Summary of Contents for Orwak 3120
- Page 1 Edition1.5 From serial no 142762- Publ. no 1000175-00 OM 3120, 2023-02 ORWAK 3120 ORIGINALNA NAVODILA ZA UPORABO ORIGINAL OPERATING INSTRUCTIONS...
-
Page 3: Table Of Contents
Temperature range of use (special oil): -10°C to +40°C Temperature range of use (special oil): -10°C to +40°C -10 °C ** -10 °C ** +5 °C +5 °C XXXX (npr. Compactor 3120) XXXX (ex Compactor 3120) ** - XXXXX (npr. 151001) ** - XXXXXX (ex 151001) *** - 490XXXX - XX (npr. -
Page 4: Varnostne Informacije
Slovenščina OPOZORILA IN DOLŽNOSTI UPRAVLJAVCA Ta priročnik mora biti vedno na voljo v bližini stiskalnice. Vsak upravljavec mora v celoti prebrati in upoštevati vsa navodila v tem priročniku, preden dobi dovoljenje za uporabo naprave. Vsi upravljavci morajo nujno preučiti in v celoti razumeti uporabniški priročnik, pri čemer morajo biti še posebej pozorni na razdelek z varnostnimi postopki. -
Page 5: Deli Stroja
Slovenščina DELI STROJA Držalo za trak Zaustavljanje v nujnem primeru Nadzorna plošča Gumbi za baliranje Plošča za prešo Zgornja vrata Zapahi Vrata Jermen za izmet Mehanizem za izmet bal Hidravlična enota Zadnji pokrov / pokrov za mehanizem za izmet bal Preklopni pokrov za vrata... -
Page 6: Varnost
slovenščina VARNOST PRED namestitvijo in začetkom uporabe stroja preberite celotna navodila za uporabo. Naše garancijske zahteve za izdelek: • upoštevanje navodil brez izvajanja sprememb ali modifikacij izdelka, • uporaba originalnih rezervnih delov ter hidravličnih olj in maziv, ki jih priporoča proizvajalec stroja, servisiranje izdelka vsaj enkrat letno. -
Page 7: Področje Uporabe
slovenščina PODROČJE UPORABE Ta stroj je hidravlična stiskalnica za stiskanje prožnih materialov, kot je lepenka, papir in plastika. Stiskani material mora biti enakomerno porazdeljen v komori. S stiskanjem kompaktnega ali predhodno stisnjenega materiala lahko poškodujete stroj. Stroj lahko uporabljate samo v prostorih pod streho, ki zaščiteni pred vetrom in imajo normalno osvetlitev. -
Page 8: Navodila Za Uporabo
slovenščina NAVODILA ZA UPORABO 4872248-00 (VG13) Paper Papir Plastic Plastika OPOZORILO! V delovnem območju stroja se lahko zadržuje samo upravljavec. Namestitev trakov Odprite vratca. 1 Držalo traku pritrdite na zadnji del stroja. 2 Valje trakov postavite na držalo traku in vstavite trakove skozi označene odprtine. -
Page 9: Namestitev
slovenščina NAMESTITEV Box 58 576 22 Sävsjö Sweden Box 58 Type Date 576 22 Sävsjö Product No Sweden Weight Serial No Type Date Product No Temperature range of use (standard oil): +5°C to +40°C +40 °C Temperature range of use (special oil): -10°C to +40°C Weight +5 °C -10 °C **... -
Page 10: Tehnične Specifikacije
1184 ~1025 Višina: 460 mm Širina: 1000 mm TRANSPORT Velikost bale: Višina: približno 800 mm 3120 Globina: 700 mm Širina: 1000 mm Teža (papir): do 100 kg Teža (plastika): do 130 kg Nivo hrupa: < 62,3 (± 1,0) dB (A) (ISO 11200 in 11202) Barva: Dvodelni nanos prahu in barve na fosfatni osnovi. -
Page 11: Izjava O Skladnosti Es
IZJAVA O SKLADNOSTI ES Družba Orwak AB Svetsaregatan 4 S-576 33 Sävsjö, Švedska Tel: 46-382-15700 pod lastno odgovornostjo izjavlja, da je model izdelka, 4903120-00 – 4903120-99 4903120-S001 – 4903120-S999 na katerega se nanaša ta izjava, skladen z naslednjimi standardi ali drugimi normativi glede na določbe direktiv... -
Page 12: Tedenski Pregled In Vzdrževanje
slovenščina TEDENSKI PREGLED IN VZDRŽEVANJE OPOMBA! Med pregledom, vzdrževanjem, servisiranjem in odstranjevanjem zataknjenih odpadkov ipd.: 1. Pritisnite gumb za izbiro ročnega načina (MAN) na nadzorni plošči. 2. Odklopite napajanje stroja tako, da odklopite vtič iz električnega napajanja. 3. Ne delajte znotraj stroja. ODPRAVLJANJE NAPAK: Najprej preverite: ZAŠČITA PRED PREOBREMENITVIJO... - Page 13 OPOMBE...
