  • Page 1 EN User Manual | Washing Machine LFN7G8434F aeg.com\register...

  • Page 2: Table Of Contents

    Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. TECHNICAL DATA..................7 5.

  • Page 3: General Safety

    • Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. • Children of less than 3 years of age should be kept away from the appliance unless continuously supervised.

  • Page 4: Safety Instructions

    • The appliance must be connected to the water mains using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre. • Old hose sets must not be reused. • If the mains power supply cable is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.

  • Page 5: Water Connection

    • Make sure that the parameters on the • Follow the safety instructions on the rating plate are compatible with the detergent packaging. electrical ratings of the mains power • Do not put flammable products or items supply. that are wet with flammable products in, •...

  • Page 6: Product Description

    These lamps are intended to withstand • Disconnect the appliance from the mains extreme physical conditions in household electrical and water supplies. appliances, such as temperature, • Cut off the mains electrical cable close to vibration, humidity, or are intended to the appliance and dispose of it.

  • Page 7: Technical Data

    The rating plate reports the model name (A), product number (B), electrical ratings (C) and serial number (D). Mod. xxxxxxxxx Prod.No. 910000000 00 000V ~ 00Hz 0000 W 00000000 4. TECHNICAL DATA Dimension Width/ Height/ Total depth 59.6 cm /81.9 cm /55.3 cm Electrical connection Voltage 230 V...
  • Page 8 5.2 The appliance is equipped with ... 5.3 Unpacking WARNING! Use the gloves. WARNING! Remove all the packaging and the transit bolts before installing the appliance. 1. Put two packaging elements on the floor under the appliance. WARNING! It is strongly recommended that this action is carries out by two persons.
  • Page 9 3. Remove the protection from the bottom. 4. Return the appliance in vertical position and remove the socket protection. 5. Remove the power supply cable and the drain hose from the hose holders. It is possible to see water flowing from the drain hose.

  • Page 10: Positioning And Levelling

    7. Close the holes with the plastic caps you find in the user manual bag. Put the smallest cap F in upper hole and the two bigger caps G in lower holes. We recommend that you keep the packaging and the transit bolts for any movement of the appliance.

  • Page 11: Hose And Cable Connection

    5.5 Hose and cable connection 1100 mm 1450 mm 1230 mm 960 mm 1360 mm 900 mm The inlet hose 1. Remove the inlet hose from inside the drum. 2. To connect the water inlet hose towards the proper direction and with the proper inclination, check the position of the water tap before connecting it to the back of the appliance.

  • Page 12: Water Drainage

    5. Connect the water inlet hose to the cold water tap with 3/4 thread. WARNING! The inlet water shall not exceed 25 °C. WARNING! Make sure that there are no leaks from the couplings. Use the hose supplied with appliance. Do not use an extension hose if the inlet hose is too short.
  • Page 13 To a wall-pipe Directly to a built-in drain pipe in the room wall and tighten it with the supplied cable tie L. You can extend the drain hose to maximum 400 cm. Contact the service centre for the other drain hose and the extension. 5.6 Building in This appliance has been designed to be built into the kitchen furniture.

  • Page 14: Preparation And Assembly Of The Cupboard Door

    The appliance is also equipped with an adhesive sponge pad H that you can find inside the drum. Attach it on the top of the appliance where indicated in the drawing. When levelling the appliance under the furniture, DO NOT squeeze the sponge pad. Before proceeding with appliance building in, bring it near the recess and preposition the inlet hose, the drain hose and the mains cable.
  • Page 15 Reversibility of the cupboard door Carry out the cupboard door reversibility before the appliance is built in completely. If the cupboard door has to be opened from left to right, invert the position of the hinge supports M with the magnetic plate N and lower plate O. Make sure that the plate with magnet is on the upper position.
  • Page 16 Set the position of the lower hole respecting dimensions and distances shown in the drawing 16-22 mm (449 mm). Countersink the holes. Ø 35 mm 12,5 - 14 mm 22±1,5 mm 595-598 mm Hinges To mount the hinges it is necessary to drill two holes (dia.
  • Page 17 Counter-magnet The appliance is pre set for a magnetic closure. For a correct closure: 1. Position the screw C and the counter-magnet D on the magnetic plate N. Lean the cupboard door against the screw until it leaves a mark. 2.

