F&F MR-RO-1 Manual

Relay outputs expansion module with modbus rtu output

Advertisement

MR-RO-1
Relay outputs
expansion module
with Modbus RTU output
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collec� on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.
Purpose
The MR-RO-1 module is used as an external device that extends re-
lay outputs of the PLC programmable controllers or other devices
in which data is exchanged via the RS-485 port with Modbus RTU
protocol.
Functions
» 1×NO/NC separated contact;
» ON/OFF control;
» Output status;
» Timer control options:
– delayed activation;
– delayed activation for a preset time;
– cyclic operation ON/OFF;
– cyclic operation OFF/ON;
» State memory state after power outage;
» Automatic start for time function;
» Time of the last output switching;
» Number output switching
» Number of executed cycles for time functions.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MR-RO-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for F&F MR-RO-1

  • Page 1 Electro thrown in the trash or abandoned in nature, pose a threat to the environment and human health. Purpose The MR-RO-1 module is used as an external device that extends re- lay outputs of the PLC programmable controllers or other devices in which data is exchanged via the RS-485 port with Modbus RTU protocol.
  • Page 2: Working Modes

    Functioning The MR-RO-1 module is equipped with a controllable relay output (separated contact). The output operates according to the preset mode of operation and parameters assigned to it. The setting and reading the output status, operation parameters and adjustment of all communication and data exchange parameters is carried out via RS-485 port using Modbus RTU communication protocol.
  • Page 3 Another ON command received at the time T1 or when the relay is already switched on will be ignored. Mode 2. Activation for a preset time The relay activates after receiving the ON command, and deac- tivates when the preset time is up. Next cycle can be initiated by sending the next ON command.
  • Page 4 Mode 4. OFF/ON cycle Cyclic operations OUT OFF (relay off) for the time T1 and OUT ON (relay on) for the time T2. The cycle is started by sending the ON command. The number of executed cycles depends on the 0x235 registry value.
  • Page 5 off. Sending the OFF command during the cycle breaks its execu- tion and turns off the relay. The ON command received during cycle execution will be ignored. After the programmed number of cycles the next ON command starts the program from the beginning.
  • Page 6: Terminals Description

    Terminals description module supply – power supply (+) – power supply (–) RS-485 port – serial port (A) – serial port (B) relay output 10 – NC contact 11 – COM contact 12 – NO contact Device description – powerr supply –...
  • Page 7 Mounting Recommended use of interference and surge filters (e.g. OP-230 from the F&F offer). It is recommended to use shielded twisted-pair cables to connect the module to another device. When using shielded cables, ground the screens only on one side and as close to the device as possible. The ends of the signal line should be terminated with termination modules (e.g.
  • Page 8: Wiring Diagram

    4. Connect the module’s power supply to terminals 1(+) and 3(–) as marked. 5. Connect signal output 4(A) and 6(B) RS-485 port to the Master output. 6. Connect the 11-12 contact in series into power circuit of the controlled receiver. Wiring diagram Implementation of communication connections accor- ding to RS-485 standard specification.
  • Page 9 Connection implementation Activation with normally open contact (active) Communication settings reset A configuration jumper is available under the module casing. Starting the controller with the jumper closed restores the factory settings of the communication parameters. To do this, remove the casing of the module and put the jumper on both pins.
  • Page 10: Technical Data

    MB Config service software Service program for quick configuration of the device. The program is available on the appliance sub-page or under the "Downloads" tab on the website: www.fif.com.pl. Technical data power supply 9÷30 V DC maximum load current (AC-1) 16 A contact separated 1×NO/NC...
  • Page 11 CE declaration F&F Filipowski L.P. declares that the device is in conformity with the essential requirements of the Low Voltage Directive (LVD) 2014/35/ EU and the Electromagnetic Compatibility (EMC) Directive 2014/30/ The CE and MID Declaration of Conformity, along with the references to the standards in relation to which conformity is declared, can be found at www.fif.com.pl from the product subpage.
  • Page 12 Communication parameters (cont.) Max. frequency of 15 Hz queries Communication registers address description func. type atr. Reading of current one and recording of new base address: 1÷245 Reading of current one and recording of new transmission rate: 0:1200 / 1:2400 / 2:4800 / 3:9600 / 4:19200 / 5:38400 / 6:57600 / 7:115200 Reading of current one and...
  • Page 13 Communication registers (cont.) address description func. type atr. 1026 Serial number: ÷ R1026×256²+R1027 1027 Production date: 1028 5 bits – day; 4 bits – month; 7 bits – year (without 2000) 1029 Software version 1031 Identifier: ÷ F& | F | MB | 1 | RO 1035 Configuration jumper: 1039...
  • Page 14 Configuration registers (cont.) address description func. type atr. Out1: F1 multiplier 0: ×0.1 (T1: 0.1÷6553.5 s) 1: ×1 (T1: 1÷65535 s) Out1: V2 time base (1÷65535) T2 time = V2 × F2 Out1: F2 multiplier 0: ×0.1 (T2: 0.1÷6553.5 s) 1: ×1 (T2: 1÷65535 s) Out1: number of ON/OFF cycles for modes 4 and 5...
  • Page 15 Outputs registers address description func. type atr. Out1: Recording of the output state ON/OFF Entering 1 (command ON) executes the program depen- dent on the selected operating mode. Entering 0 (command OFF) breaks the execution of the selected program and opens the contact.
  • Page 16 Outputs registers (cont.) address description func. type atr. Note! Total time and number of contact switching are not retained after power failure. Configuration parameters (factory settings) Operation mode 0 (ON/OFF) V1 – T1 time base F1 – T1 multiplier V2 – T2 time base F2 –...
