Q S G R U T M 5 2
Main Page > RUTM Routers > RUTM52 >
This Wiki page contains the online version of the
. Here you will nd an overview of the various components on the front and back
5 G R o u t e r
of a RUTM52 device, hardware installation instructions,
speci cations, and general safety information. It is highly recommended to acquaint yourself
with the Quick Start Guide before using the device. You can also locate a printed version of
the Quick Start Guide in the packaging box of your device.
S a f e t y i n f o r m a t i o n
Before starting operating the device, please review recommendations and precautions to
minimize the possibility of accidents. Safety precautions presented are supplementary and
subject to the local safety regulations. When various operations are executed on the device,
the user must fully follow the safety instructions and recommendations provided with the
device.
RF
4G, 5G, WiFi, GNSS
technologies
Max RF power 26 dBm@LTE, 26 dBm@5G, 20 dBm@WiFi 2.4G, 23 dBm@WiFi 5G
Power adapter Input: 0.8A@100-240 VAC, Output: 12 VDC, 2.0A, 4-pin plug
Mobile 617~960/1400~2690/3300~5900MHz, VSWR<3, gain <4dBi, Omidirectional, SMA male
antenna connector
2400~2500 /4950~5850 MHz, 50Ω, VSWR<2, gain** 3dBi, omnidirectional, RP-SMA male
WiFi antenna
connector
1575.42~1602 MHz, 2.2~5 VDC, VSWR<1.5, active total gain** 28 dB (typ.), RHCP polarization,
GNSS antenna
SMA male connector
* Order code dependant.
https://wiki.teltonika-networks.com/view/QSG_RUTM52
QSG RUTM52 - Teltonika Networks Wiki
Q S G R U T M 5 2
Q u i c k S t a r t G u i d e ( Q S G )
Radio specifications
Bundled accessories specifications*
for the
rst login information, device
R U T M 5 2