  • Page 18: Control Panel

    6. CONTROL PANEL 6.1 Control panel description 90° Lana/ 1400 Lãs + Seda Eco 40-60 60° 1200 Extra Rápido 40° 30° Edredón/ 20° Edredão Frio Night Higienizar Temp. °C Centrif. Pre-Lava. Vapor Plus Soft Plus touch button and permanent Extra Rinse option The permanent options are set by Pre-Lava.

  • Page 19: Dial And Buttons

    Door locked indicator. Delay start indicator. The digital indicator can show: • Reset position ( • Programme duration (e. g. • Delay time (e. g. • Cycle end ( • Warning code (e.g. • Error indicator ( • Indication of total operating hours of the appliance. Refer to the 'Operating hours counter' section in the 'Settings' paragraph for more details.

  • Page 20: Programme Dial

    7.3 Programme dial The intermediate and the final spinning phases are suppressed and the For selecting the desired washing programme ends with water in the drum. programme. Refer to 'Programmes' chapter This helps to reduce creasing. The door for more details. stays locked.

  • Page 21: Permanent Extra Rinse

    This option increases the programme This option can increase the programme duration. duration. This option is not available with a When the programme stops the display temperature lower than 40 °C. shows , the indicator goes off and 7.8 Permanent Soft Plus the indicator and the Inicio/Pausa led are steady on.
  • Page 22 The display shows the indicator and the indicator selected delay time. After touching the Inicio/ Pausa button, the appliance begins the countdown and the door is locked. 7.13 Extra Rápido With this option you can reduce the programme duration depending on the load ■...

  • Page 23: Programmes

    8. PROGRAMMES 8.1 Programme Chart Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture load Temperature range Washing programmes Eco 40-60 1400 rpm 8.0 kg White cotton and fast-coloured cotton. Normally soiled items.
  • Page 24 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture load Temperature range 1200 rpm 2.0 kg Outdoor 1.0 kg Do not use fabric softener and make sure that 30 °C 40 °C - Cold there is no softener residue in the detergent dispenser.
  • Page 25 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture load Temperature range 1.0 kg Cottons, Synthetics, Delicates. Short and gentle steam pro‐ gramme to refresh even your very delicate garments, includ‐ Vapor ing very delicate garments with sequins, lace etc.
  • Page 26 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture load Temperature range 800 rpm 3.0 kg Special programme for Denim clothing with delicate (Maximum ref‐ washing phase to minimize colour fading and marks. For Denim erence spin better care a reduced load size is recommended.

  • Page 27: Programme Options Compatibility

    Programme options compatibility Programme Eco 40-60 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Algod. ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Sintéticos ■ ■ ■ ■ ■ ■ ■ Delicados ■...
  • Page 28 Programme ■ ■ ■ ■ ■ ■ Sport ■ ■ ■ ■ ■ ■ ■ ■ ■ Denim ■ ■ ■ ■ Lana/Lãs+Seda Pre-Lava. and Manchas/Nódoas cannot be selected together. This option is not available with temperature lower than 40 °C. If you set the No Spin option, the appliance performs draining only.

  • Page 29: Settings

    Programme Universal Liquid Univer‐ Liquid for col‐ Delicates Special oureds woollens powder 1) Sport ▲ ▲ ▲ Denim ▲ ▲ ▲ Lana/Lãs+Seda ▲ ▲ At temperature higher than 60 °C the use of powder detergent is recommended. ▲ = Recommended -- = Not recommended 8.2 Woolmark Premium Wool Care - Blue The wool wash cycle of this machine has been tested and ap‐...

  • Page 30: Factory Reset

    activates and deactivates the acoustic 1. Switch the appliance on by pressing signals). On/Off button. 4. After 3 seconds the total hours operated 2. Turn the programme knob to the by the appliance are shown in the display: Sintéticos programme (3rd position e.g.

  • Page 31: Filling The Detergent And Additives

    Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum indicated level ). This quantity will however guarantee the best washing results. After a washing cycle, if necessary, remove any detergent residue from the detergent dispenser.

