Wedgetail Accessory Solar Panel Bracket Kit Fitting Instruction
Congratulations on the purchase of your Australian made Wedgetail Roof Rack product.
Please read and follow the instructions carefully to ensure correct fitment.
Contact us if any parts appear missing, incorrect, or damaged.
Contact us if any question about the size of platform to ensure the correct fitment
Scan QR code for a fitting demonstration
•
Hex key (5mm)
1
2
3
WTA-SPB_Fitting_Rev1 Updated
Updated: 16 Apr 2024
Tools Required:
•
Spanner (13mm)
Kit Content
WTA-SPB Solar Panel Bracket
x2
16mm Rivet
x8
M8 X 22 Dacro Black
x8
•
Rivet Gun
4
5
COPYRIGHT TRADESMAN ROOF RACKS |WEDGETAILRACK.COM.AU
WTA-SPB
M8 Channel Nut
x4
8mm Nyloc Nut
x4
Advertisement
Related Manuals for WEDGETAIL WTA-SPB
Summary of Contents for WEDGETAIL WTA-SPB
- Page 1 Wedgetail Accessory Solar Panel Bracket Kit Fitting Instruction WTA-SPB Congratulations on the purchase of your Australian made Wedgetail Roof Rack product. Please read and follow the instructions carefully to ensure correct fitment. Contact us if any parts appear missing, incorrect, or damaged.
- Page 2 Wedgetail Accessory Solar Panel Bracket Kit Fitting Instruction WTA-SPB • Place the solar panel in desired position of the platform and align the solar panel bracket on the side across the two crossbars. • Mark the points where you need to drill the holes on the side of a solar panel bracket.
