INSTALLATION & USER MANUAL
FOR GAS WOK RANGE
MODELS: PT-WOK & PT-WOK-16
IMPORTANT FOR YOUR SAFETY
P LEASE READ THIS MANUAL COMPLETELY BRFORE ATTEMPTING TO INSTALL OR OPERATE
THE WOK RANG. THIS MANUAL HAS BEEN PREP ARED FOR PERSONNEL QUALIFIED TO INSTALL
GAS EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND ADJUSTMENTS OF
THE WOK RANGE.
IN A PROMINENT LOCATION POST THE INSTRU CTIONS TO BE FOLLOWED IN THE EVENT THE
SMELL OF GAS IS DETECTED. THIS INFORMATI ON CAN BE OBTAINED FROM THE LOCAL GAS
SUPPLIER.
1
Advertisement
Table of Contents
Related Manuals for Patriot PT-WOK
Summary of Contents for Patriot PT-WOK
- Page 1 INSTALLATION & USER MANUAL FOR GAS WOK RANGE MODELS: PT-WOK & PT-WOK-16 IMPORTANT FOR YOUR SAFETY P LEASE READ THIS MANUAL COMPLETELY BRFORE ATTEMPTING TO INSTALL OR OPERATE THE WOK RANG. THIS MANUAL HAS BEEN PREP ARED FOR PERSONNEL QUALIFIED TO INSTALL GAS EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND ADJUSTMENTS OF THE WOK RANGE.
-
Page 2: For Your Safety
IMPORTANT IN THE EVENT A GAS ODORS DETECTED, SHUT DOWN UNITS AT MAIN SHUTOFF VALVE AND CONTACT THE LOCAL GAS COMPANY OR GAS SUPPLIER FOR SERVICE. FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE. EVENT OF A POWER FAILURE, DO NOT ATTEMPT TO OPERATE THIS DEVICE. - Page 3 A tray is provided to collect fat and water run-off; it opens to the front for inspection or drain-off. Power Nozzle size Pressure Model No. Burner PT-WOK 95,000 5” W.C PT-WOK-16 125,000 5” W.C THIS APPLIANCE IS EQUIPPED FOR NATURAL GAS.
-
Page 4: Installation
UNPACKING INSTALLATION This Wok range was inspected before leaving the factory. The carrier assumes full responsibility for the safe delivery upon acceptance of the shipment. Check for possible shipping damage immediately after receipt. If the Wok is found to be damaged, complete the following steps: Carrier must be notified within 5 business days of receipt. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS • Installation of all equipment should be performed by qualified, certified, and authorized personnel who are familiar and experienced with local installation codes. • Before installation, please read instructions completely and carefully. • Do not remove permanently affixed labels, warnings, or plates from the product. •... -
Page 6: Air Supply And Ventilation
AIR SUPPLY & VENTILATION • The area in front of, around and above the appliance must be kept clear to avoid any obstruction of the flow of combustion and ventilation air. • Adequate clearance must be maintained around the appliance for easy servicing. •... -
Page 7: Initial Pilot Lighting
CONNECTIONS • Please check installer supplied intake pipes visually and / or blow them with compressed air to clear any dirt particles, threading chips or any other foreign matter before installing a service line. When gas pressure is applied, these particles could clog nozzles. All connections must be sealed with a joint compound suitable natural gas, and all connections must be tested with a soapy water solution before lighting any pilots. -
Page 8: Cleaning And Maintenance
CLEANING & MAINTENANCE All equipment works better and lasts longer when maintained properly. Cooking equipment is no exception. Your appliance must be cleaned on a daily basis. DAILY MAINTENANCE BURNERS 1. Turn off range, remove all objects, and disconnect energy source. 2. -
Page 9: Troubleshooting
TROUBLESHOOTING ISSUE POSSIBLE CAUSES REMEDIES Insufficient gas pressure in pipe Contact local gas supply department Pilot not lighting Nozzle occlusion Dredge nozzle Insufficient gas pressure in pipe Contact local gas supply department Nozzle occlusion Dredge nozzle Pilot ignited, but Gas control valves broken Replace control valves the main burner Low flame distance... -
Page 10: Warranty
Patriot warrants its equipment against defects in materials and workmanship, subject to the following conditions: Patriot gas and electric equipment is warranted for one (1) year, effective from the date of purchase by the original owner. A copy of the original receipt or other proof of purchase is required to obtain warranty coverage.
