E
Operating Instructions and Spare parts list
EASY 1-S
Powder Coating Equipment
for Boron Nitride
This equipment was developed for use with electrically
non-conducting powders. The use of electrically con-
ducting powders (like metallic or graphite powders) can
cause a permanent decrease of functioning
EASY 1-S / EASY 2-S for Boron Nitride

Advertisement

loading
Need help?

Need help?

Do you have a question about the EASY 1-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ITW Gema EASY 1-S

Summary of Contents for ITW Gema EASY 1-S

  • Page 1 Boron Nitride This equipment was developed for use with electrically non-conducting powders. The use of electrically con- ducting powders (like metallic or graphite powders) can cause a permanent decrease of functioning EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 2 EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 3 5 ... 10 bar 73...145 PSI Adapter connection (for 1.1 IN OptiGun 1-A Automatic powder gun only). Mains connection 2.3 Output for Vibrator (EASY 1-B only) and Stirrer control (EASY 1-S only ) Grounding connection EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 5 2c Clean the coating equipment, see Point 1b 3c Turn off the main compressed air supply Stirrer arm Brush - viewed from above Direction of rotation Drehrichtung Bürste Brush Rührgestänge Pulverbehälterwand Stirrer arm Powder hopper wall Clamp screw Klemmschraube EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 6 5. Clean the powder gun tube with the spiral brush supplied. 6. Blow the powder gun through with compressed air again. 7. Clean the powder hose. 8. Assemble the powder gun and reconnect. EASY 1-S / EASY 2-S for Boron Nitride...

  • Page 7: Troubleshooting Guide

    - Control unit is not con- the unit illuminate, in spite of the nected to the Mains. control unit being switched In the equipment: Replace - Bulb burnt out. - Power pack defect Replace (continued) EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 8 - Motor switch is not Stirrer does not work Switch on switched on - Stirrer not connected to Check power supply - Fuse defect Replace - Control unit cable not Plug in plugged in EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 9 EASY 1-S Pneumatic diagram EasyTronic Supplementary air Conveying air Electrode rinsing air 3-10 l/min. Injector S1 = Rinsing air unit M1 = Motor throttle E1 = Input unit Figure 5 EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 10 Wiring Diagram Solenoid valve - Fluidizing air Main solenoid valve Solenoid valve - Round jet nozzle Solenoid valve - Flat jet nozzle Supplementary air Conveying air Figure 6 EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 11 Wir ing diagram for the stirrer motor (CBS control board) Stirrer motor Stirrer motor ON/OFF Option:Ccover tilt switch Not connected EasyTronic Control unit Option: Fluidizing valve Mains ON Power supply 110 or 240 VAC Figure 7 EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 12 Notes: EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 13 All dimensions for plastic powder hoses are given as external diam- eter (o/d) and internal diameter (i/d): e. g. ø 8 / 6 mm, 8 mm outside diameter / 6 mm inside diameter (i/d). EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 14 Shake-proof nut - M6 mm 244 430 Hex. Nut - M4 mm 205 192 Stirrer control unit - see page 22 Spring washer - M4 mm 205 680 * Indicate length required # Wear parts EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 15 EASY 1-S powder coating equipment 78; 93; 97 6; 91 45; 73; 90 4; 29 71; 90 3; 91 40; 71 41; 70 Figure 8 EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 16 Hex. Screw - M6 x 30 mm 216 445 Cap nut - M6 mm 221 147 Seger ring - A-08 226 653 Injector holder 380 288 Brush 377 660 Guide ring 380 318# * Indicate length required EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 17 Stirrer / Powder hopper 3; 25; 26 23; 24 17; 18 27; 28 Figure 9 EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 18 Plug screw - PG7 MS 263 656 Mains cable - Easy 1-S (2 plugs) 378 992 Mains cable - Easy 2-S (3 plugs) 379 018 # Wear parts * Indicate length required EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 19 Stirrer motor control unit 13; 14 17; 18 Figure 10 EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 20 External air input unit Adapter - 1/4"-1/4" 256 269 Compressed air connection - 1/4"-1/4" 256 277 Air connection adapter - 1/4" for Easy 1-S 237 221 Air connection adapter - 1/4" for Easy 2-S 227 838 Air connection ring - ø 8 mm-1/4"...
  • Page 21 External air input unit Easy 1-S Easy 2-S Figure 11 EASY 1-S / EASY 2-S for Boron Nitride...
  • Page 22 To the best of our knowledge and belief, the information contained in this publication was correct and valid on the date of issue. ITW Gema AG makes no representations or warranties with respect to the contents or use of this publication, and reserves the right to revise this publication and make changes to its content without prior notice.
