- Page 1 Dual Monitor Extra Tall Desk Mount STAND-V002T Series Assembly Manual Individual Product SKUs STAND-V002T STAND-V002TW...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
-
Page 3: Package Contents
Package Contents A (x2) B (x2) C (x1) D (x1) VESA Plate Clamp Lower Pole E (x1) F (x1) G (x1) H (x2) I (x1) Upper Pole Pole Cap Pole Connector Cable Clip Grommet Plate J (x5) K (x1) Rubber Pad Support Plate Included Hardware &... -
Page 4: Assembly Steps
Assembly Steps STEP 1 Insert Pole Cap (F) into Upper Pole (E). -
Page 5: Option 1: Clamp Installation
STEP 2 Option 1: Clamp Installation Remove adhesive backing from Rubber Pads (J) and apply to the underside of Clamp (C). Attach Lower Pole (D) to Clamp using M6x16mm Screws (S-A). Tighten using 4mm Allen Wrench (T-B). Clamp the assembly to the desktop. 10-88mm Proceed to STEP 3 on Page 7... - Page 6 Option 2: Grommet Installation Disassemble the Clamp (C) using a Phillips screwdriver and remove the Clamp Bolt (C1). Remove adhesive backing from Rubber Pads (J) and apply to the bottom of Grommet Plate (I). Place Support Plate (M) onto Clamp Bolt (C1) and thread it through the grommet hole and into Lower Pole (D) as shown.
- Page 7 STEP 3 Slide Cable Clip (H) and Arm (B) onto Lower Pole (D) and secure by tightening the back screw using 6mm Allen Wrench (T-C).
- Page 8 STEP 4 Thread Pole Connector (G) into Lower Pole (D), then thread Upper Pole (E) into Pole Connector. Secure by tightening the set screws on Pole Connector using 3mm Allen Wrench (T-A). Poles Won’t Thread Into Connector? If Poles (D,E) are difficult to thread into Pole Connector, the two set screws may need to be loosened.
- Page 9 STEP 5 Slide the remaining Cable Clip (H) and Arm (B) onto Upper Pole (E). Secure by tightening the back screw using 6mm Allen Wrench (T-C).
- Page 10 STEP 6 Secure VESA Plates (A) to the back of monitors using approprate Screws (M-A thru M-D) and M5 Washers (M-E). Spacers (M-F) can be used if needed. Tighten using a Phillips screwdriver. Ensure Lip on VESA Plate is facing up. Slide monitors with VESA Plates (A) onto the arms and secure using Thumbscrews (S-B).
- Page 11 STEP 7 Adjust the monitors’ tilt by loosening the Adjustment Screw using 6mm Allen Wrench (T-C). Re-tighten once at the desired angle. Adjustment Adjustment Screw Screw Route cables and store Allen Wrenches in Cable Clips (H). Adjust as desired. 180° +45°...
- Page 12 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
