OPERATION

DRY VACUUMING

See figure 4-11.
Be sure to read, understand all warnings and instructions in the
manual before use. Do not vacuum in areas with flammable gases,
vapours, or explosive dusts in the air.
Flammable gases or vapors include but are not limited to; lighter
fluid, solvent type cleaners, oil-base paints, gasoline, alcohol or
aerosol sprays. Explosive dusts include but are not limited to; coal,
magnesium, grain or gun powder. To reduce the risk of health
hazards from vapors or dust, do not vacuum toxic materials.
CAUTION
Never operate the vacuum cleaner without all of the filters
installed. This includes the HEPA filter and collection bag. Motor
damage, loss of operating efficiency and recirculation of hazardous
material into the work area will take place if not installed. Make sure
no battery pack is inserted in the battery ports before assembly.
NOTE: Make sure the power tool adaptor is fully fitted into the dust
port of the power tool.
1. Verify that no battery pack is inserted in the battery ports.
2. In order to prepare your vacuum for dry vacuuming, verify that
the HEPA filter is securely mounted. With power head removed
and in upside down position, make sure the filter is pushed in until
it stops against the power head and the filter cap is installed. Turn
the locking knob clockwise to lock the filter cap in place. (Fig 5)
3. For improved dust collecting, fit collection bag flange onto the
inlet stub, taking care not to damage the bag. (Fig 4)
4. Place the power head back on the tank, and secure it in place
using the latches. (Fig 6)
5. Insert the locking end of the hose into the vacuum port and lock
in place. Push the required attachment onto the free end of the
hose or extension. (Fig 7)
6. Open the battery port cover and insert a battery pack in the
battery port. (Fig 9)
7. Turn the motor on by turning the switch to the 'I' ON position.
(Fig 10)
8. Slide the speed selector for the desired vacuuming speed.
9. Once you have completed vacuuming, flip the switch to the 'O'
OFF position and remove all battery packs from the battery ports.
(Fig 10)
If filters are contaminated or damaged, they must be replaced prior
to performing wet vacuuming operations.
NOTE: Do not use the HEPA filter for wet vacuuming.

WET VACUUMING

See figure 11.
WARNING
WARNING
WARNING
Be sure to read, understand all warnings and instructions in the
manual before use. Do not vacuum in areas with flammable gases,
vapours, or explosive dusts in the air.
Flammable gases or vapors include but are not limited to; lighter
fluid, solvent type cleaners, oil-base paints, gasoline, alcohol or
aerosol sprays. Explosive dusts include but are not limited to; coal,
magnesium, grain or gun powder. To reduce the risk of health
hazards from vapors or dust, do not vacuum toxic materials.
1. Verify that no battery pack is inserted in the battery ports. Verify
that the tank is clean and free of dust and dirt.
2. Remove the HEPA filter and dust bag. (Fig 16 and reverse of
Fig 4)
3. Rinse out the inside of tank to remove any loose debris.
4. Carefully install the foam sleeve filter over the filter cage and place
the power head back on the tank. (Fig 11)
NOTE: Do not use the HEPA filter for wet vacuuming.
If filters are contaminated or damaged, they must be replaced prior
to performing wet vacuuming operations.
Wet vacuuming operation instructions
1. Fit the desired nozzle to the vacuum hose.
2. Verify that the switch is in the 'O' OFF position before inserting
the battery pack.
3. Open the battery port cover and insert a battery pack in the
battery port. (Fig 9)
4. Turn the motor on by flipping the switch to the 'I' ON position.
(Fig 10)
5. After use, empty the tank. (Fig 15)
NOTE: Do not use the HEPA filter for wet vacuuming.
NOTE: When vacuuming large quantities of liquids, do not immerse
the nozzle completely in the liquid. Leave a gap at the tip of the
nozzle opening to allow air inflow.
The machine is fitted with a float valve that stops the suction action
when the tank reaches its maximum capacity. You will notice an
increase in motor speed.
When this happens, turn off the machine, remove all battery packs,
and drain the liquid into a suitable receptacle or drain. To continue
vacuuming, refit the tank with the drain cap. After wet vacuuming,
turn the machine off and remove all battery packs. Empty the tank,
clean and dry the inside and outside before storage.
The foam filter must be removed after wet vacuuming, and the HEPA
filter must be reinstalled before dry vacuuming again.
BATTERIES
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C reduce the performance of the
battery pack. Avoid extended exposure to heat or sunshine (risk of
overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
