2.2 Using USB/eSATA Enclosures or External Drives

When using drives that came from a USB, or eSATA enclosure, or external drives, it is highly
recommended to leave the drive inside the enclosure. USB enclosures typically have an on-
board controller that may be necessary to read the drive properly. Taking the drive out of the
enclosure could cause any device (including computers) not to read the drive contents properly.

2.3 LEDs

The WriteProtect-PORTABLE has several LEDs:
DRIVE LEDs (USB 3.0, PCIe, SATA) –
•
On – Detects a drive connected on the corresponding port
•
Blinking – Detects activity on the corresponding port
•
Off - No drive is detected on the corresponding port
HOST –
Detects a link connection between the WriteProtect and the host computer
•
On – Detects an active link between the WriteProtect and host computer
•
Off – There is no active link between the WriteProtect and host computer
HPA/DCO –
HPA and/or DCO detection
•
On – Detects the presence of an HPA and/or DCO on the connected drive
•
Off – Does not detect the presence of an HPA and/or DCO on the connected drive
POWER –
Power LED
•
On – The WriteProtect is powered on
•
Blinking – This LED will blink while the WriteProtect is being turned ON or OFF
•
Off - The WriteProtect is turned off