  • Page 32: Setting A Programme

    • Do not exceed to liquid detergent dose is off and doesn't flash (e.g. programme dial indicated on the flap. on a wrong position). • Do not set the prewash phase. The related indicator stops flashing and stays • Do not set the delay start function. 5.

  • Page 33: Interrupting A Programme And Changing The Options

    3. Touch the Inicio/Pausa button again to start the new countdown. If the ProSense System has completed 11.8 The ProSense System load and the water filling has already started, detection the new programme starts without repeating the ProSense System. The water and the detergent are not drained After touching the Inicio/Pausa button:...

  • Page 34: Stand-By Function

    After five minutes from the end of the 3. When the programme is completed and programme, the energy saving function the door locked indicator goes off, automatically deactivates the appliance. you can open the door. 4. Press the On/Off button for a few seconds to deactivate the appliance.

  • Page 35: Stubborn Stains

    • Follow the washing instructions on the laundry care labels. • Do not wash white and coloured items together. • Some coloured items can discolour with the first wash. We recommend that you wash them separately for the first couple of times.

  • Page 36: Water Hardness

    • The choice and quantity of detergent will • Normally soiled laundry may be washed depend on: type of fabric (delicates, without prewash in order to save woollens, cottons, etc), the colour of detergent, water and time. clothes, size of the load, degree of soiling, •...

  • Page 37: Removing Foreign Objects

    Regularly examine the drum to check for limescale. Clean drum Every two months Regular detergents already contain water Clean detergent dispens‐ Every two months softening agents, but we recommend to run a cycle with an empty drum and a descaling Clean drain pump filter Twice a year product.

  • Page 38: Cleaning The Drum

    drawer, every two months carry out the following cleaning procedure how explained in the following diagrams: Always obey the instructions that you find on the packaging of the product. 1. Open the drawer. Press the catch downwards as indicated in the picture Check and remove objects (if there are any) and pull it out.

  • Page 39: Cleaning The Drain Pump Filter

    4. Insert the detergent drawer into the guide rails and close it. Run the rinsing programme without any clothes in the Regularly check the drain pump filter and drum. make sure that it is clean. Clean the drain pump if: •...
  • Page 40 180˚ 3. Turn the filter 180 degrees in anti-clockwise direction to open it, without removing. Let the water flow out. 4. When the bowl is full of water, turn the filter back and empty the container. 5. Repeat the steps 3 and 4 until the water stops to flow out.

  • Page 41: Cleaning The Inlet Hose And The Valve Filter

    8. Clean the filter under the water tap. 9. Put the filter back into the special guides by turning it clockwise. Make sure that you tighten the filter correctly to prevent leakages. 10. Close the pump cover. When you drain the water with the emergency drain procedure, you must activate the drain system again: 1.

  • Page 42: Emergency Drain

    45° 20° 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, carry 2. Close the water tap. out the same procedure, described in 3. Put the two ends of the inlet hose in a 'Cleaning the drain pump' paragraph.
  • Page 43 14.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Inicio/ Pausa button may flash continuously: If the appliance is overloaded, remove some items from the drum and/or keep pressed the door while touching the Inicio/Pausa...
  • Page 44 • The programme was not finished properly or the appliance stopped too early. Switch the appliance off and on again. Internal fail. No communica‐ • If the alarm code appears again, contact the Authorised Service Centre. tion between electronic ele‐ ments of the appliance.

  • Page 45: Emergency Door Opening

    Problem Possible solution • Make sure the levelling of the appliance is correct. Refer to "Installation in‐ struction". The appliance makes an un‐ • Make sure that the packaging and/or the transit bolts are removed. Refer to usual noise and vibrates. "Installation instruction".

  • Page 46: Consumption Values

    4. Take out the laundry and then close the appliance door. 15. CONSUMPTION VALUES 15.1 Comment The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database. Keep the energy label for reference together with the user manual and all other documents provided with this appliance.

  • Page 47: Environmental Concerns

    Off (W) Stand-by (W) Delay start (W) Time to Off/Standby mode is 15 minutes maximum. 15.3 Common programmes Programme Litres hh:mm °C Algod. 2.250 85.0 04:00 52.00 85.0 1400 90°C Algod. 1.350 80.0 03:25 52.00 55.0 1400 60°C Algod. 0.250 80.0 02:50 52.00...
