3-1. FRONT PANEL
1 Three screws
(BVTP 3x8)
5 Three screws
(BVTP 3x8)
3-2. BALANCE BOARD, DISPLAY BOARD AND VOLUME BOARD
9 DISPLAY board
2 Nut
1 Knob
(Volume)
SECTION 3
DISASSEMBLY
3 Flat type wire (19 core)
(CNS701)
9 Flat type wire (19 core) (CNS105)
7 Remove the connector (CNS410)
8 Front panel
7 Six screws
(BVTP 2.6x8)
3 Knob
(Balance)
— 22 —
4 Flat type wire (17 core)
(CNJ203)
6 Flat type wire (19 core) (CNS402)
8 Remove the four claws.
5 BALANCE board and
VOLUME board
6 Bracket
2 Screw
(BVTP 3x8)
4 Two screws
(BVTP 2.6x8)