-
Page 14: Safety Information
English OPERATOR WARNING & DUTY This manual must be available permanently near the baler. Each operator must read and follow the full instruction of this manual before being authorize. All operator must absolutely study and fully understand the operator’s manual, specifically pay a particular attention to the safety procedure section. -
Page 15: Parts Of The Machine
English PARTS OF THE MACHINE Strap holders Emergency stop Control panel Bale buttons Press plate Strap slots Shutter Latches Door Ejection belt Bale ejection mechanism Hydraulic unit Rear cover / cover for bale ejection mechanism Door flap... -
Page 16: Safety
English SAFETY Please read the entire operating instructions BEFORE installing and starting the machine. Our Warranty and Product Liability require that: • instructions are followed and that no alterations or modifications are carried out; • original spare parts, and hydraulic oils and lubricants recommended by the machine manufacturer are used;... -
Page 17: Range Of Application
English RANGE OF APPLICATION The machine is a hydraulically operated baler designed for compacting non-rigid materials such as cardboard, paper and plastic. The material being compacted should be evenly distributed in the chamber. Compaction of compact or pre-compressed material may result in damage to the machine. The machine should only be used in areas with a roof, wind protection and normal lighting. The machine is designed for use in the temperature range from -10 °C to +40 °C. -
Page 18: Operating Instruction
English OPERATING INSTRUCTIONS 4872248-00 (VG13) Paper Paper Plastic Plastic WARNING! Only the operator is allowed in the working area of the machine. Fitting the straps Open the doors. 1 Fix the strap holder to the rear of the machine. 2 Place the strap rolls on the strap holder and insert the straps through the designated holes. -
Page 19: Installation
English INSTALLATION Box 58 576 22 Sävsjö Sweden Box 58 Type Date 576 22 Sävsjö Product No Sweden Weight Serial No Type Date Product No Temperature range of use (standard oil): +5°C to +40°C +40 °C Temperature range of use (special oil): -10°C to +40°C Weight +5 °C -10 °C **... -
Page 20: Technical Specification
Height: approx. 800 mm Depth: 700 mm TRANSPORT Width: 1000 mm 3120 Weight (paper): up to 100 kg Weight (plastic): up to 130 kg Noise level: < 62.3 (± 1.0) dB (A) (ISO 11200 & 11202) Paint: Two-part paint and powder coat with phosphatising as base. -
Page 21: Ec Declaration Of Conformity
English English EC DECLARATION OF CONFORMITY Orwak AB Svetsaregatan 4 S-576 33 Sävsjö, Tel: 46-382-15700 declare under our sole responsibility that the product model 4903120-00 – 4903120-99 4903120-S001 – 4903120-S999 to which this declaration relates is in conformity with the following standards or other... -
Page 22: Weekly Inspection And Maintenance
English WEEKLY INSPECTION AND MAINTENANCE NOTE! During inspection and maintenance, servicing and the removal of trapped waste, etc: 1. Press the button to select manual mode (MAN) on the control panel. 2. Disconnect power to the machine by removing the plug from the mains. 3. - Page 23 NOTES...
-
Page 24: Hydraulic Diagram
4876345-50 idravlična sHema ydraulic diagram Ø2 0,1-10,1V 90-250 bar 2.5 cc 1.6 cc Description Item Svenska English Deutsch Français Español 1 Elmotor Electrical motor Elektrischer Motor Moteur électrique Motor eléctrico 2 Dubbelpump Double pump Doppelpumpe Double pompe Doble bomba 3 Sugfilter Suction filter Saugsieb Filtre... -
Page 25: Electrical Diagram
lektrična sHema lectrical diagram... - Page 26 lektrična sHema lectrical diagram...
- Page 30 COMPACTION SOLUTIONS FOR MOST TYPES OF WASTE ORWAK develops solutions for sorting and recycling waste ORWAK develops solutions for sorting and recycling waste materials that improve business efficiency, contribute to a materials that improve business efficiency, contribute to a cleaner working and natural environment to provide the best cleaner working and natural environment to provide the best total waste handling economy.
