Summary of Contents for TESmart HKS202 Master 24
- Page 1 User HDMI 2 . 1 KVM Switch Manual HKS202 Master 24 HKS202 Master 24 English...
- Page 3 English...
-
Page 4: Copyright Notice
The ownership of the trade names and brand names adopted in this user manual belongs to their companies. Product Information For more information about TESmart products and how they can help you to enjoy your job, please visit the following TESmart website or contact an TESmart Authorized Reseller. www.tesmart.com... -
Page 5: Table Of Contents
Contents 1. Safety Tips and Warnings ··································01 9.3 Built-in Network Switch 2. Battery Description···········································02 9.4 Mouse Wheel Switching 3. Warranty Information········································03 Operation Method ···········································23 4. Preface··························································04 10.1 Front Panel Button Switching Method 5. Features·························································05 10.2 IR Remote Control 6. Packing List·····················································06 10.3 Keyboard Hot Keys 7. -
Page 6: Safety Tips And Warnings
1. Safety Tips and Warnings Tips: Please read the safety tips and warnings for HDMI KVM Switch comprehensively before use. Use this produce in accordance with its instructions, safety tips and warnings to prevent unnecessary damage to the product and potential dangers to users. Keep the product away from water. -
Page 7: Battery Description
2. Battery Description Tips: By default, the remote control is not equipped with batteries, due to the safety requirements of some express companies. Install AAA dry cells before use. Caution: Improper disposal of the lithium battery may cause an explosion. Do not throw the battery into fire. -
Page 8: Warranty Information
3. Warranty Information We warrant this product as free of defects in material and workmanship for a period of one (1) year from the date of shipment. If during the period of warranty this product proves defective under normal use, we will repair or replace this product, provided that this product has not been subjected to mechanical, electrical, or other abuse or modifications. -
Page 9: Preface
RGB lighting becomes a unique spectacle on your desk. Tips: If you need to control more computers or conduct more complex and professional switching, you can also choose other products of our company. For more details, please visit our official website: www.tesmart.com. -
Page 10: Features
5. Features Using 2 monitors, 1 set of keyboard and mouse to control 2 computers Ÿ HDMI 2.1 compliant, has 48Gbps ultra-high speed bandwidth and also support VRR, FVA and ALLM Ÿ Support resolution up to 8K(4320p)@60Hz 4:4:4 and is backward compatible with Ÿ... -
Page 11: Packing List
6. Packing List 1 * 2x2 HDMI 2.1 Dual Monitor KVM Switch Ÿ 2 * KVM Cables Ÿ 2 * HDMI Cables Ÿ 1 * IR Remote Control Ÿ 1 * DC 12V Power Adapter Ÿ 1 * User Manual Ÿ... -
Page 12: Panel Description
7. Panel Description Name Function 3.5mm audio/mic Integrated microphone and L/R audio output. USB 3.2 Gen 1 ports Connect to USB 3.0 device. Keyboard and mouse input For USB keyboard and mouse input. Display status indicators Display the current output status of each monitor. - Page 13 Name Function Audio and USB 3.0 indicator Indicate the current path of audio and USB 3.0. Input selection button Press to switch input sources. Power switch Press for about 2 seconds to turn on or turn off power supply. Features 4 lighting modes to match your atmosphere Please refer to RGB LED stirp page 30 for how to switch different modes.
- Page 14 Name Function DC 12V 12V DC power supply. Insert the network cable into this port to let the 2 input PCs to connect LAN port to the local network area. Support external UART commands for channel switch and functionality UART command interface control.
- Page 15 Name Function HDMI outputs Connect to 2 HDMI displays for video output. 2 PCs can be connected to the KVM at the same time. KVM input ports group Each group contains 2 HDMI ports(marked as Input 1/2) and a USB port.
-
Page 16: Connection Description
8. Connection Description 8.1 Connection Diagram Keyboard Mouse Monitor 2 Monitor 1 USB Type-A to B Cable Router HDMI Cable Hard disk Headset drive Driver Ethernet Switch PC 2 PC 1 Tips: For your better experience, please use an HDMI 2.1 cable to connect to the display. -
Page 17: Connection Preparation
8.2 Connection Preparation Take into consideration all devices required to be connected and prepare a workbench large Ÿ enough before the connection. Lay out the cables properly to facilitate the layout of power supply as a lot of power sockets Ÿ... -
Page 18: Connection Steps
8.3 Connection Steps 1. Connect PC 1 with 1 HDMI cable and 1 KVM cable. 2. Connect PC 2 with the same method. 3. Connect KVM's HDMI output ports to 2 HDMI displays with 2 HDMI cables. - Page 19 4. Use 1 network cable, one end is connected to the RJ45 port, the other end is connected to a switch or a router. 5. Connect external mouse and keyboard to KVM's keyboard and mouse input port. Tips: For the normal service of hotkeys, we recommend you use the full-key external keyboard with a separate [Scroll Lock] key (as shown above...
- Page 20 6. Connect USB 3.0 devices to KVM's standard USB 3.0 ports. 7. Connect external audio device to KVM's L/R out port.
- Page 21 8. Connect the power cable to KVM's DC 12V port and plug it to a power socket. 9. By now, the connection has been completed. Turn on the power supply and the KVM Switch will begin to work. Tips: 1. By default, the network cable is not included in the package. 2.
