Summary of Contents for Ryobi RAINFABG1
- Page 1 RAINFABG1 AIR BLOW GUN OPERATOR'S MANUAL ORIGINAL INSTRUCTIONS...
- Page 2 Important! It is essential that you read the instructions in this manual before assembling, operating, and maintaining the product. Subject to technical modifications.
- Page 3 DESCRIPTION 1. Nozzle 3. NITTO style plug 5. Air hose (not included) 2. Trigger 4. Quick coupler (not included) Fig.2 Fig.1 Fig.3 Quick Quick connector connector Filter Tool compressor Cut-off valve Quick coupler Air hose Regulator (0-8.5 bar) Fig.4...
-
Page 4: General Safety Warnings
activities, the operator can experience discomfort in GENERAL SAFETY WARNINGS the hands, arms, shoulders, neck or other parts of the body. ■ For multiple hazards, read and understand the safety instructions before installing, operating, repairing, ■ While using the product, the operator should adopt a maintaining, changing accessories on, or working comfortable posture whilst maintaining secure footing near the product. -
Page 5: Additional Safety Instructions For Pneumatic Power Tools
■ Do not exceed the maximum air pressure stated on the product. Air blow gun ■ Never carry an air tool by the hose. Model RAINFABG1 SAFETY WARNINGS FOR BLOW GUN Average air consumption ≤180 L/min @ ■ Never use oxygen, combustible or any other bottled 4 bar(58 psi) gas as a power source. -
Page 6: Intended Use
WARNING! If any parts are damaged or missing do A-weighted sound pressure L pA =84 dB(A), not operate this tool until the parts are replaced. Use of level K pA =3 dB this product with damaged or missing parts could result in Sound power level L wA =95 dB(A), serious personal injury. -
Page 7: Maintenance
GENERAL OPERATING INSTRUCTION ■ Drain the air tank daily. Water in the air line will damage the product. See figure 3. ■ If the product cannot be used anymore, make sure to ■ Ensure the trigger is not depressed before connecting dispose of it so as not to impose hazards on people to the air supply. -
Page 8: Parts List
PARTS LIST Description Description Description Description NITTO style plug Switch pipe Switch seat Fluid nozzle O-ring 7.2x1.9 O-ring 2.6x2.2 Trigger Gun body O-ring 10.2x1.9 Trigger pin Switch spring Rectangle washer O-ring 8x1.5... - Page 12 31 Gilby Road, Mount Waverley VIC, 3149, Australia Techtronic Industries N.Z. Limited RYOBI is a trade mark of Ryobi Limited, and is used under license. Unit C, 70 Business Parade South NITTO is a registered trade mark owned by Nitto Kohki Co., Ltd.
