Summary of Contents for Texecom INS273-5
- Page 1 Installation Manual Premier Elite ComIP INS273-5...
- Page 2 • Upload/Download via Wintex UDL • Receive Push Notifications, Arm, Disarm, Part Arm & Reset via Texecom App's • Signal alarms to an Alarm Receiving Centre •...
- Page 3 If you are not familiar with these concepts, you may require assistance from an IT professional before attempting to install the module. The ComIP module is designed to be fitted inside the control panel and is powered via the harness connection supplied. INS273-5...
-
Page 4: Pcb Layout
100BASE-T Half Duplex; Activity Solid Green 100BASE-T Full Duplex Link Blinking Green 100BASE-T Full Duplex; Activity Solid Amber 10BASE-T Half Duplex Link Blinking Amber 10BASE-T Half Duplex; Activity Solid Green 10BASE-T Full Duplex Link Blinking Green 10BASE-T Full Duplex; Activity INS273-5... -
Page 5: Installation
Accessing your Router On your PC open your web browser and type the routers IP address into the address bar as shown and press enter. Values used are typical only; they may be the same as your own router. INS273-5... - Page 6 Click Add New or whatever your router displays and enter the required details. The MAC address is printed on the ComIP and will be required, as will the IP address you will be assigning to the ComIP. Once you have entered the details press Save. INS273-5...
-
Page 7: Port Forwarding
Exit Engineers mode on the control panel. The control panel can now be accessed on your LAN, however to access the panel from the Texecom Apps or Wintex remotely, additional steps are required within the various programmes and the Control Panel. - Page 8 Local system to connect to the outside world (Internet WAN), and can change frequently. Because of the nature of Dynamic addresses you will need a third party service to manage the IP address to ensure you can always connect to your system. INS273-5...
- Page 9 For remote Connections it is highly recommended that you enable Push Notifications. This will mean that Texecom will track your IP address and update it as required. If your service provider does not provide you with a fixed IP address (most don't) you will require a third party DDNS provider to allow the app to operate remotely if you do not Enable Push notifications.
- Page 10 • Scroll to Poll IP Every • Press / and then enter a value 15 minutes (015). Do not exit the menu, now we will setup the reporting options. Texecom App Server Address Primary IP Address 54.88.92.200 Port Number 10001...
- Page 11 Press to start the test call. All communication devices on the system will carry out a test call. Once completed and if successful you will receive a notification from the Control Panel to the App. Do not exit Engineers mode yet, please read below INS273-5...
- Page 12 The IP address will have changed. The address now being shown is provided by your ISP and will match the WAN IP address shown in your router. If for some reason this has not worked please see details below to troubleshoot the installation. INS273-5...
-
Page 13: Troubleshooting
IP address of the router connected to the same LAN segment as the ComIP. The gateway address must be within the local network. Netmask (Subnet Mask) A netmask defines the number of bits taken from the IP address that are assigned for the host section. The default mask is 255.255.255.0 (8 bits). INS273-5... -
Page 14: Operation
Push Notifications Push notifications are used entirely at the users own risk and Texecom will accept no liability for system failure, missed communications, failure of polling, failure of message delivery or any other failing which may occur. -
Page 15: Warranty
ATS level 2 and environmental class 1 or 2. Warranty All Texecom products are designed for reliable, trouble-free operation. Quality is carefully monitored by extensive computerised testing. As a result the ComIP is covered by a two-year warranty against defects in material or workmanship. - Page 16 Texecom Limited, Bradwood Court, St. Crispin Way, Haslingden, Lancashire BB4 4PW, England. Technical Support: UK Customers Tel: 08456 300 600 (Calls charged at 3.36 pence per minute from a BT landline. Calls from other networks may vary.) International Customers Tel: +44 1706 233875 Email: techsupport@texe.com...
