To reset the selected auxiliary meter to zero, select its
value on the meter and then press and hold the RESET
button for 3 sec.
Selected
parameter

Pulse output

The indicator has a SO+ SO- pulse output. This allows you to con-
nect another pulse device (SO) that reads impulses generated by
the meter. The number of pulses depends on the total energy
increment, with 1.000 pulses for each kWh of energy. No ad-
ditional device is required for the correct operation of the meter.
Sealing
The meter has the option of sealing the input and output termi-
nals, preventing the meter from being bypassed.
Press button
for 3 sec
- 4 -
Reset
meter
