹ Item Part Name Memo ❶ Silicone scraping pen Please store it in the environment of 10 ~ 40 ℃.
-
Page 12: Bottom Case
BOTTOM CASE The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Screws Spec Torque (kgf-cm) Step 1 : Remove screws *10pcs. Step 2 : Use plastic blade to pry the bottom case. M2.5*12L(4.2,0.8)(K) #1 2.5±0.2 Step 3 : Disconnect LED R and LED L connector, then remove the bottom case. -
Page 13: Bottom Case(With Led Bd)
BOTTOM CASE (WITH LED BD) The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Remove screws *2pcs and LED module. Screws Spec Torque (kgf-cm) Step 2 : Disconnect LED BD FFC *2pcs. M2*3.5L(4,0.8) (K)#1 2.0±0.2 Unscrew... -
Page 14: Disconnect Battery Connector
DISCONNECT BATTERY CONNECTOR Disassembly Notice The device has an Ambient Light Sensor (ALS) for power-off protection Function. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to avoid IC damage. Assembly Notice Step 1 : Disconnect the battery connector. -
Page 15: Ssd
The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Remove the SSD screws *2pcs, then remove the SSD *2pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove the THERAML PAD *1pc from top side SSD. M2*2.5L (5,0.8) (K) #1 2.0±0.2 Step 3 : Tear off the Graphite from SSD *2pcs. - Page 16 The device has an Ambient Light Sensor (ALS) for power-off protection Function. Assembly Notice Please use this SSD1 slot as first priority. For New SSD assembly: Please follow the steps below. Step 1: Paste the Graphite on the SSD. (Graphite sheet don’t reuse.) Turn and Paste Paste Align...
-
Page 17: Ddr
The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Tear off DDR Absorber *2pcs. Assembly Notice Assembly Notice Step 2 : Unlock DDR. Step 3 : Remove DDR. Please check and remove the spec label from the For New RAM Module assembly, please follow the steps below. -
Page 18: Battery
BATTERY The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Remove screws *4pcs and BATTERY. Step 2 : Remove BATTERY Cable. Screws Spec Torque(kgf-cm) M2.0*3.5L(4,0.8) (K)#1 2.0±0.2 Remove Unscrew Back... -
Page 19: Wifi Card
WIFI CARD The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Disconnect the RF CABLE connector *2pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove the screw *1pc. M2*2.5L (5,0.5) (K) #1 2.0±0.2 Step 3 : Remove WIFI CARD. -
Page 20: Speaker
SPEAKER The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Release the tape *2pcs. Step 2 : Disconnect the SPEAKER connector. Assembly Notice Step 3 : Remove SPEAKER. For Speaker assembly, please follow the mark below to tidy cable. Release Remove Disconnect... -
Page 21: Fan
The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Disconnect the connector on the CPU FAN. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *3pcs on the CPU FAN. M2*4.5L (4.5,0.8) (K) #1 2.0±0.2 Step 3 : Remove the CPU FAN. -
Page 22: Thermal Module(With Mb)
THERMAL MODULE(with MB) The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Screws Spec Torque (kgf-cm) Step 1 : Disconnect (yellow mark) connector. M2*3.5L (4,0.8) (K) W-NI 2.0±0.2 Step 2 : Release TYPE C CONDUCTIVE TAPE *2pcs(blue mark). Step 3 : Remove screws *8pcs (green mark) and remove Thermal module (with MB). -
Page 23: Main Board
MAIN BOARD Mainboard connector placement CPU FAN GPU FAN ANTENNA EDP CABLE KB FPC Supports using JIG BOARD to refresh F1 BIOS. SPEAKER TP FFC KB FFC INDICATOR BD FFC BATTERY Back... - Page 24 MAIN BOARD Materials on mainboard Parts marked in yellow can be ordered/replaced separately at L2 repair level. When L3/L4 repair finished, no need to paste new one if shortage of this material on the MB. G513QY GPU BKT ASSY G733PY GPU ABSORBER G513QC HDMI GASKET G733PY TYPE C AL-MYLAR G733CX CPU BKT ASSY...
-
Page 25: Indicator Bd
INDICATOR BD The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Disconnect and remove the LED FFC. Step 2 : Release KB BRKT LED BD CONDUCTIVE TAPE *2pcs. Assembly Notice Step 3 : Pry and remove the INDICATOR BD. Step 4 : Disconnect and remove the KB BL FFC. -
Page 26: Touchpad Module
TOUCHPAD MODULE The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Disconnect and remove TP FFC. Assembly Notice Step 2 : Tear off the TP MODULE GND CONDUCTIVE TAPE. Step 3 : Remove screws*3pcs. For New TOUCHPAD Module assembly, please follow the steps below. -
Page 27: Keyboard Module
KEYBOARD MODULE The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Remove the screws *4pcs. Screws Spec Torque (kgf-cm) Step 2 : Turn over the device, then pry the TOP HIGNE COVER to remove it. M2.5*4.5L(4.5,0.8) (K)#1 2.5±0.2 Step 3 : Remove the screws *6pcs. -
Page 28: Lcd Bezel
LCD BEZEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Remove LCD BEZEL. Assembly Notice Start from the bottom right corner of the bezel, using the Plastic Blade to pry open bezel. When reuse the LCD BEZEL: Please paste new LCD BEZEL ADHESIVE before assembly BEZEL. -
Page 29: Lcd Panel
LCD PANEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *8pcs, then remove right hinge. Step 2 : Unlock hinge cap hook, then remove left hinge. Screws Spec Torque (kgf-cm) Step 3 : Pull out LCD adhesive *2pcs. - Page 30 LCD PANEL The device has an Ambient Light Sensor (ALS) for power-off protection Function. Assembly Notice Before assembly L HINGE, please follow the steps to tidy up EDP cable, hinge cap When reuse the LCD PANEL: and L HINGE. Please use the fingertip to clean the residual glue on PANEL or BEZEL. Align and assembly HINGE CAP Assembly and align the LCD to the upper side of the LCD Cover.
-
Page 31: Lcd Cover(With Camera)
LCD COVER(WITH CAMERA) The device has an Ambient Light Sensor (ALS) for power-off protection Function. Disassembly Notice Step 1 : Disconnect the WEBCAM FPC+CABLE then separate EDP cable and WEBCAM FPC+CABLE. Assembly Notice Step 2 : Tear off gasket then remove the camera module. Step 3 : Remove camera sponge *2pcs.
