Baxton Studio BBT 61296 Assembly Instructions

MODEL : BBT 61296 QUEEN BED
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
Tool needed : Screwdriver (not provider).
STEP 1
ASSEMBLY INSTRUCTIONS
A
G
B
H
PART LIST
QTY
ITEM DESCRIPTION BOX
A
HEADBOARD 1 1 PC
B
FOOTBOARD 2 1 PC
C SIDE RAIL 2 2 PCS
D
CENTER RAIL 2 1 PC
E
CENTER SUPPORT LEG 2 3 PCS
F BED SLAT 3 1 SET
G
HEADBOARD LEG 2 2 PCS
H
FOOTBOARD LEG 2 2 PCS
STEP 2
1
2
5
HARDWARE LIST (BOX : 2)
ITEM DESCRIPTION
1 JCBC BOLT M6 x 80mm
2 JCBC BOLT M6 x 100mm
3 WOOD SCREW M4 x 38mm
4 WOOD SCREW M4 x 20mm
5 M4 ALLEN KEY (BALL SHAPE)
6 M5 ALLEN KEY (BALL SHAPE)
A
B
1 of 3
QTY
4 PCS
4 PCS
9 PCS
2 PCS
1 PC
1 PC
