CDN DTL572-G Manual

FOR THIN CUTS OF MEAT AND
GENERAL PURPOSE COOKING
• NSF Certified
®
• 4-second response
• Waterproof (IPX7)
• One-button field calibration
• 1.5 mm thin tip
• Accuracy: ±1.3°F (0.72°C)
• Hold
• Max/min
• High heat
• Big digit
• On/off button
• Auto-off
• Selectable units
• BioCote antimicrobial
®
• Temperature guide
• Sheath can be used as handle extension
• 4.3" (11.0 cm) stem
• Mounting: pocket clip
• Batteries & instructions included
Note: Remove label from display before initial use.
Clean the thermometer stem before each use.
Tel 800 338-5594 Fax 800 879-2364 Web CDNmeasurement.com
LOLLIPOP THERMOMETER
Note:
In the following instructions, names of the control
buttons are shown in CAPS. Function information that
appears on the display is shown in
BATTERY INSTALLATION
Replace batteries when LCD becomes dim.
"---" flashes on the display when the batteries need
to be replaced.
1. Power off the unit before installing the batteries.
A malfunction may occur if the power is on when
the batteries are installed. If a malfunction occurs,
restart the device.
2. Remove battery cover on the back with a coin.
3. Remove the cover completely.
4. Install two LR44 batteries with positive (+) sides up.
5. Replace the battery cover.
Important: THE WATER RESISTANT FEATURE REQUIRES
MAINTAINING THE RUBBER GASKET EVENLY WITHIN THE
GROOVE.
WARNING
• INGESTION HAZARD: DEATH or serious injury
can occur if ingested.
• A swallowed button cell or coin battery can
cause Internal Chemical Burns in as little as
2 hours.
• KEEP new and used batteries OUT OF REACH
OF CHILDREN
• Seek immediate medical attention if a
battery is suspected to be swallowed or
inserted inside any part of the body.
• For treatment information call: [phone number
for the National Battery Ingestion Hotline,
currently 1-(800) 498-8666].
• Remove and immediately recycle or dispose of
used batteries according to local regulations and keep
away from children. Do NOT dispose of batteries in
household trash or incinerate.
• Even used batteries may cause severe injury or death.
• Call a local poison control center for treatment
information.
• The compatible battery type is LR44.
• The nominal battery voltage of the LR44 is 1.5V.
• Non-rechargeable batteries are not to be recharged.
• Do not force discharge, recharge, disassemble,
heat above 104°F (40°C) or incinerate.
Doing so may result in injury due to
venting, leakage or explosion resulting in
Model: DTL572
-40 to +572°F/-40 to +300°C
BOLD CAPS.
