- Page 1 User Manual RSS 3000 DUAL INVENTIVE BELGIËSTRAAT 5 5061 KG OISTERWIJK Telephone: +31 (0)13-5339969 Date: September 2024 Email: info@dualinventive.com Version: 0.4 Internet: dualinventive.com User manual: Original...
-
Page 2: Table Of Contents
7.2 Installing the RSS 3000 ..................20 7.2.1 Mounting the RSS 3000 ................20 7.2.2 Installing the relay cables into the RSS 3000 ..........20 7.3 Functional test ....................21 Setup MTinfo 3000 ....................23 Operations: Switching ..................24 9.1 Introduction ....................24 9.2 Manual switching ..................... - Page 3 10.4 Errors and Alerts – Reminders................29 11 Maintenance ......................31 11.1 Periodic maintenance ..................31 11.2 Accessories ....................31 12 Abbreviations ...................... 32 13 Lifespan ......................33 13.1 Warranty and delivery conditions ..............33 14 Disposal ......................34 User manual RSS 3000 Page 3 of 34...
-
Page 4: Version History
REFERENCE APPROVED 01.12.2022 Initial Version Alex Ruijs Updated Pictures and Tech 10.05.2023 Alex Ruijs Specs Revised based on feedback 10.08.2024 Alex Ruijs from users and developers Proofread, New Images 09.09.2024 Alex Ruijs User manual RSS 3000 Page 4 of 34... -
Page 5: Preface
Carefully read and understand this manual to ensure proper product. Keep this manual within close proximity of the RSS 3000, for quick reference during usage. This manual is integral to the RSS 3000. In case of resale or trade-in, it must accompany the product. -
Page 6: User Roles For The Rss 3000
MTinfo 3000. After certification, the user receives a personal MTinfo 3000 account for the RSS 3000 with the assigned user rights. Certified users are always responsible for keeping the username, password and/or PIN code confidential. -
Page 7: User Manual Convention
• Operator: section 9. The RSS 3000 is supported by the web interface MTinfo 3000 and the app. The work planner will frequently use MTinfo 3000 web, and operator will frequently use the app. To alert the reader to safety issues and essential information, the following symbols and terms... -
Page 8: Introduction
Furthermore an RSS 3000 can be used in conjunction with other RSS 3000 and ZKL 3000 RC remote control track circuit operating devices, to provide flexible and larger areas of protection for track workers. -
Page 9: Specifications
Protects a section of a track by remote control switching of a predesigned and installed signal interlocking circuit independently of the railway signaling controller/despatcher/signaler. Can be operated remotely and manually. • Can be remotely switched and monitored through Dual Inventive’s cloud based electronic control platform MTinfo 3000. SPECIFICATION VALUE •... -
Page 10: Dimensions
3.3.2 Dimensions Figure 1 Dimensions and views of RSS 3000 DESCRIPTION Top View Front View Side View 3.4 Worksite Always ensure your own safety when entering the railway environment. Follow the applicable local regulations and organizational procedures. Please feel free to define your own labor rules in addition to these regulations and procedures. -
Page 11: Product Description
Cloud Light Switch status indicator The RSS 3000 can be connected to one relay within a relay cabinet, allowing it to switch the connected relay on or off. The RSS 3000 comes equipped with an antenna to ensure a proper 4G telecommunications connection is made. - Page 12 The CloudLight on the RSS 3000 displays several states of the RSS 3000, such as its connectivity (online or offline) and error state. The green LED on the RSS 3000 indicates whether it has switched the railway interlocking.. When this LED starts blinking green, the railway interlocking it is connected to has been correctly switched .
-
Page 13: Transport Case And Accessories
Antenna extension cable; Available in 2m or 5m (depends on relay room size) Antenna Relay connector with 2 uniform keys M5 nuts Wire insertion tool The RSS 3000 and its accessories are delivered in a recyclable box. User manual RSS 3000 Page 13 of 34... -
Page 14: Identification
4.5 Work scenarios The RSS 3000 is used for long term installation in a relay cabinet and is used to switch signals and other railway signaling assets whenever a work zone needs to be secured. This can be used for both short-term and long-term work. -
Page 15: Terms Of Use
See chapter 2.5.1 Technical specifications.Environment The RSS 3000 can be used within a temperature range from -20 to 60 °C whilst inside a relay cabinet. The RSS 3000 is not water- or dustproof and should therefore be protected from rain, sand or other particles that may damage it. -
Page 16: Safety
Guarantee safety while installing the RSS 3000. Installing the RSS 3000 is a job in itself. Installation should only be undertaken by those deemed competent by the relevant infrastructure controller. -
Page 17: Key Switch
Use the key switch for the positions: ON, OFF and OPERATIONAL. The function and use of these positions are explained in section 7 and 9. 5.5.2 Cloud light The cloud light shows the status of the RSS 3000 while it is operating. The cloud light has the following indications: INDICATION STATE Blue (Constantly lit) Online and is working properly. - Page 18 & error messages, see section 10. Try to resolve.. If the error remains, contact Dual Inventive for support. DANGER Do not use the RSS 3000 when it has an error. User manual RSS 3000 Page 18 of 34...