-
Page 22: Kvm Workbench
8.4 KVM Workbench A workbench with 2x2 dual monitor KVM Switch successfully connected is shown as below:... -
Page 23: Function Description
9. Function Description 9.1 Display Mode Description The 2x2 HDMI 2.1 dual monitor KVM Switch support 2 display modes. You can choose to implement 2-screen extended display or duplicate display or display different PCs on 2 monitors. Display Mode 1: Display the same PC Duplicate displays Extend displays Display A... - Page 24 Display Mode 2: Display the different PCs Display A Display B PC 1 PC 2 In this mode, you can show one PC on any two monitors connected to the KVM and the other PC on the remaining monitor. Use the front panel, hotkeys, or IR control to switch between PCs and monitors.
-
Page 25: Keyboard And Mouse Emulation Mode
9.2 Keyboard and Mouse Emulation Mode We provide two keyboard and mouse modes: Pass Through Mode and Legacy Emulation Mode. Pass Through mode supports most keyboard and mouse drivers and multifunction keyboards and mice. Legacy Emulation Mode ensures the normal functioning of the keyboard, mouse, and hotkey features. -
Page 26: Built-In Network Switch
9.3 Built-in Network Switch The 2x2 KVM Switch have a built-in USB Ethernet Adapter, which adds a standard RJ45 port to all the PC that is connected to the KVM and allows you to connect your computers to a router or network switch for gigabit wired network connection. Full 1000Mbps Ethernet for fast, stable data transfer, more reliable than most wireless connections. -
Page 27: Mouse Wheel Switching
9.4 Mouse Wheel Switching Mouse wheel switching method can quickly switch input sources by mouse operation, double-click the mouse wheel to switch to the next input port. Mouse wheel switching mode is off by default. You can use keyboard hotkey command to turn on mouse wheel switching mode. -
Page 28: Operation Method
10. Operation Method 10.1 Front Panel Button Switching Method The 2x2 KVM Switch can switch to any input devices at any time with front panel keypad, IR remote control and keyboard hot keys. You can choose your favorite switching method according to your personal needs and habits. -
Page 29: Ir Remote Control
10.2 IR Remote Control —— Press directly to select among 2 PCs, and 2 displays will display the selected PC at the same time. (i.e. display mode 1) —— Press the key, and then press the [1~2] key to make the selected monitor display the selected PC. -
Page 30: Keyboard Hot Keys
10.3 Keyboard Hot Keys Use external keyboard hot keys to switch the input source or set up some other functions.. à Tips: The keyboard hot keys can only work with external keyboard correctly connected to the keyboard [Right-Ctrl]. and mouse input port of the KVM. The default hot key trigger key is After press [Right-Ctrl] key twice within 2 seconds and you will hear the buzzer beep once, please enter the commands within 3 seconds and the KVM will execute the corresponding commands. - Page 31 Switch PCs on different monitors separately(i.e. display mode 2): Monitor 1：[Right-Ctrl] → [Right-Ctrl] → [←] Right Right ← Ctrl Ctrl Monitor 2：[Right-Ctrl] → [Right-Ctrl] → [→] Right Right → Ctrl Ctrl Switch keyboard and mouse focus in display mode 2: [Right-Alt] →...
- Page 32 Disable/enable follow mode: Tips: "Follow Mode" refers to whether the audio devices and USB 3.0 devices connected to the front panel will switch synchronously with the keyboard and mouse focus when switching. [Right-Ctrl] →[Right-Ctrl] →[~] Right Right Ctrl Ctrl Tips: The default setting of follow mode is enabled. When you disable it, the buzzer will emit only 1 short beep;...
- Page 33 Disable/enable fan: Right Right Ctrl Ctrl [Right-Ctrl] →[Right-Ctrl] →[F3] Tips: The fan has 4 adjustable modes, distinguishable by the number of beeps from the buzzer. The default fan mode is 2. Fan mode 1: The fan is disabled. Adjust to this mode, the buzzer will beep once. Fan mode 2: The fan speed is automatic.
- Page 34 Turn on/off mouse wheel switching mode: Right Right [Right-Ctrl] →[Right-Ctrl] →[F6] Ctrl Ctrl Tips: Turning on the mouse wheel switching mode will trigger the buzzer to beep twice and turning it off will trigger the buzzer to beep once. Disable or enable buzzer sound: Right Right [Right-Ctrl]...
- Page 35 Switch lighting modes: Turn off lighting: [Right-Ctrl] → [Right-Ctrl] → [L] → [0] Right Right Ctrl Ctrl Light effects vary with KVM indicators: [Right-Ctrl] → [Right-Ctrl] → [L] → [1] Right Right Ctrl Ctrl Marquee lighting effect: [Right-Ctrl] → [Right-Ctrl] → [L] → [2] Right Right Ctrl...
-
Page 36: Change Hot Key Combination
11. Change Hot Key Combinations For your convenience, we have built-in a custom hotkey function. By setting, you can use any key on the keyboard connected to the KVM as the trigger key for the hot key command. The default hotkey trigger key is the [Right-CTRL]. The custom hotkey function can be set in the following ways: Method 1: After powering on the KVM, press and keep holding the [... -
Page 37: Uart Command Description
12. UART Command Description The 2x2 HDMI 2.1 dual-monitor KVM Switch is equipped with a UART command interface, allowing users to communicate with the KVM using UART (Universal Asynchronous Receiver- Transmitter) commands. Command Function Configuration AA BB 03 00 00 EE Switch to PC1. - Page 38 Command Function AA BB 04 02 Disable or enable buzzer sound. （ can be any value.） AA BB 05 02 00 EE Disable RGB LED strip. AA BB 05 02 01 EE Switch the RGB LED strip lighting effects to vary with KVM indicators. AA BB 05 02 02 EE Switch the RGB LED strip lighting effects to marquee.
- Page 39 V002...
- Page 40 To Enjoy Smart HKS202 Master 24 Tesla Elec Technology Co.,Ltd WEEE-Reg.-Nr. DE 66784279...
