- Page 1 CX418 HD Logistics Thermal Label Printer User Guide （China） Stock Symbol 688365...
- Page 2 Warm Tips The K COMER team researched CX418 in 2020 and it is widely welcomed. In order to enhance the customer's sen- se of use, we have recently developed a new upgraded it- em-CX418HD, with high-definition version 300dpi, small t-...
-
Page 3: Product Introduction
Product introduction / CX418 HD Package contents Standard Accessories Printer Power Cable USB Line Quick Installation Guide User Guide Appearance and Components Front View: Rear View: Paper feed Paper out button Upper cover Power Button Uncap USB interface button pole... -
Page 4: Cable Connection
Quick Printer Installation / CX418 HD open close Power Line Cable Connection 1. Confirm the printer is Power-off (0); 2. Connect the power line to the printer; 3. Connect the other end of Power line to the socket;... - Page 5 open close USB Connection 1. Confirm the printer is Power-off (0); 2. Connet the USB B-Type line to the printer 3. Connect the other end of the USB B-Type line to the pc mainframe; 3. Turn on the printer power to be Power- on (I)
- Page 6 Consumables Installation 1. Face the back of the printer,hole down the paper guide with both hands to adjust the guide space according to the paper size; 2. Insert the thermal paper into the paper guide; 3. Feed the thermal label into the paper channel slowly, and the paper will automatically absorbed by detector Outside-scroll Installation 1.
- Page 7 Paper Jam 1. Facing the front of the printer, move the opening button forward with both hands at the same time to open the top cover 2. Lift the top cover upwards 3. After pulling the jammed paper out of the paper path, replace it with new paper and discard the wrinkled paper 4.
- Page 8 Driver Installation & Print Test / CX418 HD Note: 1.Please download the driver from website ( https://kcomer.com ) or u-disk. 2.The driver file is safe, please rest assured to install. 3.There are detailed guide and video for your reference,if you still have probl- ems or questions, please contact us for help,Email:service1@kcomer.com...
- Page 9 Find the driver and prompt to install. Installed successfully. After installation, place direct thermal label, then start to print a test page and set print paremeter.
- Page 10 Find the installed printer. Click【Setting】-【Devices】-【Printer and Scanners】 for windows 10 (as the pic shows), or click 【Control Panel】-【Devices and Pr- inters】for windows 7. Click "print a test page" and the test page will show the detailed information of the printer. Click "Printer Properties" to set print density, print speed and so on.
- Page 11 Please contect the printer to computer and ensure the printer on, download the windows driver from website or u-disk. Note: If there is a error “the pkg file can’t be opened because it is from undentifi- ed developer” when installing the MAC driver, please allow the macOS to finish the installation：...
- Page 12 Go to the "Security & Privacy", to allow the driver open (As the picture shows). Continue to install the driver.
- Page 13 Please confirm the CX418 HD printer already installed. Next how to find the Installed printer in your Mac? Pls find the installed printer driver in the launchpad of your Mac.
- Page 14 Pls click the system preference. Select 【Printer and Scanners】,Add the printer drive;...
- Page 15 If the page display your printer information, the installation succeeds.
- Page 16 Set the print size according to your needs.
- Page 17 Button FEED Instruction / CX418 HD Function Printer Status Operation of FEED Feed in a blank paper Press standby automatically - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
- Page 18 Indicator Light Instruction / CX418 HD Indicator Lignt Status Printer Status Blue light on Printer standby Purple light on Printer head overheated Red light on Upper cover problem Red light flash slowly Lack paper Red light flash quickly Label learn mode problem...
- Page 19 The printer uses Tips Note: 1. To ensure the optimal print quality, please use the original factory power adapter. 2. Please avoid to use the poor quality label which wear the printer and cause damage to the printer. 3. Please clean the print head regularly to ensure the high-quality print effect. 4.
- Page 20 Printing Width 50 -108 mm Paper Width 50 -118 mm Power Adapter 1.5A The Comer thermal printer is covered by one-year warranty. For any questions or suggestions, please email to service1@kcomer.com For any further information, please visit our website: https://comer-us.com...