-
Page 19: Transport And Storage
NOTE The device can be installed in the zone B (1-3 meters away from the track) When you store the RSS 3000 for a longer period before installation, follow these instructions for proper storage: Make sure that the content of the box is complete. -
Page 20: Installation
Installing the relay cables into the RSS 3000 Once the RSS 3000 has been mounted in the relay cabinet and the antenna has been installed, the relay cables can be connected to the RSS 3000 through the connector plug which is included in the box. -
Page 21: Functional Test
Perform the functional test with the installed RSS 3000 to verify that the device is working as intended. During the test, check the status of the RSS 3000 in MTinfo 3000. - Page 22 Figure 2 Key Positions DESCRIPTION Operational User manual RSS 3000 Page 22 of 34...
-
Page 23: Setup Mtinfo 3000
Inventive Cloud based control system MTinfo 3000. The setup in MTinfo 3000 for the RSS 3000 is similar to that of other Dual Inventive devices such as the ZKL 3000 RC and RDI 3000. It allows users who have experience with setting up a project for the ZKL 3000 RC, to create a project with one or more RSS 3000s. -
Page 24: Operations: Switching
9 OPERATIONS: SWITCHING 9.1 Introduction After the installation of the RSS 3000 and the setup of MTinfo 3000, you can switch the RSS 3000 in accordance with the rules of the railway infrastructure controller: • manually with the key; •... - Page 25 NOTE For instructions on remote switching the RSS 3000 in the MTinfo 3000 SMART phone application, refer to the User manual MTinfo 3000 app. You can download this manual from www.dualinventive.com/en/downloads/ User manual RSS 3000 Page 25 of 34...
-
Page 26: Troubleshooting
RSS 3000 is functioning correctly. The RSS 3000 is equipped with an SD card to store data from the device. The SD card is not accessible to the user and can only be read by Dual Inventive. The user can access data of the RSS 3000 using MTinfo 3000. -
Page 27: Errors, Alerts And Warnings
EXPLANATION ACTION Check the device connector and cable RSS 3000 “Serial Number“ RSS 3000 switch status is unknown or to the Relay and replace if damaged. If Detection NOT ok. Please cannot be guaranteed The detection is this does not solve the issue replace check manual for more not OK. - Page 28 2001042 `DNE_WRN_FIRMWARE_DNCM_MISMATCH` Expected dncms mismatch 2001058 `DNE_WRN_FIRMWARE_SECTION_BROKEN` A switch section is broken 2001059 `DNE_WRN_FIRMWARE_SELFTEST_SKIPPED` Self test skipped because not all sections where open 2001061 `DNE_WRN_FIRMWARE_DNCM1_SD_CARD_ERROR` The sd card have an error (DNCM1) User manual RSS 3000 Page 28 of 34...
-
Page 29: Errors And Alerts - Reminders
10.4 Errors and Alerts – Reminders For offline and critical events, a reminder system is introduced. The reminders help the user to remember that there is an unresolved issue with a specific RSS 3000 NOTE In the event of persistent error messages requiring examination of, or manual... - Page 30 ALERT EXPLANATION ACTION Reminder: RSS 3000 “Serial Check the power source of the RSS Reminder message when the device is Number“ is offline. Please 3000 or check the Status page for offline, and the device is in an activated check manual for more network outage.
-
Page 31: Maintenance
11 MAINTENANCE 11.1 Periodic maintenance The RSS 3000 is designed to operate within a relay cabinet, which is designed to withstand an environment where it is exposed to all kinds of weather, shocks, vibrations, and electromagnetic signals. As such, the RSS 3000 is not intended to be used outside of these protected cabinets and does not require periodic maintenance. -
Page 32: Abbreviations
12 ABBREVIATIONS ABBREVIATION EXPANSION Normally Closed RSS 3000 Remote Safety Switch 3000 Personal Protective Equipment User manual RSS 3000 Page 32 of 34... -
Page 33: Lifespan
13 LIFESPAN The RSS 3000 does not need to be serviced periodically by Dual Inventive. It has a lifespan of 10 years. 13.1 Warranty and delivery conditions Dual Inventive's products are carefully manufactured from high-quality materials. The RSS 3000 is supported by a service contract that contains the: •... -
Page 34: Disposal
CAUTION The owner of the RSS 3000 is responsible for proper disposal. Dual Inventive offers a service for responsible collection and recycling of the RSS 3000. Please contact Dual Inventive for this service. If no take-back agreement has been made, consult local authorities and specialized disposal companies.
